NETGEAR GS724TPv2 Manual

ProSAFE 24-Port Gigabit

Smart Managed Switch with

PoE+ and 2 SFP Ports

Hardware Installation Guide

Model GS724TPv2

April 2017

202-11766-01

350 E. Plumeria Drive

San Jose, CA 95134

USA

Support

Thank you for purchasing this NETGEAR product.You can visit www.netgear.com/support to register your

product, get help, access the latest downloads and user manuals, and join our community.We recommend that

you use only official NETGEAR support resources.

Conformity

For the current EU Declaration of Conformity, visit http://kb.netgear.com/app/answers/detail/a_id/11621.

Compliance

For regulatory compliance information, visit http://www.netgear.com/about/regulatory.

See the regulatory compliance document before connecting the power supply.

Trademarks

©NETGEAR, Inc., NETGEAR, and the NETGEAR Logo are trademarks of NETGEAR, Inc.Any non-NETGEAR

trademarks are used for reference purposes only.

GS724TPv2 ProSAFE 24-Port Gigabit Smart Managed Switch with PoE+ and 2 SFP Ports

Contents

Chapter 1 Introduction

Overview................................................................................................................5

Features.................................................................................................................5

Safety Instructions and Warnings..........................................................................7

Chapter 2 Hardware Overview

Front Panel...........................................................................................................10

Back Panel...........................................................................................................11

LEDs....................................................................................................................11

Switch Hardware Interfaces.................................................................................12

RJ-45 Ports for 10/100/1000BASE-T Ethernet Connectivity...........................12

SFP Ports for Fiber Connectivity.....................................................................13

Reset Button...................................................................................................13

Factory Defaults Button...................................................................................13

Chapter 3 Installation

Step 1: Prepare the site.......................................................................................15

Step 2: Protect Against Electrostatic Discharge...................................................16

Step 3: Unpack the Switch...................................................................................16

Step 4: Mount or Place the Switch.......................................................................17

Mount the Switch in a Rack.............................................................................17

Place the Switch on a Flat Surface.................................................................18

Optional Step 5: Install SFP Transceiver Modules...............................................18

Step 6: Attach Devices.........................................................................................19

Step 7: Check the Installation..............................................................................19

Step 8: Apply AC Power and Check the LEDs.....................................................20

Step 9: Manage the Switch..................................................................................20

Chapter 4 Applications

PoE Applications..................................................................................................22

PoE Overview..................................................................................................22

Connect PoE Equipment in a Business Environment......................................22

Connect PoE Equipment for Surveillance and Security..................................23

Desktop Switching...............................................................................................24

Chapter 5Troubleshooting

Troubleshooting Chart..........................................................................................26

PoE Troubleshooting Suggestions.......................................................................27

Additional Troubleshooting Suggestions..............................................................27

Introduction

This hardware installation guide is for the NETGEAR ProSAFE®24-Port Gigabit Smart Managed Switch with

PoE+ and 2 SFP Ports, Model GS724TPv2.

The switch provides twenty-four 1-Gigabit RJ-45 copper PoE+ ports with two dedicated SFP fiber ports.Power

over Ethernet (PoE) lets you provide power to PoE-capable devices such as WiFi access points, VoIP phones,

and IP security cameras so that you do not need to use power supplies for those devices.The switch can supply

up to 30W PoE+ (IEEE 802.3at) to each port, with a maximum PoE power budget of 190W across all active

PoE+ ports.

This hardware installation guide complements the installation guide that came with your switch.The resource

CD that came with your switch includes software and additional documentation and support resources.

This chapter serves as an introduction to the switch and includes the following sections:

•Overview on page 5

•Features on page 5

•Safety Instructions and Warnings on page 7

For more information about the topics that are covered in this manual, visit the support website

at support.netgear.com.

Note

For technical specifications, see the data sheet at

netgear.com/business/products/switches/managed. For switch documentation, see the

resource CD in the product package or visit downloadcenter.netgear.com.

Note

Overview

Theswitchprovidestwenty-four 10/100/1000BASE-TRJ-45 copperports that supportnonstop 10/100/1000M

Layer 2 and Layer 3 networks.All RJ-45 ports support PoE+.Two additional ports can accept small form-factor

pluggable (SFP) gigabit interface converters (GBICs) for 1G fiber connectivity.

For information about application samples, see Applications on page 21.Note

The switch provides administrative management options that let you configure, monitor, and control the

network.Using the web browser–based management interface, you can configure the switch and the network,

including the ports, the managementVLAN,VLANs for traffic control, link aggregation for increased bandwidth,

Quality of Service (QoS) for prioritizing traffic, and network security.

Initial discovery of the switch on the network requires the Smart Control Center program, which runs on a

Windows-based computer and is included on the resource CD.If you do not use aWindows-based computer,

get the IP address of the switch from the DHCP server in the network or use an IP scanner utility.

After discovery, you can configure the switch using the web browser–based management interface for

advanced setup and configuration of features, or the Smart Control Center program for very basic setup.

For more information, see the user manual, which you can download from downloadcenter.netgear.com.

You can install the switch freestanding or rack mounted in a wiring closet or equipment room.The switch

is IEEE compliant and offers low latency. All ports can automatically negotiate to the highest speed, which

makes the switch very suitable for a mixed environment with Fast Ethernet and Gigabit Ethernet.

Use Category 5e (Cat 5e) or higher-rated Ethernet cables terminated with RJ-45 connectors to make Gigabit

connections.

Features

The switch supports the following key hardware features:

•24 PoE+ Gigabit Ethernet ports.

•2 dedicated SFP fiber ports.

•PoE support:

-24 PoE+ (802.3at) ports

-Total PoE power budget of 190W for the switch

•MAC table size of 8K.

•Variable speed fan that can lower the noise level during low temperatures.

•Acoustic noise is equal to or less than 33 dBA at 25°C.

•52 Gbps full-duplex, nonblocking switch fabric.

Introduction

GS724TPv2 ProSAFE 24-Port Gigabit Smart Managed Switch with PoE+ and 2 SFP Ports

•Includes 19-inch rack-mount kit for rack installation.

•Full compatibility with IEEE standards:

-IEEE 802.3 Ethernet

-IEEE 802.3u 100BASE-T

-IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX

-IEEE 802.3ab 1000BASE-T

-IEEE 802.3i 10BASE-T

-IEEE 802.1Q VLAN tagging

-IEEE 802.3x Full-duplex flow control

-IEEE 802.3ad Link aggregation (LAG with LACP)

-IEEE 802.1ab LLDP

-IEEE 802.1p Class of Service (QoS)

-IEEE 802.1D Spanning Tree Protocol (STP)

-IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)

-IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)

-IEEE 802.1x RADIUS network access control

-IEEE 802.3az Energy Efficient Ethernet (EEE)

•AutoSensing and autonegotiating capabilities for all ports.

•Auto Uplink technology is supported on all ports.

•Automatic address learning function to build the packet-forwarding information table.The table contains

up to 8K Media Access Control (MAC) addresses.

•Store-and-forward transmission to remove bad packets from the network.

•Active flow control to minimize packet loss and frame drops.

•Half-duplex backpressure control.

•Per-port status LEDs and system status LEDs.

•NETGEAR green power-saving features:

-Energy efficiency mode that fully conforms to the IEEE802.3az standard

-Per-port automatic change to a lower power mode when the port link is down

Introduction

GS724TPv2 ProSAFE 24-Port Gigabit Smart Managed Switch with PoE+ and 2 SFP Ports

Safety Instructions andWarnings

Use the following safety guidelines to ensure your own personal safety and to help protect your system from

potential damage.

To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment, observe the following

precautions:

•This product is designed for indoor use only in a temperature-controlled (0–50°C) and humidity-controlled

(10–90% relative humidity) environment.

Any device that is located outdoors and connected to this product must be properly grounded and surge

protected.

To the extent permissible by applicable law, failure to follow these guidelines could result in damage to

your NETGEAR product, which might not be covered by NETGEAR’s warranty.

•Observe and follow service markings:

-Do not service any product except as explained in your system documentation.

-Opening or removing covers that are marked with the triangular symbol with a lightning bolt can

expose you to electrical shock.We recommend that only a trained technician services components

inside these compartments.

•If any of the following conditions occur, unplug the product from the electrical outlet and replace the part

or contact your trained service provider:

-The power cable, extension cable, or plug is damaged.

-An object fell into the product.

-The product was exposed to water.

-The product was dropped or damaged.

-The product does not operate correctly when you follow the operating instructions.

•Keep your system away from radiators and heat sources. Also, do not block cooling vents.

•Do not spill food or liquids on your system components, and never operate the product in a wet

environment.If the system gets wet, see the appropriate section in your troubleshooting guide, or contact

your trained service provider.

•Do not push any objects into the openings of your system.Doing so can cause fire or electric shock by

shorting out interior components.

•Use the product only with approved equipment.

•Allow the product to cool before removing covers or touching internal components.

•Operate the product only from the type of external power source indicated on the electrical ratings label.

If you are not sure of the type of power source required, consult your service provider or local power

company.

Introduction

GS724TPv2 ProSAFE 24-Port Gigabit Smart Managed Switch with PoE+ and 2 SFP Ports

•To avoid damaging your system, be sure that the voltage selection switch (if provided) on the power

supply is set to match the power at your location:

-115V, 60 Hz in most of North and South America and some Far Eastern countries such as South

Korea and Taiwan

-100V, 50 Hz in eastern Japan and 100V, 60 Hz in western Japan

-230V, 50 Hz in most of Europe, the Middle East, and the Far East

•Be sure that attached devices are electrically rated to operate with the power available in your location.

•Use only approved power cables. If you were not provided with a power cable for your system or for

any AC-powered option intended for your system, purchase a power cable approved for your country.

The power cable must be rated for the product and for the voltage and current marked on the product

electrical ratings label.The voltage and current rating of the cable must be greater than the ratings

marked on the product.

•To help prevent electric shock, plug the system and peripheral power cables into properly grounded

electrical outlets.

•The peripheral power cables are equipped with three-prong plugs to help ensure proper grounding. Do

not use adapter plugs or remove the grounding prong from a cable.If you must use an extension cable,

use a three-wire cable with properly grounded plugs.

•Observe extension cable and power strip ratings.Make sure that the total ampere rating of all products

plugged into the extension cable or power strip does not exceed 80 percent of the ampere ratings limit

for the extension cable or power strip.

•To help protect your system from sudden, transient increases and decreases in electrical power, use a

surge suppressor, line conditioner, or uninterruptible power supply (UPS).

•Position system cables and power cables carefully. Route cables so that they cannot be stepped on or

tripped over. Be sure that nothing rests on any cables.

•Do not modify power cables or plugs. Consult a licensed electrician or your power company for site

modifications.

•Always follow your local and national wiring rules.

Introduction

GS724TPv2 ProSAFE 24-Port Gigabit Smart Managed Switch with PoE+ and 2 SFP Ports

Hardware Overview

This chapter describes the switch hardware features.

The chapter includes the following sections:

•Front Panel on page 10

•Back Panel on page 11

•LEDs on page 11

•Switch Hardware Interfaces on page 12

Front Panel

The switch provides twenty four 10/100/1000BASE-T RJ-45 PoE+ ports and two SFP ports.The following

figure shows the front panel.

Figure 1. Front panel

Table 1. Front panel

DescriptionNumber

Power, Fan, and PoE Max LEDs.

For more information, see LEDs on page 11.

Reset button.

For more information, see Reset Button on page 13.

48 LEDs associated with the 24 Ethernet ports.For each port, the associated upper LED functions as the

combined speed and activity LED and the associated lower LED indicates the PoE status.

2 LEDs associated with the 2 SFP ports.For each port, the associated LED functions as the combined

link and activity LED.

For more information, see LEDs on page 11.

24 independent 10/100/1000BASE-T RJ-45 PoE ports.

For more information, see RJ-45 Ports for 10/100/1000BASE-T Ethernet Connectivity on page 12.

2 dedicated SFP fiber ports in which you can install GBICs for fiber connections.

For more information, see SFP Ports for Fiber Connectivity on page 13.

Factory Defaults button.

For more information, see Factory Defaults Button on page 13.

Hardware Overview

GS724TPv2 ProSAFE 24-Port Gigabit Smart Managed Switch with PoE+ and 2 SFP Ports

Otros manuales para GS724TPv2

Tabla de contenidos

Otros manuales de Cambiar de NETGEAR

NETGEAR

NETGEAR ProSafe Plus GS116E Manual de usuario

NETGEAR

NETGEAR FS726T - ProSafe Smart Switch Manual de usuario

NETGEAR

NETGEAR FSM7326P - ProSafe Managed Switch Manual

NETGEAR

NETGEAR GSM7328S - ProSafe Switch - Stackable Manual de usuario

NETGEAR

NETGEAR GSM7352SNA - Prosafe 48 Port Gigabit L3 Managed Stackable... Manual de usuario

NETGEAR

NETGEAR XS728T ProSAFE Manual de usuario

NETGEAR

NETGEAR FS108 - ProSafe 10/100 Desktop Switch Manual de usuario

NETGEAR

NETGEAR FE508 - Hub Manual de usuario

NETGEAR

NETGEAR GS716T - ProSafe Switch Manual

NETGEAR

NETGEAR FS116P - ProSafe 16 Port 10/100 Desktop... Manual de usuario

NETGEAR

NETGEAR ProSAFE GS105PE Manual de usuario

NETGEAR

NETGEAR GS728TPv3 Manual

NETGEAR

NETGEAR FSM7326P - ProSafe Managed Switch Manual de usuario

NETGEAR

NETGEAR Smart Switch GS752TXS Manual

NETGEAR

NETGEAR GS110 Manual de usuario

NETGEAR

NETGEAR GSM7248R - ProSafe Switch Manual de usuario

NETGEAR

NETGEAR ProSAFE GS724Tv4 Manual de usuario

NETGEAR

NETGEAR FSM7328S - ProSafe Switch Manual de usuario

NETGEAR

NETGEAR ProSafe GSM7328 Manual de usuario

NETGEAR

NETGEAR ProSAFE M7100-24X Manual de usuario

NETGEAR

NETGEAR M6100 Series Manual de usuario

NETGEAR

NETGEAR GS748Tv2 - Gigabit Smart Switch Manual de usuario

NETGEAR

NETGEAR GS305EP Manual de usuario

NETGEAR

NETGEAR GS724TP - ProSafe Smart PoE Switch Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
