NETGEAR FSM7328S - ProSafe Switch Manual de usuario

7000 Series (Firmware 6.0.0.15)

Configuring VLANs and Routing

Scenario:

Creation of a 2 VLAN Routed network with access to the Internet via

an FVS Router/Firewall.

VLAN 3 being the Users PC domain

VLAN 2 being the Internet domain

Network Diagram:

Physical Setup:

1x FSM7328S Prosafe Layer 3 Managed switch - Firmware 6.0.0.15

4x Windows XP Computers (2x on each VLAN)

1 x FVS___ Prosafe Firewall Router

Logical Setup:

FVS___ : 192.10.10.1/24

VLAN 2 –192.10.10.0/24

VLAN 3 –172.10.11.0/24

VLAN2 IP address 192.10.10.254

VLAN3 IP address 192.10.11.254

WORKING INSTRUCTIONS

Set the Management IP address

1) Plugged the console cable to the Serial port of the switch and the serial port on the

PC

2) Open a new Hyper Terminal session (connecting via the COM port) –settings 9600,

8 , None , 1, None

3) Power Cycle the switch

4) Upon POST the User: prompt will appear

5) Username is admin , password “blank”

6) Type Enable to access the privileged mode (password “blank” )

7) Type network protocol none to reset the network settings

8) Type network parms <<Management IP>> <<Subnet Mask>> <<Default Gateway

IP>>. For example network parms 192.168.0.1 255.255.255.0 192.168.0.1

9) User copy system:running-config nvram:startup-config to save the configuration

10) Check with show network if the settings are correct

The switch should now be accessible patching a CAT5 Straight-through cable. The PC

NIC must be configured with an IP address within the same subnet used to configure the

management IP of the switch (Example: 192.168.0.2 255.255.255.0

Creating a Routing VLAN2 and Routing VLAN3 via the SmartWizard

1) Access the GUI

2) Browse to Smart Wizard –VLAN routing Wizard

3) Assign the VLAN ID

4) Select the port(s) members of the VLAN (Use CTRL to select multiple ports)

5) Assign the VLAN IP address and Subnet Mask

6) Click on Submit. The UNIT/SLOT/PORT entry will show the Virtual PORT created

and associated to the new VLAN.

7) Perform point 1-6 to create VLAN3 (with relevant IP address)

WEB GUI instructions

Creating a Routing VLAN2 and Routing VLAN3 via the SmartWizard

1) Access the GUI

2) Browse to Smart Wizard –VLAN routing Wizard

3) Assign the VLAN ID

4) Select the port(s) members of the VLAN (Use CTRL to select multiple ports)

5) Assign the VLAN IP address and Subnet Mask

6) Click on Submit. The following statement should be prompted.

7) Perform point 1-6 to create VLAN3 (with relevant IP address)

8) The following summary should be obtained:

Checking routing is in place on the switch

1) Browse to Routing –RIP –Interface Summary

2) The following situation should appear

NOTE: The RIP admin mode will show ENABLE only if at least one active device is

patched into a port in the relevant VLAN

NOTA BENE:

Router/Firewall:

If the firewall as in this case is patched into a port in a specific VLAN (VLAN2 here),

ensure its static routing table contains a route back to the VLAN IP address for each of

the other VLANS on the switch that require Internet access.

For example in this case the FVS Firewall must contain the following route:

192.10.11.0 (Subnet) 255.255.255.0 (Subnet Mask) 192.10.10.254 (Default Gateway).

On the other hand another option would be to run RIP on the Firewall.
