NETGEAR FS205v2 Manual de usuario

Installation Guide

June 2019

Package contents

• Switch model FS205v2, FS208v2, GS205v2,

or GS208v2

• Power adapter (varies by region)

• Installation guide

Note: Ethernet cables are not included.

We recommend that you use Category 5e

(Cat 5e) cable or higher for Gigabit Ethernet

connections.

5-Port and 8-Port Unmanaged

Fast Ethernet Switch

(FS205v2 and FS208v2)

5-Port and 8-Port Unmanaged

Gigabit Ethernet Switch

(GS205v2 and GS208v2)

1. Register with the NETGEAR Insight app

1. Search for NETGEAR Insight and download the latest app.

2. Set up a NETGEAR account if you do not have one.

3. Tap the menu in the upper-left corner.

4. Tap REGISTER ANY NETGEAR DEVICE.

5. Enter the serial number located on the bottom of the switch, or use the

camera on your mobile device to scan the serial number bar code.

6. Tap GO.

The switch is registered and added to your account. You can now view the

switch in the NETGEAR Insight app.

Note: Because this is an unmanaged switch, you cannot configure or manage it in

NETGEAR Insight.

2. Connect the switch

Internet

Router

ReadyNAS

Sample connections

GS208v2

Desktop

Access point

Gaming console

3. Power on the switch

1. Connect the power adapter to the switch and plug it into an electrical outlet.

2. If your switch includes an On/Off button, make sure that the button is in the

On position.

On/Off

button

The LEDs indicate the status.

LED Description

Power • On. The switch is receiving power.

• Off. The switch is not receiving power.

Port • Solid green. The switch detected a link with a powered-on

device on this port.

• Blinking green. The port is sending or receiving trafc.

• Off. The switch does not detect a link on this port.

Support

Thank you for purchasing this NETGEAR

product. You can visit

https://www.netgear.com/support/ to register

your product, get help, access the latest

downloads and user manuals, and join our

community. We recommend that you use only

ofcial NETGEAR support resources.

Si ce produit est vendu au Canada, vous pouvez

accéder à ce document en français canadien à

https://www.netgear.com/support/download/.

(If this product is sold in Canada, you can access

this document in Canadian French at

https://www.netgear.com/support/download/.)

For regulatory compliance information including

the EU Declaration of Conformity, visit

https://www.netgear.com/about/regulatory/.

See the regulatory compliance document before

connecting the power supply.

Do not use this device outdoors. If you connect

cables or devices that are outdoors to this

device, see https://kb.netgear.com/000057103

for safety and warranty information.

Technical specications

Specications Description

Operating temperature 32°F to 104°F (0°C to 40°C)

FS205v2, FS208v2, GS205v2

power adapter output

5VDC, 0.7A

GS208v2 power adapter

output

12VDC, 0.5A

NETGEAR, Inc.

350 East Plumeria Drive

San Jose, CA 95134, USA

trademarks of NETGEAR, Inc. Any non-NETGEAR trademarks

are used for reference purposes only.

NETGEAR INTERNATIONAL LTD

Floor 1, Building 3,

University Technology Centre

Curraheen Road, Cork,

T12EF21, Ireland
