NETGEAR ProSecure UTM150 Manual de usuario

Installation Guide

Familiarize yourself with the connectors and controls on the back of the unit

Complete the Basic Setup

Follow these steps to quickly setup the UTM appliance.

Connect the Unit

For initial setup, connect the WAN Ethernet port to an active WAN connection such

as a broadband modern, connect a DHCP enabled PC to a LAN port, and turn on

the unit.

Verify the following:

• Power LED: It takes about a minute to boot. The power LED should turn solid

green. If it does not, see the Troubleshooting section of the Reference Manual.

• Test LED: When you first turn on the unit, the amber test LED will be lit for

approximately 2 minutes.

• WAN Status LED: The status LED on the connected WAN port should be lit. If

not, make sure the Ethernet cable is securely attached to the modem and the

WAN port, and that the modem is powered on.

• LAN Status LED: A LAN status LED should be lit. If not, ensure that the Ethernet

cable from the computer to the unit is securely attached at both ends, and that

the computer is turned on.

1. Use a browser to connect to

https://192.168.1.1.

7. Kensington lock 8. Console port

9. Factory reset button 10. Power connector

https://192.168.1.1

2. When prompted, enter admin for the User

Name and password for the Password.

Click Login.

You are now connected. After 5 minutes of

inactivity (the default login time-out), you

are automatically logged out.

Note: When the unit scans secure HTTPS

traffic, import its root CA certificate into client

browsers. Click the link at the bottom of the

Use the Setup Wizard for Basic Configuration

The Setup Wizard will guide you through the basic network and scanning setup.

Note: If you choose to bypass the Setup Wizard, be sure to configure an alerts

email address and change the admin password.

1. Start the Setup Wizard.

SelectWizards > SetupWizard

to start the wizard.

For guidance on how to fill in

the wizard screens, refer to the

online help or the Reference

Manual via a link in the

Support > Documentation

page.

2. Use the Setup Wizard to configure these basic network and scanning settings:

• LAN and WAN network settings.

• System time (NTP server) and time zone.

• Scanning of network protocols and services.

• Default scan actions when the unit detects threats.

• Scan exceptions like the maximum file size.

• Specify the notification server and notices to be used in email notifications.

• Scan engine and signature updates.

ProSecure™ Unified Threat Management (UTM) Appliance

Follow these instructions to configure your ProSecure Unified Threat Management

appliance to use a single WAN interface, and enable the default threat management

scanning. Then, consult the Reference Manual for instructions on configuring other

options such as multiple WAN settings, VPN, firewall, and custom scanning. You

can access the Reference Manual from the product management interface, via the

Resource CD and from the NETGEAR support site: http://kbserver.netgear.com.

Estimated time: 30 minutes.

Verify the Package Contents

• ProSecure™ UTM appliance.

• Installation Guide.

• Resource CD.

• Rubber feet (4) with adhesive backing.

• Rack mount brackets (some models).

• Power cord.

Familiarize Yourself with the Unit

Familiarize yourself with the ports and status lights on the front of the unit.

1. Green power LED 2. Amber test LED 3. USB port (for future use)

4. Gigabit LAN ports 5. LAN port 4 DMZ identifier 6. Gigabit WAN ports, dual

WAN model shown

November 2010

This symbol was placed in accordance with the European Union Directive 2002/96 on the Waste

Electrical and Electronic Equipment (the WEEE Directive). If disposed of within the European Union,

this product should be treated and recycled in accordance with the laws of your jurisdiction

implementing the WEEE Directive.

NETGEAR, Inc. in the United States and/or other countries. Other brand and product names are trademarks or

registered trademarks of their respective holders. Information is subject to change without notice.

3. Click Apply to save your changes.

The unit will reboot. Your computer will lose its connection to the unit if its IP

address is now on a different subnet. If so, restart the computer to refresh its

network settings.

Licenses

Your unit is bundled with three 30-day trial licenses.

• Web scanning

• Email scanning

• Support and maintenance

Activating the licenses starts their term of use. Activate the licenses only when you

are ready to start using this unit. If your unit has never been registered before you

can use the 30 day trial period for all 3 types of licenses to perform initial testing and

configuration.

Note: Be sure the unit has Internet access before registering the licenses.

• Activate the trial licenses by selecting Support > Registration and click the

“Trial” button. Once you activate the trial licenses, you can then update the

unit with the latest UTM build and signature & engines during the 30-day trial

period.

• If you purchase a license subscription bundled with your unit, a license will

be assigned to your unit’s serial number. When you register your unit, the

license key will automatically be downloaded to your unit. Select Support >

Registration, fill out the registration page, and click “Register” to activate

the services.

Note: the 30-day trial licenses will be revoked once you activate the purchased

service license keys. The purchased service license keys offer one year or three

years of service.

For additional information on licenses see the reference manual.

Note: BesuretheunithasInternet

access before registering the

licenses.

1. Log in to the unit.

2. Select Support > Registration

to display the Registration tab.

3. Enter the customer information. If using the trial licenses, click Trial. If you

have purchased licenses, click Register. The unit will activate the licenses.

After registration is complete the unit will display the license keys and their

expiration dates.

Online Documentation and Support

Select Support > Documentation

to view the reference manual.

Select Support > Knowledge Base

to view the support page, which

includes this document and the

reference manual. Going to

http://www.netgear.com/support and

selecting your product model

number takes you to the same page.

Consult the reference manual for instructions on how to use the online support

remote diagnostics.

Technical Support

Thank you for selecting NETGEAR products.

After installing your device, locate the serial number on the label of your product and

use it to register your product at http://www.NETGEAR.com/register. Registration is

required before you can use the telephone support service. Registration via our

website is strongly recommended.

Go to http://kbserver.netgear.com for product updates and Web support.

For additional information about setting up, configuring, and using your Product

Name Only, see the User Manual.

For complete DoC please visit the NETGEAR EU Declarations of Conformity

website at: http://kb.netgear.com/app/answers/detail/a_id/11621/
