NETGEAR WN3000RPv3 Manual de usuario
Quick Start
N300 WiFi Range Extender
Model WN3000RPv3
2
Getting Started
The NETGEAR WiFi Range Extender increases the distance of a WiFi
network by boosting the existing WiFi signal and enhancing the overall
signal quality over long distances. An extender repeats the signals from an
existing WiFi router or access point.
Existing WiFi
Sometimes your router
does not provide the WiFi
coverage you need.
WiFi Range
Extender
Boosts the range of your
existing WiFi and creates
a stronger signal in
hard-to-reach areas.
3
Meet Your Extender
Before you install your extender, familiarize yourself with its LEDs,
buttons, and port.
WPS button
Power On/O
button
Factory Reset button Ethernet port
Power LED
Client
Link
LED
WPS LED
Router
Link
LED
4
LED Descriptions
Router Link LED This LED indicates the connection between the extender and
the router or access point.
Solid green. Best connection.
Solid amber. Good connection.
Solid red. Poor connection.
O. No connection.
Client Link LED This LED indicates the connection between the extender and
a computer or WiFi device.
Solid green. Best connection.
Solid amber. Good connection.
Solid red. Poor connection.
O. No connection.
Power LED Solid amber. The extender is booting.
Solid green. The extender is powered on.
O. The extender is powered o.
WPS LED Solid green. WiFi security is enabled (WPA or WPA2).
Blinking green. A WPS connection is being established.
O. WiFi security is not enabled.
5
Use the Extender in Extender Mode
In extender mode, the extender repeats the signals from an existing WiFi
router or access point. Place the extender, apply power, and connect it to
your WiFi network.
Place the Extender and Apply Power
1. Place your extender in the same room as your WiFi router.
Proximity to the WiFi router is required only during the initial setup
process.
2. Plug the extender into an electrical outlet.
Wait for the Power LED to light green.
3. If the Power LED does not light, press the Power On/Off button on
the extender.
Connect to an Existing WiFi Network
To extend the range of your WiFi network, you must connect the extender
to your existing WiFi network. You can do this in one of two ways:
• Connect with WPS. For more information, see Connect with WPS on
page 6.
• Connect with web browser setup. For more information, see
Connect with Web Browser Setup on page 8.
6
Connect with WPS
Wi-Fi Protected Setup (WPS) lets you join a secure WiFi network without
typing the network name and password.
Note: WPS does not support WEP network security. If you are using WEP
security, follow the instructions in Connect with Web Browser Setup on
page 8.
1. Press the WPS button on the side panel of the extender.
The Power LED blinks.
2. Within two minutes, press the WPS button on your router or access
point.
When the extender connects to your existing WiFi network, the WPS
LED on the extender lights solid green and the Router Link LED
lights. If the Router Link LED does not light, try again. If it still
does not light, see Connect with Web Browser Setup on page 8.
3. Unplug the extender and move it to a new location that is about
halfway between your router and the area with a poor router WiFi
signal.
7
The location that you choose must be within the range of your
existing WiFi router network.
4. Plug the extender into an electrical outlet and wait for the Power LED
to light green.
5. Use the Router Link LED on the front panel to help you choose a
spot where the extender-to-router connection is optimal.
6. If the Router Link LED doesn’t light amber or green, plug the extender
into an outlet closer to the router and try again.
Keep moving the extender to outlets closer to the router unti lthe
Router Link LED lights amber or green.
7. On your computer or WiFi device, find and connect to the new
extended WiFi network.
The extender creates a new extended WiFi network. The extender’s
new WiFi network names are based on your existing WiFi network
name, with _EXT at the end of the name.
For example:
• Existing WiFi network name. MyNetworkName
• New extended WiFi network name. MyNetworkName_EXT.
Use the same WiFi password that you use for your WiFi router.
8. Test the extended WiFi range by moving your computer or WiFi device
to the area with a poor router WiFi signal:
8
a. Leave your computer or WiFi device in the area with a poor router
WiFi signal and return to the extender.
b. Check the Client Link LED on the extender:
• If the Client Link LED is solid green or amber, your extended
WiFi network reaches the area with a poor router WiFi signal
and your network setup is complete.
• If the Client Link LED is red, your extended WiFi network
does not reach the area with a poor router WiFi signal.
You must move the computer or WiFi device closer to the
extender until the Client Link LED turns solid green or amber.
Connect with Web Browser Setup
1. Use a WiFi network manager on a computer or mobile device to find
and connect to the extender WiFi network NETGEAR_EXT.
Aer the connection with the computer or WiFi device is established,
the Client Link LED lights.
2. Launch a web browser.
3. Enter www.mywifiext.net in the address field of the browser.
The New Extender Setup page displays.
4. Click the NEW EXTENDER SETUP button.
The Create Account page displays.
9
5. Complete the fields on the page to set up your login credentials and
click the NEXT button.
6. Click the WIFI RANGE EXTENDER button.
The extender searches for WiFi networks in your area and displays a
list
7. Select a WiFi network to extend and click the NEXT button.
8. In the Password (Network Key) field, type the existing WiFi
network passphrase (also called the passphrase or security key) and
click the NEXT button.
9. Set the network name (SSID) and password for your extender and
click the NEXT button.
Wait for the page to display a list of available extended WiFi networks,
which might take up to one minute.
10. Use a WiFi network manager on the computer or WiFi device to
connect to the new extended WiFi network.
You must connect your computer or WiFi device before you click the
Continue button.
11. Click the Continue button.
A message displays confirming that the extender is connected and
ready.
12. Click the Next button.
The registration page displays.
10
13. Complete the registration fields and click the Finish button to
complete the setup.
If you do not want to register your extender, click the Skip
Registration link. Note that you must register your extender before
you can use NETGEAR telephone support.
The Status page displays.
14. Unplug the extender and move it to a new location that is about
halfway between your router and the area with a poor router WiFi
signal.
The location that you choose must be within the range of your
existing WiFi router network.
15. Plug the extender into an electrical outlet and wait for the Power LED
to light green.
16. Use the Router Link LED to help you choose a spot where the
extender-to-router connection is optimal.
17. If the Router Link LED doesn’t light amber or green, plug the extender
into an outlet closer to the router and try again.
