NETGEAR WNA3100 - Wireless-N 300 USB Adapter Manual de usuario

)NSTALLATION'UIDE

Wireless-N 300 USB Adapter WNA3100

This guide explains Express installation with the NETGEAR Smart Wizard.

Note: For help with custom installation, see the User Manual on the Resource CD.

Estimated completion time: 10 minutes.

Package Contents

Wireless-N 300 USB Adapter

USB cable with adapter cradle

Resource CD

Start Here

First, install the WNA3100 software

1. Insert the Resource CD in your computer’s CD drive. If the CD main page does not

display, browse the files on the CD and double-click Autorun.exe.

2. Click Install the Software. The Software Update Check screen displays.

3. If you are connected to the Internet, click

Check for Updates. If not, then click Install

from CD.

4. Accept the license agreement. Then click

Next on the Setup Type screen for Express

setup.

5. Follow the wizard steps to install the

software.

Then, install your WNA3100 adapter

You are prompted to insert your adapter.

1. Locate a USB port on your PC.

2. Insert the adapter into the USB port or

connect it with the USB cable (see “Using

the USB Cable” on the other side of this

guide).

Note: For best results, put the wireless

adapter at least 4 feet (1 meter) away from

your router.

3. Click Next. The WNA3100 software detects the adapter. Follow the onscreen prompts

to install the driver.

Connect to a wireless network

After the driver is installed you are prompted to connect to a wireless network:

a. If your router supports Push 'N' Connect (also called WPS), follow the steps to

push the WPS button on your adapter and connect.

b. If no WPS networks are in your area, select your wireless network from the list and

click Next. If you select a secured network, you need to enter the passphrase or

network key.

The adapter connects to the network, which can take a minute or two. The Smart Wizard

Settings screen displays. Your settings are saved in a profile, which you can name.

You are now connected to a wireless network!

The WNA3100 icon appears in the system tray and on the desktop so you can open the

Smart Wizard to make changes or connect to a different wireless network.

a: WPS-capable networks in your area b: No WPS-capable networks in your area

Profile name

This symbol was placed in accordance with the European Union Directive 2002/96 on the Waste

Electrical and Electronic Equipment (the WEEE Directive). If disposed of within the European Union,

this product should be treated and recycled in accordance with the laws of your jurisdiction implementing

the WEEE Directive.

NETGEAR, Inc. in the United States and/or other countries. Other brand and product names are trademarks or

registered trademarks of their respective holders. Information is subject to change without notice.

November 5, 2009

The Status Bar at the bottom of the Smart Wizard screen shows details about your wireless

connection.

Understanding the Status Bar

1. Wireless network Identifies which wireless network you have joined.

2. Join a Network Click Join a Network to start the Connection Wizard. You can

select a different wireless network or reconnect to your current

network, should you become disconnected.

3. Connection

status •Connected to Internet.

•Connected to Router. The adapter is connected to a router, but

the router is not connected to the Internet.

•169.254.x.x or ___.___.___.___. You are connected to a router,

but the router has a problem. See the User Manual on the

Resource CD.

4. Security • A closed lock indicates a network with wireless security.

• An open lock indicates an open network without wireless

security.

5. Channel The wireless channel used by the network. If many wireless

networks in your area use the same channel, they can interfere

with one another.

6. Data rate Wireless data rate measured in Megabits per second. To optimize

wireless data rate, connect to a network with a high-speed router

or access point and a high-speed Internet connection.

7. Signal strength More dots indicates a stronger signal. Usually, your connection

works best when the signal is strongest.

12345 67

Using the USB Cable

You can use the USB cable and adapter cradle to extend the range of your adapter and obtain

better wireless reception. Insert the adapter in the plastic cradle and attach the USB cable to

the adapter and the computer.

Technical Support

After completing the Smart Wizard configuration assistant, locate the serial number on the

bottom label of your product, and use it to register your product at

http://www.NETGEAR.com/register.

Registration on the website or over the phone is required before you can use our telephone

support service. The phone numbers for worldwide regional customer support centers are on

the Warranty and Support Information card that came with your product.

Go to http://www.netgear.com/support for product updates and Web support.
