NetComm NB16WV-02 Manual de usuario

NetCommWireless

QUICK START GUIDE

NetComm

Wireless

NB16WV-02

N600 Dual Band WiFi Gigabit

Modem Router with Voice

NetComm

Wireless

THANKS FOR PURCHASING

NETCOMM WIRELESS

This quick start guide is designed to get you up and running quickly with your new

router. More advanced set up instructions can be found in the user manual which can be

downloaded from www.netcommwireless.com

SET UP YOUR ROUTER

1. Take the supplied power adapter and attach to the Power socket on the rear of the router.

Connect to your wall socket and power on your router by ensuring the ON/OFF button on

the rear of your router is on.

2. For use with ADSL, attach the supplied phone cable to the ADSL port on the rear of your

router. Connect the other end to the phone line that supplies your ADSL Internet.

3. For use with a 3G/4G connection, attach your 3G/4G USB modem to the 3G/4G USB

port on the rear of the router.

Connecting via an Ethernet cable

1. Connect the yellow Ethernet cable provided to one of the yellow LAN ports on the back

of the NB16WV-02.

2. Connect the other end of the yellow Ethernet cable to your computer.

Computer

Connecting via WiFi

1. Ensure WiFi is enabled on your device (computer/laptop/smart phone/gaming console).

2. Scan for wireless networks in your area and connect to the network name that matches

the Wireless network name found on the Wireless Security Card (included in the box).

3. When prompted for your wireless security settings, enter the Wireless security key listed

on your Wireless Security Card (included in the box).

N600 Dual Band WiFi Gigabit Modem Router with Voice- NB16WV-02

CONNECTING THE ROUTER TO THE INTERNET

1. After establishing a connection using the previous steps, open your Web browser and

type http://192.168.20.1 into the address bar at the top of the web browser window and

press Enter.

2. Enter admin into both the username and password elds and click Login.

3. The First-Time Setup Wizard should then be displayed. Click on the Yes, Let’s get

started with the wizard button to congure you NetComm Router.

4. Select your chosen connection type. You can select from:

- ADSL, Mobile Broadband, WAN

ADSL:

Select the ADSL connection type and enter the

username/password as supplied by your ADSL

provider

Note: To enable a backup connection via 3G, tick the checkbox and then

enter the appropriate 3G connection information. This information

should be supplied by your 3G provider. You will also need to enter a

high availability website (e.g. – www.google.com) in order to verify if

your ADSL based internet connection is currently active.

Mobile Broadband:

Select the APN from the dropdown box (enter your username/password if required) as

supplied by your Mobile Broadband provider.

WAN:

Select the Ethernet WAN type and enter details as supplied by your internet Service provider.

After selecting the appropriate connection type and entering the required details, click Next.

5. Select to enable or disable your wireless network, show or hide your wireless network

(Hide SSID) or change the wireless network name (SSID). After making the appropriate

changes, click Next. (If you do not want to change the default settings, simply click Next)

6. Select the wireless security and wireless security key you would like to use on your

wireless network and click Next. (If you do not want to change the default settings, simply

click Next)

7. Repeat the steps above for the 5GHz WiFi setup

8. Enter the username and password you would like to use when logging into the web based

user interface. Conrm the new password by entering it in a second time in the Retype

Password eld and Click Next. (If you do not want to change the default settings, simply

click Next)

9. Review your selected settings and click Finish. If you would like to change any of

the settings, click Back until you reach the required page and adjust your settings

accordingly. Click Next until you reach the summary page again.

The NetComm Wireless Router will now attempt to connect using the details you have

entered. This can take up to 2 minutes. If the connection attempt was successful, the

Internet Connection LED on the front of the unit will then be lit.

NetComm

Wireless

QSG-00033 NB16WV-02 rev 2

WORKS WELL WITH NETCOMM POWERLINE

Powerline Adapters with AC Passthrough Wireless Powerline Kit

NP504 NP206

Stream Music, Movies & Photos, Browse, Socialise & Play Online with Powerline

List of Mobile Broadband Service Providers

MOBILE SERVICE APN

Australia

Telstra Telstra.internet

Telstra.pcpack

Telstra.datapack

Telstra.extranet

Optus – Postpaid connect

Optus – Prepaid preconnect

Three – Postpaid 3netaccess

Three – Prepaid 3services

Vodafone – Postpaid vnternet.au

Vodafone – Prepaid vfprepaymbb

Crazy John’s purtona.net

DoDo dodolns1

Blink splns888a1

Internode internode

Primus primuslns1

TPG internet

Exetel Exetel1

Westnet Splns555a1

iiNet iiNet

New Zealand

Vodafone NZ www.vodafone.net.nz

CallPlus www.callplus.net.nz

Slingshot www.slingshot.net.nz

Telstra Clear www.telstraclear.net.nz

Telecom NZ XT internet.telecom.co.nz

• No new wiring necessary

• Plug and play

• Reliable connection

• Perfect for devices that are not mobile –

gaming consoles, IPTV, media players etc
