NetComm 3G27WV-02 Manual de usuario

21Mbps Mobile Broadband Router with Voice – 3G27WV-02

NetCommWireless

21Mbps Mobile Broadband

Router with Voice

QUICK START GUIDE

NetComm

Wireless

3G27WV-02

NetComm

Wireless

THANKS FOR PURCHASING

NETCOMM WIRELESS

This quick start guide is designed to get you up and running quickly with

your new router. More advanced set up instructions can be found in the user

manual which can be downloaded from www.netcommwireless.com

Hardware setup

1. Insert your activated SIM card (until you hear a click) into the SIM slot.

2. Attach the supplied antenna to the connector labeled Antenna on the

rear panel.

3. Connect the power adapter to the power socket on the back of

the router.

4. Plug the power adapter into the wall and power on.

5. Wait approximately 60 seconds for the router to power up.

Connecting to the router - via cable

6. Connect the supplied yellow Ethernet cable to the LAN port at the back

of the router.

7. Connect the other end of the yellow Ethernet cable to your computer.

8. Wait approximately 30 seconds for the connection to establish.

21Mbps Mobile Broadband Router with Voice – 3G27WV-02

Power Adapter Wall Socket

SIM Card

Computer

NetComm

Wireless

Connecting to the router - wirelessly

1. Ensure wireless networking is enabled on your device (computer/laptop/

tablet/smartphone etc.).

2. Scan for wireless networks and connect to the network name that

matches the Wireless Network Name found on the wireless security card

(included in the box).

Wireless Security Card

Wireless Network Name (SSID) Wireless Security Key

3. When prompted for your wireless security password, enter the Wireless

Security Key listed on your Wireless Security Card.

4. Wait approximately 30 seconds for the connection to establish.

5. To connect additional devices, repeat steps 1-4.

21Mbps Mobile Broadband Router with Voice – 3G27WV-02

Connecting to the Internet

Your 3G/4G connection should automatically congure and connect you to

your 3G/4G service. In the event it doesn’t, please follow these steps:

1. After establishing your connection to the router, open your Web browser

and type http://my.router or http://192.168.20.1 into the address bar at

the top of the web browser window and press enter.

2. At the login screen, type admin into both the Username and the

Password elds and click OK.

3. Click switch to advanced view at the bottom of the page to navigate to

the Advance setting page.

4. Hover your mouse over the Internet Settings menu at the top of the web

browser window and click on WWAN.

NetComm

Wireless

5. Select disable from the Auto-APN drop down menu.

6. Enter the 3G/4G service details as supplied by your 3G/4G service

provider. This may include the APN, username / password, or dialled

number. Leave any elds which are not required blank.

7. Once the correct details are entered, click the Save button.

8. The router will now attempt to connect using the details you have entered.

This can take up to 2 minutes.

9. If you are successfully connected the blue 3G/4G light on the front of the

unit will be lit.

Making and receiving voice calls

Your router allows you to make voice calls over the cellular wireless network.

1. Ensure your SIM card is activated on a plan that supports both data and

voice (Internet and Phone) service for your router.

2. Plug a standard home phone into the Line 1 or Line 2 phone port on the

back of the device.

The corresponding Phone light on the front edge of the router will turn on and

you will be able to hear a dial tone on your phone.

When an incoming call is received, both Line 1 and Line 2 lights will start

ashing and the phone(s) connected to the router will ring.

If the call is answered from the phone connected to Line 1, the phone

connected to Line 2 will receive an engaged tone for the duration of the call.

Note: In the event of a power outage, voice services will not function.

21Mbps Mobile Broadband Router with Voice – 3G27WV-02

Calling features

CALLING FEATURE USAGE ACT

CODE

DE-ACT

CODE

Access Voice Mail Access Voice Mail Standard

wireless

*98

Call Display - Blocking

per call

#31#

Call Forwarding All Calls *21* [ten

digit phone

number]#

#21#

Call Waiting *43# #43#

Answering Call Waiting Hook Flash

To switch between calls Hook Flash

Directory Assistance Dial 411

Emergency Call Dial 911

Collect Calls Collect calls cannot be received

on your phone. However you can

make an outgoing collect call.

Roaming The router will function only when

you are in range of your chosen

carrier

Advanced conguration (optional)

3. For advanced conguration, open your web browser (e.g. Firefox,

Chrome, Internet Explorer, Safari)

4. Enter the address of your router (Default: http://192.168.1.1/)

5. When prompted for your Username and Password enter:

Username: admin

Password: admin

NetComm

Wireless

MERCI D’AVOIR ACHETÉ UN PRODUIT

NETCOMM WIRELESS

Ce guide de démarrage rapide est conçu pour vous aider à congurer

rapidement votre routeur. Des consignes d’installation plus avancées sont

présentées dans le guide de l’utilisateur qui peut être téléchargé au

www.netcommwireless.com

Conguration de matériel

1. Insérez la carte SIM activé dans la fente pour carte SIM (jusqu’à ce que

vous entendiez un clic).

2. Fixez l’antenne fournie au connecteur « Antenne » à l’arrière du panneau.

3. Connectez l’adaptateur de courant à la prise à l’arrière de la Centrale

sans-l.

4. Branchez l’adaptateur de courant dans la prise murale et allumez le

dispositif.

5. Patientez environ 60 secondes pour l’allumage de la Centrale sans-l.

Connexion router au moyen d’un câble

6. Connectez le câble Ethernet jaune de l’appareil à l’un des ports de

réseau local à l’arrière de la Centrale sans-l.

7. Connectez l’autre bout du câble Ethernet jaune à votre ordinateur.

8. Patientez environ 30 secondes pour l’établissement de la connexion.

21Mbps Mobile Broadband Router with Voice – 3G27WV-02

Adaptateur

de courant

Prise murale

Carte SIM

Ordinateur

NetComm

Wireless

Établissement d’une connexion router sans l

1. Assurez-vous que la fonction de réseau sans-l est activée sur votre

appareil (ordinateur de bureau, ordinateur portable, tablette, téléphone

intelligent, etc.).

2. Recherchez des réseaux sans-l et établissez une connexion au réseau

sans-l dont le nom correspond à celui qui se trouve sur la carte de

sécurité sans-l (incluse dans la boîte).

Wireless Security Card

Wireless Network Name (SSID) Wireless Security Key

3. Lorsqu’on vous demandera votre mot de passe de sécurité sans-l,

entrez la clé indiquée sur votre carte.

4. Patientez environ 30 secondes pour l’établissement de la connexion.

5. Pour brancher d’autres appareils, répétez les étapes 1 à 4.
