Mobile Oil Radiator
Article number: HTOI30WT7 / HTOI30WT9 / HTOI30WT11
Nedis BV
De Tweeling 28, 5215 MC ’s-Hertogenbosch, The Netherlands 04/22
Preface
Thank you for purchasing the Nedis HTOI30WT7 / HTOI30WT9 / HTOI30WT11.
This document is the user manual and contains all the information for correct, ecient and
safe use of the product.
This user manual is addressed to the end user. Read this information carefully before
installing or using the product.
Always store this information with the product for use in the future.
Product description
Intended use
The Nedis HTOI30WT7 / HTOI30WT9 / HTOI30WT11 is a heater that allows the user to
control the surrounding temperature.
The built-in thermostat measures the room temperature and automatically switches off the
product when the desired room temperature is reached. When the room temperature
decreases below the desired temperature, the product switches back on automatically.
The product has three heating modes to control the heating power.
The product is intended for indoor use only.
Any modication of the product may have consequences for safety, warranty and proper
functioning.
This product can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the product in a safe way and
User manual EN
understand the hazards involved. Children shall not play with the product. Cleaning and
user maintenance shall not be done by children without supervision.
Children of less than 3 years should be kept away.
This product is intended for use in household environments for typical housekeeping
functions that may also be used by non-expert users for typical housekeeping functions,
such as: shops, oces other similar working environments, farm houses, by clients in
hotels, motels and other residential type environments and/or in bed and breakfast type
environments.
The product is not intended for professional use.
This product is only suitable for well insulated spaces or occasional use.
Specications
Product Mobile Oil Radiator
Article number HTOI30WT7 HTOI30WT9 HTOI30WT11
Dimensions (l x w x
h)
310 x 240 x 620
mm
390 x 240 x 620
mm
440 x 240 x 650
mm
Weight 5.4 kg 6.4 kg 7.7 kg
Input power 220 - 240 V~; 50 - 60 Hz
Heating power
range 600 - 1000 W 900 - 1500 W 1500 - 2500 W
Information requirement for the electric local space heaters
Model identier(s): HTOI30WT7 / HTOI30WT9 / HTOI30WT11
Item Symbol Value Unit Item Unit
Heat output
Type of heat input, for electric
storage local space heaters only
(select one)
Nominal heat Pnom 1.5 / 2.0 / 2.5 kW manual heat charge No
User manual EN
output control, with integrated
thermostat
Minimum heat
output
(indicative)
Pmin 0.6 / 0.9 / 1.5 kW
manual heat charge
control with room and/or
outdoor temperature
feedback
No
Maximum
continuous heat
output
Pmax,
c1.5 / 2.0 / 2.5 kW
electronic heat charge
control with room and/or
outdoor temperature
feedback
No
Auxiliary electricity consumption fan assisted heat output No
At nominal heat
output elmax N/A kW Type of heat output/room
temperature control (select one)
At minimum
heat output elmin N/A kW
single stage heat output
and no room temperature
control
No
In standby
mode elSB 0 kW
two or more manual
stages, no room
temperature control
No
with mechanic thermostat
room temperature control Yes
with electronic room
temperature control No
electronic room
temperature control plus
day timer
No
electronic room
temperature control plus
week timer
No
Other control options (multiple
selections possible)
User manual EN
room temperature control,
with presence detection
No
room temperature control,
with open window
detection
No
with distance control
option No
with adaptive start control No
with working time
limitation No
with black bulb sensor No
Contact details Nedis BV, De Tweeling 28, 5215 MC ’s-Hertogenbosch, The
Netherlands
Main parts (image A)
User manual EN
* HTOI30WT7 only.
Control panel (image B)
Safety instructions
WARNING
• Ensure you have fully read and understood the instructions in this document before
you install or use the product. Keep the packaging and this document for future
reference.
• Only use the product as described in this document.
• Misuse of this product can result in serious injury.
• Do not use the product if a part is damaged or defective. Replace a damaged or
defective product immediately.
• Do not use the product if the surface is cracked.
• Do not drop the product and avoid bumping.
• This product may only be serviced by a qualied technician for maintenance to reduce
the risk of electric shock.
B
1Power dial
2Thermostat dial
3Power indicator LED
User manual EN
• Do not plug the product in a power outlet of a power group with other products that
consume a lot of power.
• Do not plug the product in a power outlet with a current of less than 10 A.
• This product may not be used by persons (including children) whose physical, sensory
or mental capabilities or lack of experience and knowledge prevents them from using
the product safely without supervision or instruction.
• Children should be supervised to ensure that they do not play with the product.
• Do not expose the product to water or moisture.
• Do not use the product where splashing of water might occur, e.g. bathroom,
swimming pool or close to a washbowl.
•Do not use the product in a room with an area smaller than 5 m2.
• Keep the product at a minimum distance of 1 m away from ammable or combustible
materials.
• Before use, always check that the mains voltage is the same as the voltage on the
rating plate of the product.
• Do not use an extension cord or power strip, which could overheat and result in a re.
• Only plug the cable into a wall outlet. Do not use extension cords.
• Unplug the product from the power source if problems occur.
• Unplug the product and set dials to zero when not in use and before cleaning.
• Do not unplug the product by pulling on the cable. Always grasp the plug and pull.
• Do not use external timers or remote control systems to switch the product on or off.
• Do not plug the product in a power outlet of a power group with other products that
consume a lot of power.
• Do not locate the product immediately below a power outlet.
• Do not cover the power cable by e.g. carpets, rugs or furniture.
• Do not let the power cable hang over the edge of a table or counter, or touch hot
surfaces.
• Do not leave the product unattended when the product is connected to the power
outlet.
• Disconnect the product from the power source before service and when replacing
parts.
• If the power cable is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualied persons in order to avoid a hazard.
• The surfaces of the product get hot during use. Only touch the handles of the product
to avoid burns.
• Do not use the product outdoors, the product is designed for indoor use.
• To avoid overheating, do not cover the product.
• Only use the product in a well-ventilated area.
• Do not block the air in- and outlets of the product.
• Do not allow this product to come in contact with curtains, wall coverings, clothing,
User manual EN
dishtowels or other ammable materials during use.
• Do not use the product in rooms where ammable liquids or gases are used or stored.
• Do not try to open or repair the product, controller or cable. It must be serviced by a
qualied technician.
• Dispose of the oil separate from the product. Check the local rules and regulations for
the correct disposal instructions.
• Do not use the product when it is leaking oil.
• Only use the product in the upright position.
• Do not move the product during operation.
Explanation of the safety symbols on the product
Icon Description
Indication to explain that the product contains a substance that is
fatal or toxic if swallowed, inhaled or in contact with skin.
Installation
Check the contents of the package
Check that all parts are present and that no damage is visible on the parts. If parts are
missing or damaged, contact the Nedis B.V. service desk via the website: www.nedis.com.
Assembling the product (image C)
User manual EN
1. Remove all packaging.
2. Carefully place A2 upside down on a soft surface.
3. Place the U-shaped bolt A8 between the rst and second n behind the front cover.
4. Place the hook of A8 through the slot on the castor mounting plate A3.
5. Place the thread A8 through the other slot on A3.
6. Screw the wing nut A9 on A8.
Do not overtighten the bolts. This will damage the product.
7. Place the castor wheel A6 in the hole of A3.
8. Screw the cap nut A5 on A6.
Repeat steps 3 - 10 for A3 between the last two ns on the other side of the product.
4
The HTOI30WT7 has a U-shaped castor mounting plate A4.
Place A4 between the rst and second n behind the front cover.
Point the ends of A4 to A1.
Installing the product
1. Place the product on a stable and at surface.
2. Turn the power dial B1 and the thermostat dial B2 to the
0
and
MIN
position.
3. Connect the power plug A7 into a power outlet.
C
User manual EN
Use
Using the product
1. Rotate the thermostat dial B2 to the
MAX
position.
2. Rotate the power dial B1 to the desired mode:
Mode HTOI30WT7 HTOI30WT9 HTOI30WT11
I600 W 900 W 1500 W
II 800 W 1200 W 2000 W
III 1000 W 1500 W 2500 W
3. When the room has reached the desired temperature, rotate B2 counter-clockwise
until the indicator light switches off. The thermostat is now set to the current room
temperature.
• When the room temperature reaches the selected level, the built-in thermostat
automatically switches off the product.
• When the room temperature decreases, the built-in thermostat automatically switches
the product back on.
4. Rotate B2 to adjust the desired room temperature.
4
The product might make some noise when it is used for the rst time or after a long
period when the product was not used. This is normal and does not affect the safety
of the product.
Switching off the product
1. Rotate B1 to the
0
position.
2. Unplug A7 from the power outlet.
3. Allow the product to cool down.
Maintenance
Cleaning the product
1. Before cleaning and maintenance, switch off the product and disconnect the power.
User manual EN
Otros manuales para HTOI30WT7
1
Este manual sirve para los siguientes modelos
2
Tabla de contenidos
Otros manuales de Calentador de nedis
nedis
nedis HTIF10FYW Manual de usuario
nedis
nedis HTFA10GWT Manual de usuario
nedis
nedis HTPA20EBK Manual de usuario
nedis
nedis HTBA20WT Manual de usuario
nedis
nedis HTCO50FWT Manual de usuario
nedis
nedis HTFA20WTW Manual de usuario
nedis
nedis WIFIHTPL20FWT Manual de usuario
nedis
nedis HTOI30WT7 Manual de usuario
nedis
nedis HTIF20FYW Manual de usuario
nedis
nedis HTFA14CWT Manual de usuario
nedis
nedis HTFA13CWT Manual de usuario
nedis
nedis 5412810314706 Manual de usuario
nedis
nedis NE-HMH002/W Manual de usuario
nedis
nedis HTIF20FYW Manual de usuario
nedis
nedis HTFA11CWT Manual de usuario
nedis
nedis HTFA10CWT Manual de usuario
nedis
nedis HTFA22WTW Manual de usuario
nedis
nedis HTIF30FYW Manual de usuario
nedis
nedis Subheader Manual de usuario
nedis
nedis PEFW110CGY Manual de usuario
Manuales populares de Calentador de otras marcas
Empire Heating Systems
Empire Heating Systems WCC65 Manual de usuario
Wetekom
Wetekom 92 86 43 Manual de usuario
Desa
Desa SPC170-F Manual de usuario
Watlow
Watlow Watrod Electric Tubular Heaters Manual de usuario
Haverland
Haverland ECO-DRY GPS Series Manual de lista de piezas
Stelpro
Stelpro ASILVC2060 Series Manual de usuario
