Nectre Fireplaces 2000 Instrucciones de funcionamiento

NECTRE 2000

FREESTANDING SPACE HEATER

SERVICE INSTRUCTIONS

REV 2

Do not modify this appliance.

Freestanding gas appliance

Natural gas only.

Approval no.AGA 5954G

Warning –Servicing shall be carried out only by authorized personnel.

WARNING

The Nectre 2000 space heater has a primary safety glass fitted in front of the glass door. This safety

glass is fitted to this appliance to reduce the risk of injury from burns and at no time should this glass

be permanently removed.

For protection of young children or the infirm, a secondary guard is required.

The appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

IMPORTANT SAFETY NOTICE

◼DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE.

◼DO NOT USE OR STORE FLAMMABLE MATERIALS IN OR NEAR THIS APPLIANCE.

◼DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILST IT IS IN OPERATION.

◼CARE MUST BE TAKEN TO ENSURE THAT ANY RETURN AIR REGISTER OR EXHAUST SYSTEM DOES NOT ADVERSLEY

AFFECT THE OPERATION OF THE APPLIANCE OR DRAUGHT OF CHIMNEY OR FLUE.

◼DO NOT MODIFY THIS APPLIANCE.

◼APPLIANCE IS DESIGNED TO OPERATE WITH LUMINOUS FLAMES. MAY EXHIBIT SLIGHT CARBON DEPOSIT.

◼NOTE: A slight smell may be apparent for the first few hours of use. This is due to the heat resistant

paint curing. It is recommended to open windows in the room for the first lighting of the fire. In some

instances, a slight discolouration may occur inside the firebox. This is a normal condition and is not

covered by warranty.

◼APPLIANCE IS DESIGNED TO OPERATE WITH LUMINOS FLAMES.

MAY EXIBIT SLIGHT CARBON DEPOSIT.

SERVICING

It is recommended you service your gas fire every 2 years as a minimum.

CORD REPLACEMENT

Electrical cord replacement must be undertaken by qualified and trained personnel only.

VENTILLATION REQUIREMENTS

Permanent ventilation of the room where the fire is to be situated is essential while fire is in operation. The

room must have a minimum cross-sectional area of 40,000sq mm of effective ventilation.

INSTALLATION NOTICE

◼The installation of this appliance is only to be carried out by an authorised person in accordance

with the Manufacturer’s Instructions, local gas fitting regulations, AS/NZS5601.1-2013installation code

for gas burning appliances and any other relevant statutory regulations.

◼In all cases the installation of this appliance shall meet the requirements as set out in

AS/NZS5601.1-2013.

◼Do not install in a fireplace as a Type 1 installation.

◼Not intended as a fireplace insert.


3

CONTENTS
DATA PLATE......................................................................................................................................... 4
DIMENSIONS........................................................................................................................................ 4
INSTALLATION CODES................................................................................................................... 5
FLUE SIZES AND COWLS .............................................................................................................. 5
FLUE TERMINATION LOCATION ............................................................................................... 5
SEQUENCE OF OPERATION......................................................................................................... 6
FAULT GUIDE ...................................................................................................................................... 7
MEDIA INSTALLATION ................................................................................................................... 9
COMMISSIONING PROCEDURE................................................................................................ 10
BURNER PRESSURE ADJUSTMENT ...................................................................................... 11
IGNITION ADJUSTMENTS (SPARK GAPS) ........................................................................ 12
AERATION ADJUSTMENTS ........................................................................................................ 12
DOOR GLASS & GLASS SEAL REPLACEMENT................................................................. 13
DOOR REMOVAL & REPLACEMENT....................................................................................... 13
GAS VALVE REMOVAL.................................................................................................................. 13
BURNER................................................................................................................................................ 14
ROOM AIR FAN REPLACEMENT............................................................................................... 14
HEAT EXCHANGER CLEANING ................................................................................................ 14
WIRING DIAGRAM ........................................................................................................................... 15
CONVERSION DETAILS ................................................................................................................ 15
PARTS LIST ........................................................................................................................................ 16

 .

DATA PLATE

Natural Gas Jet 2.95mm High TPP .52Kpa Consumption 28Mj/h

Low TPP .30Kpa Consumption 20Mj/h

Working pressure required to operate appliance

Natural Gas 1.13Kpa- 5.00Kpa

Installation must meet Australian gas codes AS/NZS 5601.1-2013.

DIMENSIONS

INSTALLATION CLEARANCES-

clearances from combustible materials

GAS CONNECTION –15mm (1/2”) Compression union.

Rear 75mm

Sides 75mm

Minimum flue length 3.6 m

ELECTRICAL CONNECTION –3 Pin 10Amp GPO plug

POWER RATING OF APPLIANCE- 230V 50Hz 0.55Amp

INSTALLATION CODES

•Note appliance gas type –Natural gas only available.

•Installers –Please ensure the installation and instruction manuals supplied with this appliance

are supplied to the customer and the customer is trained on how to operate the appliance

correctly.

•Do not modify the appliance.

•Do not exceed maximum rated pressures.

•Appliance must be installed as per gas installation code (AS/NZS 5601.1-2013) and applicable

electrical installation code (AS3000).

•Test for gas leaks prior to operating appliance.

•Check gas pressures and adjust if incorrect.

WARNING - Transit material such as cardboard packaging, pallet, plastic wrap, glass

packaging warning labels and burner media protection must be removed prior to use.

FLUE SIZES AND COWLS

The appliance must be fitted with an approved cowl.

Minimum flue length 3.6 m

Flue size ∅100mm.

FLUE TERMINATION LOCATION

SEQUENCE OF OPERATION

Turning the heater ON

1. Check that the gas and electricity is turned on.

2. Open the fold down control panel in the front of the pedestal.

(The glass door is fixed and does not open).

There are three switches to operate the fire:

𝑶𝑭𝑭

𝑶𝑵 𝑭𝑨𝑵 𝑯𝑰𝑮𝑯

𝑭𝑨𝑵 𝑳𝑶𝑾 𝑭𝑰𝑹𝑬 𝑯𝑰𝑮𝑯

𝑭𝑰𝑹𝑬 𝑳𝑶𝑾

3. Always start the fire with the fire set on HIGH (RH switch up), and the fan on LOW (Middle switch down).

4. Turn the ON/OFF switch to ON.

•The controller will automatically turn on the gas and spark at the rear of the burner. After

a few seconds the gas will ignite.

•If no flame is detected the gas is automatically turned off. If this happens, the heater is

reset by simply turning the ON/OFF switch to OFF, wait 30 seconds, and then turn ON

again.

•The burner of the fire will light with a soft blue flame. You may see some moisture

appearing on the inside of the heater glass. This will disappear after about a minute as

the heater warms up. Leave the fire on HIGH and after about ten minutes the top of the

flames will become more orange like a real log fire.

5. The fan may be set on high or low at any time according to personnel taste after the heater has

warmed up.

6. If the room becomes too hot, the fire can be turned down simply by pressing the right-hand Fire

Low Switch.

Turning the heater OFF

To turn the heater off simply press the left hand switch to OFF and the burner and fan will both be turned

off.

FAULT GUIDE

FAULT

CAUSE

REMEDY

Igniter Sparks but

no Ignition

No Gas

Check supply

Purge lines.

Igniter does not

spark and fan does

not run

Electricity not ON

Fuse blown

Fault in wiring

Check electricity supply.

Replace fuse (check why

fuse blew).

Check wiring.

Igniter does not

sparks but fan runs

Spark rod at rear of burner

shorting

Poor Earth connection

Faulty spark cable

Spark cable disconnected

Clean insulator or

replace if damaged.

Check connection

between burner and

body and earth

connections between

control unit and body.

Replace

Reconnect.

Igniter sparks but

no ignition

No gas

Air in line

Check supply.

Purge gas line.

Note: reset igniter by

turning on/off switch off

and on again.

Gas ignites but

goes out

immediately

Flame sensor not in flame.

Flame sensor wire faulty or

disconnected.

Power point faulty (Active and

Neutral swapped)

Bend flame sensor rod

above gas port.

Reconnect or replace

wire.

Use extension cord to try

a different power point.

Gas ignites but

goes out after a

few moments.

Gas pressure too low.

Unit cold.

Adjust gas pressure high

and low.

Attempt to relight the

fire after waiting 30

seconds.

Flame abnormality

Incorrect pressure

Dirt in jet or burner.

Log arrangement incorrect.

Check gas pressure high

and low.

Clean jet and burner.

Check log and ember

effect against

instructions.

MEDIA INSTALLATION

•Media must be setup as per instructions.

•The media is designed and shaped to correctly locate and remain in the correct position.

•Do not add extra media, or combine media types.

•Only the approved supplied media is to be used.

•Do not use any other media than as supplied and recommended by the manufacturer. Use of

other media may result in explosive media which may cause injury or damage.

Fitting of the ceramic “log” set, Natural Gas model

•Open the fire box front door of the unit by removing the locking screw at the base of the main

handle.

•Remove the inside glass by loosening the two screws of the left hand glass retainer bracket.

Remove the two screws and right hand glass retainer bracket. Slide glass to the right a little,

then out. Note: Take care not to chip edge of glass and be careful of sharp edges.

•Unpack the log set and ember wool. There should be 3 Ceramic “logs” and a small bag of fibre

wool. The base board should be sitting on top of the burner.

•Place the large flat rear log (3) with its cross hatched surface to the front on the two supports at

the back of the burner leaning against the rear of the firebox.

•Place the right hand lower log (5) on to its two location studs and the Y shaped left lower log (4)

on to its locating studs.

•Place pieces of ember wool in the two cut outs of the base board and on top of visible parts of

the base bard. Do not place ember wool over the slotted main burner ports.

•Do not fit any other logs or coals.

•Wash hands after handling coals and/or logs and ensure children do not handle them as the

colouring may contain toxic dies.

COMMISSIONING PROCEDURE

•Once the fire is installed.

•Install media.

•Refit doors/ glass.

•Connect to gas and power.

•Fit firebox door.

•Check for gas leaks.

•Carry out the lighting procedure.

•Check burner pressures and inlet supply pressure (Valve is non adjustable).

•Check appliance for combustion (CO) leakage.

•Turn off.

•Handover instructions to owner.

•Instruct owner on how to operate the fireplace safely.

•Instruct owner how to isolate the appliance in an emergency.
