NEC MultiSync LCD1700M+ Manual de usuario

English

1700e.p65 01/02/28, 17:40Page 9 AdobePageMaker6.5J/Win

ﾌﾞﾗｯｸ

1700e.p65 01/02/28, 17:40Page 10 AdobePageMaker6.5J/Win

ﾌﾞﾗｯｸ

Contents

Your new NEC MultiSync monitor box* should contain the following:

– MultiSync LCD1700M+ Monitor.

– Power Cords.

– Audio Cable.

– User’s Manual.

– Installation Disk.**

* Remember to save your original box and packing material to transport

or ship the monitor.

** This diskette contains the Windows 95/98 INF file. This enables easy

and correct configuration of the monitor witn this operating system.

To use the INF file, double-click on the display icon in the control

panel, select the settings tab and follow the instructions to change the

monitor type.

Contents E - 1

MultiSync LCD1700M+ Monitor

Power Cords

Audio Cable

1700e.p65 01/02/28, 17:40Page 11 AdobePageMaker6.5J/Win

ﾌﾞﾗｯｸ

Hardware Installation

To attach the MultiSync monitor to your system, follow these instruc-

tions:

1. Make sure that the computer and monitor’s power are both turned

off. Please follow the steps to install your LCD monitor.

a. Place monitor face down on a non-abrasive surface. Take off

the rear cover, then the base cover.

b. Connect the power cord to your LCD monitor. Then connect

the audio cable into the Audio Input of the monitor. Reattach

base cover.

c. Put rear cover back.

d. Plug the 15-pin Mini D-SUB cable into the signal connector

of the computer.

E - 2 Hardware Installation

Bundle cables here.

1700e.p65 01/02/28, 17:40Page 12 AdobePageMaker6.5J/Win

ﾌﾞﾗｯｸ

2. Connect the power cord at the back of the monitor to an AC

power socket.

Please make sure, that the socket is not blocked or covered, so

you can disconnect the unit from AC supply if you need to. Your

monitor is equipped with an automatic power supply for a volt-

age range from 100 to 240 Volt at a frequency of 50 to 60 Hz.

Be sure that your local power is within the supported range. If

you are unsure, ask your electricity supplier.

Hardware Installation E - 3

1700e.p65 01/02/28, 17:40Page 13 AdobePageMaker6.5J/Win

ﾌﾞﾗｯｸ

E - 4 Software Installation

Software Installation

Choosing the best resolution

Due to the technology of a LCD monitor, it always provides a fixed reso-

lution. For this monitor, it is a resolution of 1280x1024. This is called the

native resolution, which also represents the maximum resolution. Lower

resolutions are displayed on a full screen through an interpolation circuit.

Flaws do occur with the interpolated resolution compared to the native

resolution. If you want to have all the advantages of LCD technology you

must use the native resolution. Using Windows 95/98/2000 you can change

the resolution as follows:

1. Double-click the “Display”icon in the control panel.

2. From the “Display properties”window, select the “Settings”tab.

There is a slider on the right-hand side in the middle of the win-

dow. There you can alter the resolution.

3. Set a resolution of 1280x1024.

4. In the subsequent window press: “Apply”, “OK”and “Yes”.

5. You can now close “Display Properties”.

Refresh Rate Selection

There is no need to choose the highest possible refresh rate on a LCD

monitor. It is not technically possible for a LCD display to flicker. Even

at a refresh rate of 60 Hz you will get an absolutely flicker-free image.

More important is that you make sure that you use one of the factory

modes. In contrast to a modern CRT monitor, which is a multi-scan moni-

tor, this model is a multi-frequency monitor. This means, the best results

are only obtained by using the factory modes. You will find a table with

the factory modes in this user guide. For the native resolution of

1280x1024, these, for example, are 60, 70 and 75 Hz, not 72 Hz. In Win-

dows 95/98/2000 you can change the refresh rate as follows:

1. Double click the “Display”icon in the control panel.

2. From the “Display properties”window, select the “Settings”tab.

Click the “Advanced properties”button in the bottom right cor-

ner.

1700e.p65 01/02/28, 17:40Page 14 AdobePageMaker6.5J/Win

ﾌﾞﾗｯｸ

3. Select the “Adapter”tab. The refresh rate selection field is lo-

cated in the center at the bottom of the window.

4. Choose a refresh rate from the table with the factory modes,

which can be found in the user’s guide, and select this in the

settings field.

5. In the subsequent window press: “Apply”, “OK”and “Yes”.

6. You can now close “Display Properties”.

Software Installation E - 5

1700e.p65 01/02/28, 17:40Page 15 AdobePageMaker6.5J/Win

ﾌﾞﾗｯｸ

E - 6 Adjusting the Monitor

Adjusting the Monitor

There are 4 keys & one wheel for user’s control that includes Power,

Auto, Exit, Enter and a wheel. The following descriptions are the intro-

duction of these keys & fly wheel.

1. Power: Turn the power on or off.

2. Auto: Adjust vertical position, phase, horizontal position and

pixel clock automatically.

3. Exit: Back to main menus ; Entering “save menu”; Exit OSD

menu without saving. Hot key for Audio volume adjustment.

4. Enter: Enter main/sub menus ; select items ; save menu.

5. Fly-wheel: Left/right adjustment. Hot key for Brightness/Con-

trast adjustment.

Power Indicator

Power

Auto

Fly-wheel

Exit Enter

1700e.p65 01/02/28, 17:40Page 16 AdobePageMaker6.5J/Win

ﾌﾞﾗｯｸ

Adjusting the Monitor E - 7

Adjustable Items

Luminance

Contrast

Adjusts the contrast.

Brightness

Adjusts the brightness.

Geometry

Hor. Position

Adjusts a displaying position in horizontal direction.

Ver. Position

Adjusts a displaying position in vertical direction.

Phase

Adjusts a phase when horizontal noise is displayed on the

screen. Also used when characters are blurred or not sharply

displayed.

Pixel Clock

Expands or contracts the screen.

Color Adjustment

(9300K)

Selects the pre-set colour (9300K).

(6500K)

Selects the pre-set colour (6500K).

(5800K)

Selects the pre-set colour (5800K).

(User)

Adjusts the colour proportion for red, green and blue.

1700e.p65 01/02/28, 17:40Page 17 AdobePageMaker6.5J/Win

ﾌﾞﾗｯｸ

E - 8 Adjusting the Monitor

Recall (Display Mode)

Displays information about the input signal.

Returns a currently displayed set value for signal to factory

set one when Enter key is pressed.

(Only values adjusted at Geometry can be returned to fac-

tory set ones.)

Miscellaneous

OSD Position

Adjusts an OSD menu position.

Language Select

Switches the current language displayed on OSD menu into

another.

OSD Time

Set a time in which OSD menu disappears automatically.

Zoom

Selects whether or not display is expanded to 1280 x 1024.

Volume

Adjusts the speaker volume.

SN (Serial Number)

Displays the serial number of this liquid crystal display

(LCD).

1700e.p65 01/02/28, 17:40Page 18 AdobePageMaker6.5J/Win

ﾌﾞﾗｯｸ
