NEC MultiSync LCD1525S Manual

To begin the setup/adjustment of the NEC MultiSync LCD

1525S

monitor,

push any of the CONTROL buttons on the front bezel of the monitor

to bring up the NEC

On Screen Manager

.

Press the right arrow to highlight the „AUTO‰ tab and to select the

„AUTO

ADJUST‰ menu in green.

Press the š„PROCEED‰ button to initiate the

Auto Adjust

Function

(This function will take a few seconds to be completed).

Press EXIT to close the OSM



menu.

NEC Technologies, Inc. MultiSync



LCD1525S





Setup instructions for Windows



95/98 & NT Computers

For Optimal Performance

the MultiSync LCD

1525S

should be set up for

1280x1024 @ 60Hz.

Once you have booted up your computer and have entered Windows, please follow the instructions below

to fully optimize your MultiSync LCD monitor.

Step 1 Auto Adjust your MultiSync LCD monitor.

(Proceed to Step 2)

Part No.78659051

Printed in Japan

see reverse side

Step 2 Make sure that your computer is set up for 1280x1024 resolution.

Open the Display Properties window by following this mouse click sequence ((

((

(11

11

1

, 2, 3, 4, & 5), 2, 3, 4, & 5)

, 2, 3, 4, & 5), 2, 3, 4, & 5)

, 2, 3, 4, & 5)

indicated by the numbered arrows below.

Step 3 Repeat Step 1.

This will ensure that the monitor is auto-adjusted to the new resolution.

On the right side of the Display Properties window, there is a box labeled Display

area. Make sure the „Screen‰ slide bar (6)(6)

(6)(6)

(6) is set to 1280x1024.

You may have to restart your computer for this change to take effect. After the re-

start, double check the Display Properties/Settings window to make sure you

are now at 1280x1024 resolution.

(Proceed to Step 3.)

2

1

3

4

5

6

If you have questions regarding the setup of your MultiSync LCD monitor, please refer to the user’s manual

or contact the NEC Technical Support Center at 1-800-632-4662.
