Nauticam NA-ZVE1 Manual de usuario
NA - ZVE1
For Sony ZVE1 Mirrorless Camera
User Manual
Housing
FF- MIL
PN 17434
Introduction 2
2
3
4
7
8
Package Contents
Important Instructions
Part Names and Functions
Housing Mount
Opening the housing
9Closing the housing
10
15
Preparation for Use
Optional Accessories
16
17
18
Care/Storage
Warranty
Specications
July, 2023
2
INTRODUCTION
PACKAGE CONTENTS
Thank you for purchasing this Nauticam product.
Before using the product, please read this manual thoroughly to familiarize yourself with full scope of functions on the
product as well as ensuring that you will use the product correctly.
Make sure that you have all the included items listed below before using this product.
If some items are missing or damaged, contact your local Nauticam dealer.
After purchase, we suggest that
you reuse all packaging materials
for future travelling.
Panasonic CR2032 Battery
(pre-installed for Moisture Alarm)
Spare Main O-ring
#90133
Padded Travel Case Allen key set
O-ring Remover Manual Instruction Card
NA-ZVE1
(2 x Handles with Mounting Balls, 1 x Housing Cap,
2 x Optical Fiber Mount Caps, 2 x Stainless Steel Handle Brackets)
Lubricant
3
IMPORTANT INSTRUCTIONS
Water-tight test of the housing (without
camera inside) before usage is recom-
mended as well as any O-ring renewal
and port change.
Use only Nauticam lubricant on silicone
rubber O-ring.
Discontinue use immediately when there is
a sign of leakage.
Do not expose the housing in direct
sunlight for a prolonged period.
Prevent any sand or dust or water
penetration inside the housing. Be
extra careful when changing lens and
inserting or removing the camera.
This product is not intended for use by
children, or persons with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they
are supervised and/or given instruction by
a responsible person concerning use of
the product to ensure that they can use it
safely.
Do not seal the housing when travelling by
air as this may lead to a pressure difference
between the atmosphere and inside the
housing.
Only the accesories specied by
Nauticam must be used. Third-party
accessories may result in malfunctions
or damage to the product.
Do not stretch any O-rings excessively.
Only remove it using Nauticam O-ring
remover.
Do not open the housing in wet or sandy
environment. Protect the housing from
moisture and debris in order to prevent
malfunction or leakage.
1
3
5
7
9
11 12
4
6
8
10
2
Do not attempt to remove parts of the
housing yourself. Repairs must be done
at authorized service centers only.
The housing should be positioned on the a
stable and safe surface on land.
4
PART NAMES AND FUNCTIONS
Moisture alarm window REC button
Menu button Housing unlock button
Quick control dial 1
Playback button Right/self-timer/drive mode button
Display button
ISO button
Delete/product showcase set button
Exposure compensation button
Fn button
1 2
3 4
5
7
9
11
6
8
10
12
Rear View
2
4
67
Menu/Set button
A
9
5
3
1
810
A
11
12
A
5
PART NAMES AND FUNCTIONS
M24 Accessory port
W/T/index/playback zoom lever
M10 Accessory port
Optical ber cable connection
C1/Background defocus button
Rear dial
1/4” Threaded holes
Main switch
Accessory mounting ball
M14 Accessory port
Still/movie/S&Q lever
M16 Accessory port
1
5
9
13
2
6
10
14
3
7
11
4
8
12
Top + Front Views
1
3
4
13
14
12
11
10
8
7
Port index mark Lens release button
9
6
5
2
6
PART NAMES AND FUNCTIONS
Back + Side Views
Zoom/Focus knob release
Shutter release lever
1/4” Threaded tripod holes
Port lock safety button
Housing unlock button
Port lock lever
Sacricial zinc anodes
Enlarge/C2 lever
3
7
1
4
8
5
2
6
7
6
8
2
3
4
5
1
HOUSING MOUNT
4 x 1/4” -20 mounting threads
M14 Accessory port
1
2
3
Compatible accessoriesHousing mount
25221
25086
25xxx
25081
25032
25046
25028 HDMI 1.4
HDMI 2.0
17959
25624
M10 Strobe mounting ball
M24 adaptor for HDMI 2.0 cable
M24D2R200-M28A1R170 HDMI 2.0 Cable
M24 to M16 Step down adaptor
Custom HDMI bulkhead to use with socket extension
HDMI (D-D) cable in 200mm length
Socket extension for 25032 HDMI bulkhead
with M16 thread
Housing mounting ball with 1/4’’ screws
M14 Vacuum valve II
2
M10 Accessory port
M24 Accessory port
M16 Accessory port
4
525625
25019
25056
M16 Vacuum Valve II (Pushbutton Release)
M16 to M14 Step down adaptor
M14 Nikonos 5-pin bulkhead
17954
17960 Universal tripod plate
Universal quadra-pod plate
1/4” -20 mounting threads
6
4
5
3
1
6
7
Electrical triggering
8
OPENING THE HOUSING
* drawings as illustrations only
1
2
3
depress housing unlock button
turn housing lock latch
anti-clockwise to open the
housing
ip open the back housing
when lock latch is aligned to
‘open’ position
9
CLOSING THE HOUSING
* drawings as illustrations only
1
2
3
before closing the housing, clean
and lubricate the main O-ring
make sure nothing is caught
between front and back housing
and that they are fully aligned
before locking
main O-ring
insert the housing shaft into the
shaft hole and then rotate the lock
latch clockwise until you hear and
feel it click into place
housing locked in place securely
10
PREPARATION FOR USE
Installing the Camera - housing tray attachment
1
4
2
3
unlock camera tray lever and
remove the tray from the housing
lock camera tray
* place the zoom/focus knob in
place and make sure it is engaged
with lens gear
*gently push the ON/OFF lever downwards
to make sure it is engaged with the lever on
the camera
attach the camera tray by tightening
the tray screw into the tripod socket
of the camera
place the actuator on the camera
tray in place and make sure it is
engaged with the focus mode
swtich on the camera
* rst turn the ON/OFF lever to OFF
position then lift up the ON/OFF lever
each time before installing the camera
*make sure the ON/OFF lever is
aligned with camera control OFF
position before sliding the camera into
the housing
*pull out the zoom/focus knob if
installing the camera with lens and
gear attached
slide the camera tray back into the
housing along the tray rail
* drawings as illustrations only
