INSTRUCTION MANUAL

For N100 X1855-Z Zoom Gear for

Fujifilm FU INON XF18-55F2.8-4.0

PN# 36474

Thank you for your purchase of a NAUTICAM

product.

At NAUTICAM, e pride ourselves in the ability to

recognize the requirements of professional as ell

as amateur under ater photographers and fulfill

them through the innovative designs of our

products. We strive to achieve a high level of

user-friendliness by allo ing stress-free

installation and easy operation of all important

functions of the camera.

Each product is individually inspected and ater

pressure tested to ensure optimum quality.

Please read this manual carefully before using the

product, this ill maximize its performance as ell

as its lifetime.

FORWORD

Current as of 1/16/2023

All NAUTICAM Products are arranted against

any material and manufacturing defects for t o

years from the date of purchase for consumer

use. This arranty only applies to products

purchased from authorized NAUTICAM dealers

and does not extend beyond the original retail

purchaser.

To return your product for service, please

contact your regional authorized service

center(s). Please note that this arranty only

applies hen the product is purchased in the

territory here the service center is located.

NAUTICAM does not hold responsibility for

damage, of any nature, to any equipment used

ith and/or placed ithin our products.

NAUTICAM accepts no liability for any loss of

captured images or the inability to capture

images even if it is due to the malfunctioning of

our products.

Unauthorized modifications and/or repairs of

our products ill automatically invalidate the

arranty.

WARRANTY

IDENTIFICATION OF PARTS

Spare Rubber grips

Plastic C-ring

X1855-Z Zoom Gear

MOUNT THE GEAR ON A LENS

1. Insert the plastic C-ring as sho n and

place it over the lens.

2 Insert the X1855-Z Zoom Gear on the

plastic C-ring until it reaches the

flange of the plastic C-ring.

3. To remove the X1855-Z Zoom Gear,

reverse the above steps.

The tightness bet een the X1855-Z

Zoom Gear and the lens can be

adjusted by removing or adding rubber

grips on either sides of the plastic C-

ring, spare rubber grips are included in

the package.

CONTROL THE GEAR

1. The X1855-Z Zoom Gear can be controlled by zoom/focus knob of the

housing.

After mount the camera and lens ( ith gear installed) on the housing,

confirm that the zoom/focus knob operates correctly.

SPECIFICATIONS

#36474 N100 X1855-Z Zoom Gear for Fujifilm

FU INON XF18-55F2.8-4.0

Dimensions: DIA87.0mm ×41.9mm

Type: Zoom gear

Compatible lens: Fujifilm FU INON XF18-

55F2.8-4.0

Remark:

Nauticam supports only e-manuals. Please do nload

corresponding product manuals on google drive

https://bit.ly/Nauticammanual, or contact us for e-

manuals.
