Nauticam Atomos shogun Manual de usuario
0
1
Thank you for your purchase of a NAUTICAM housing.
At NAUTICAM, we pride ourselves in the ability to recognise the re uirements of
professional as well as amateur underwater photographers and fulfill them
through the innovative designs of our products. We strive to achieve a high level
of user-friendliness by allowing stress-free installation and easy operation of all
important functions of the camera.
Each housing is individually inspected and water pressure tested to ensure
optimum uality.
Please read this manual carefully before using the housing, this will maximise its
performance as well as its lifetime.
2
1.
All NAUTICAM Products are warranted against any material and
manufacturing defects for one year from the date of purchase for consumer
use. Please fill in the warranty cards shipped with our housings and
viewfinders at the time of sale and return them to your point of purchase
within a month. If we do not receive the completed warranty card for a
particular product, the warranty period would be assumed to begin from the
day that the product is shipped from our facility. This warranty only applies to
products purchased from authorised NAUTICAM dealers and does not extend
beyond the original retail purchaser.
2.
To return your product for service, please contact your regional authorized
service centre(s). Please note that this warranty only applies when the
product is purchased in the territory where the service centre is located.
3.
NAUTICAM accepts no liability for any damage to and defects in the housing
caused by improper use and/or poor maintenance; it is the responsibility of
the owner to carefully follow the instructions in our manuals.
4.
NAUTICAM does not hold responsibility for damage, of any nature, to any
e uipment used with and/or placed within our products.
5.
NAUTICAM accepts no liability for any loss of captured images or the inability
to capture images even if it is due to the malfunctioning of our products.
6.
Unauthorised modifications and/or repairs of our products will automatically
invalidate the warranty.
3
1. Nauticam Atomos Shogun Housing
2. HDMI bulkhead with integrated cable and type D connector
3. Instruction manual
4. Hand pump
5. Spare silicone rubber main o-ring
6. O-ring remover
7. CR2032 battery (Vacuum Check and Leak Detection System)
8. Lubricant
9. Set of Allen keys
Spare silicone rubber o-ring
Lubricant CR2032 battery
HDMI bulkhead with integrated
cable and type D connector
Hand Pump
O-ring remover
4
1. A water-tight test without the monitor inside the housing is highly
recommended when using the system for the first time and after the changing
of port and O-ring(s).
2. Do not use lubricants from other brands with the silicone rubber O-ring on this
housing, only use the lubricant provided by NAUTICAM.
3. Discontinue use immediately should you notice any leakage.
4. Store the housing in a robust, shock-proof container during transportation;
avoid transporting with any e uipment, such as a camera, inside the housing.
5. When travelling by air, do not close the housing as this may lead to a pressure
difference between the atmosphere and inside the housing.
6. Care must be taken when opening the housing, as pressure may build up inside
the housing which increases the opening force.
7. Do not open the product in a wet or sandy environment. Protect the interior
from moisture and debris in order to prevent malfunction or leakage.
8. Do not store the product in an environment of high humidity.
9. Do not leave the housing and the monitor in direct sunlight for prolonged
periods.
10. Keep out of reach of children, failure to do so could result in injury.
11. Defective products should be shipped to our distributors for service,
unauthorized disassembling and/or modifications could result in malfunction
or leakage.
5
Specifications 6
Identification of Parts 7
Opening and Locking the Housing 8
Preparation of the Housing 9
Installing the Monitor 13
onnecting to the amera Housing 14
are and Maintenance 16
Optional Accessories 17
6
Construction
Housing body: Aluminium alloy
Surface treatment: Hard anodised
Display window: Abrasion resistant polycarbonate
Dimensions
Width: 286mm
Height: 176mm
Depth: 120mm
Weight Approx. 2.35kg
Buoyancy Positive
Depth rating 60 metres
Operating
Temperature
Normal operating temperature is between 10°C and
40°C. For usage outside the stated temperature range,
please contact our dealers for more information.
7
1 HDMI cable 10 Fan indicator
2 Moisture alarm window 11 M14 accessory port
3 M16 Vacuum valve 12 Fan on/off button
4 Threaded holes for monitor
hood (4x) 13 Monitor on/off button
5 REC button 14 Housing lock safety button
6 PLAY button 15 Housing lock
7 1/4" threaded holes attachment
points (4x) 16 Waveform Monitoring button
8 Swing button for various
controls 17 Monitor Assist button
9 M16 accessory port
1
3
2
9
4
12
13
8
7
11
14
15
5
6
16
17
10
8
To open the housing:
To lock the housing:
1.
Press the housing lock safety
button.
2.
Turn the housing lock anti
-
clockwise for 270°, until the lock
reaches the “Open” position as
shown.
3.
Close the housing while the
housing lock is in the “Open”
position.
4.
Turn the housing lock clockwise
for 270°, until the lock reaches the
“lock” position as shown.
Confirm that the white indicator
line on the safety button is
visible.
9
1. After verifying that the main O-ring is in good condition, lightly coat it with the
lubricant provided.
2. Make sure the O-ring groove located in the front part of the housing is free
from any foreign material; the groove can be cleaned with the aid of a
microfiber cloth.
3. Place the main O-ring into the groove, first at the corners, then the whole
perimeter.
4. Setting up the cooling fans:
Insert a Sony NP-F570 battery or Atomos 7.4V 2600mah battery to the fan battery
holder as shown. Only use the battery models stated above.
