sbRIO-9607

GETTING STARTED GUIDE

NI sbRIO-9607

Single-Board RIO OEM Devices

This document describes how to begin using the NI sbRIO-9607.

Safety Guidelines

Operate the sbRIO-9607 only as described in the user documentation.

Caution The sbRIO-9607 must be installed in a suitable enclosure prior to use.

Caution NI makes no product safety, electromagnetic compatibility (EMC), or CE

marking compliance claims for the sbRIO-9607. The end-product supplier is

responsible for conformity to any and all compliance requirements.

Caution Exercise caution when designing an enclosure for the sbRIO-9607.

Auxiliary cooling may be necessary to keep the sbRIO-9607 within the specified

operating temperature range. Refer to the NI sbRIO-9607 Specifications on ni.com/

manuals for more information about the maximum operating temperature rating. For

information and examples regarding factors that can affect thermal performance,

visit ni.com/info and enter the Info Code sbriocooling.

Caution Do not operate the sbRIO-9607 in a manner not specified in this

document. Product misuse can result in a hazard. You can compromise the safety

protection built into the product if the product is damaged in any way. If the product

is damaged, return it to NI for repair.

Safety Voltages

Connect only voltages that are below these limits.

V terminal to C terminal 30 VDC maximum, Measurement Category I

Measurement Category I is for measurements performed on circuits not directly connected to

the electrical distribution system referred to as MAINS voltage. MAINS is a hazardous live

electrical supply system that powers equipment. This category is for measurements of voltages

from specially protected secondary circuits. Such voltage measurements include signal levels,

special equipment, limited-energy parts of equipment, circuits powered by regulated low-

voltage sources, and electronics.

Caution Do not connect the sbRIO-9607 to signals or use for measurements within

Measurement Categories II, III, or IV.

Preparing the Environment

Ensure that the environment in which you are using the sbRIO-9607 meets the following

specifications.

Local ambient operating temperature near

device (IEC 60068-2-1, IEC 60068-2-2)

-40 °C to 85 °C

Maximum reported onboard sensor temperature

CPU/FPGA temperature 98 °C

Primary System temperature 85 °C

Secondary System temperature 85 °C

Note Ensure that the local ambient, reported CPU/FPGA, and reported Primary

System temperatures do not exceed any of the maximum temperatures listed in this

document. For more information about how to access the onboard sensors, visit

ni.com/info and enter the Info Code sbriosensors.

Operating humidity (IEC 60068-2-78) 10% RH to 90% RH, noncondensing

Pollution Degree (IEC 60664) 2

Maximum altitude 5,000 m

Indoor use only.

Note Refer to the device specifications on ni.com/manuals for complete

specifications.

2| ni.com | NI sbRIO-9607 Getting Started Guide

Unpacking the Kit

Caution To prevent electrostatic discharge (ESD) from damaging the device,

ground yourself using a grounding strap or by holding a grounded object, such as

your computer chassis.

1. Touch the antistatic package to a metal part of the computer chassis.

2. Remove the device from the package and inspect the device for loose components or any

other sign of damage.

Caution Never touch the exposed pins of connectors.

Note Do not install a device if it appears damaged in any way.

3. Unpack any other items and documentation from the kit.

Store the device in the antistatic package when the device is not in use.

Verifying the Kit Contents

Verify that the following items are included in the sbRIO-9607 kit.

Figure 1. sbRIO-9607 Kit Contents

12 3 4

5 6 7 8

1. sbRIO Device

2. NI CompactRIO Device Drivers Media

3. Getting Started Guide

4. Power Supply

5. 10-pin IDC to 9-pin DSUB Cable

6. Power Cable Assembly

7. Standoffs and Screws

8. NI 9694 Digital I/O Breakout RMC Board

Note The provided power supply is only intended for the getting started

experience. NI recommends the use of a power supply that meets the specifications

listed in the NI sbRIO-9607 Specifications for system deployment.

NI sbRIO-9607 Getting Started Guide | © National Instruments | 3

Installing Software on the Host Computer

Before using the sbRIO-9607, you must install the following application software and device

drivers on the host computer.

1. LabVIEW 2015 or later

2. LabVIEW Real-Time Module 2015 or later

3. LabVIEW FPGA Module 2015 or later

4. NI CompactRIO Device Drivers August 2015 or later

For minimum software support information, visit ni.com/info and enter the Info Code

softwareversion.

Connecting the sbRIO-9607

The sbRIO-9607 has the following components.

Figure 2. sbRIO-9607 Components

1 2 3 4 5 6 7 8

1. J9, Power Connector

2. Chassis Ground Bracket

3. J10, USB Host Port

4. W1, CAN (CAN0)

5. J7, RJ-45 Ethernet Port

6. W2, RS-232 (COM1)

7. Reset Switch

8. LEDs

9. Mounting Holes Connected to Chassis Ground

10. Ethernet RGMII Transceiver

11. ULPI USB Transceiver

12. FPGA Processor

13. DDR Memory

14. NAND Flash

15. CPLD

16. J1, RIO Mezzanine Card Connector

4| ni.com | NI sbRIO-9607 Getting Started Guide

Connecting the sbRIO-9607 to Power

The NI sbRIO device requires a 9 VDC to 30 VDC external power supply. The NI sbRIO

device filters and regulates the supplied power and provides power for RMCs.

Note Refer to the Power Requirements section of the NI sbRIO-9607

Specifications for the complete power requirement specifications.

Note Refer to the Power Requirements section of the NI sbRIO-9607 User Manual

for formulas and examples for calculating power requirements for different

configurations and application types.

Note Refer to the Power Requirements section of the NI sbRIO-9607 User Manual

for proper wiring of the power cable assembly.

Complete the following steps to connect a power supply to the device.

Caution Do not mate or unmate the power supply connectors while power is

applied.

1. Ensure that your power supply is powered off.

2. Insert the power connector plug into the power connector receptacle of the NI sbRIO

device until the connector latches into place.

3. Turn on the power supply.

Powering On the NI sbRIO Device

The NI sbRIO device runs a power-on self test (POST) when you apply power to the device.

During the POST, the Power and Status LEDs turn on. When the Status LED turns off, the

POST is complete. If the LEDs do not behave in this way when the system powers on, refer to

the STATUS LED Indicators section.

Connecting the sbRIO-9607 to the Host Computer

Complete the following steps to connect the sbRIO-9607 to the host computer using the RJ-45

Ethernet port.

1. Power on the host computer.

2. Connect the sbRIO-9607 to the host computer using a standard Category 5 (CAT-5) or

better shielded, twisted-pair Ethernet cable.

Caution To prevent data loss and to maintain the integrity of your Ethernet

installation, do not use a cable longer than 100 m.

The first time you power up the device, it attempts to initiate a DHCP network

connection. If the device is unable to initiate a DHCP connection, it connects to the

network with a link-local IP address with the form 169.254.x.x. After the device has

NI sbRIO-9607 Getting Started Guide | © National Instruments | 5

powered up, you must install software on the device and configure the network settings in

MAX.

Note Installing software may change the network behavior of the device. For

information about network behavior by installed software version, visit ni.com/

info and enter the Info Code ipconfigcrio.

Configuring the System in Measurement &

Automation Explorer (MAX)

Complete the following steps to find the system in MAX.

1. Launch MAX on the host computer.

2. Expand Remote Systems in the configuration tree and locate your system.

3. Select your target.

Tip MAX lists the system under the model number followed by the serial

number, such as NI-sbRIO-9607-########.

Setting a System Password

Complete the following steps to set a system password.

Note The default username for the sbRIO-9607 is admin. There is no default

password for the sbRIO-9607, so you must leave the password field blank when

logging in until you set a system password.

1. Right-click your system and select Web Configuration.

The NI Web-Based Configuration and Monitoring utility opens in your default browser

and is where you set the password. If you have not installed Microsoft Silverlight,

NI Web-based Configuration & Monitoring prompts you to do so.

2. Enter a unique name for your system in the Hostname field.

3. Click the Security Configuration icon.

4. Click Login.

5. In the Login dialog box, enter the username admin and leave the password field blank.

6. Click OK.

7. Click Change Password.

8. Enter and re-enter a new password.

9. Click OK.

10. Click Save.

11. Click OK to confirm you are changing the password.

Caution NI cannot recover lost system passwords. If you forget the password,

you must contact NI and reformat the controller.

6| ni.com | NI sbRIO-9607 Getting Started Guide

Installing Software on the sbRIO-9607

Complete the following steps to install software on the sbRIO-9607.

1. In MAX, expand your system under Remote Systems.

2. Right-click Software.

3. Select Add/Remove Software to launch the LabVIEW Real-Time Software Wizard.

Tip You must log in if you set a system password.

4. Select the recommended software set for your LabVIEW and NI CompactRIO Device

Drivers versions.

5. Click Next.

6. Select NI Scan Engine from the software add-ons.

Select any additional software to install. If you plan on using the sbRIO-9607 with the

LabVIEW FPGA Module, you can click Next.

Tip You can use this wizard at anytime to install additional software.

7. Click Next.

8. Verify that the summary of software to install is correct.

9. Click Next to start the installation.

10. Click Finish when the installation is complete.

Troubleshooting the sbRIO-9607

The sbRIO-9607 is Not Communicating with the

Network

• Ensure that the Ethernet connections between the sbRIO-9607 and the host computer and

the Ethernet connections between the host computer and the router are secure.

• Ensure that you have the correct version of NI CompactRIO Device Drivers installed on

the host computer. Visit ni.com/info and enter the Info Code softwareversion for the

minimum supported versions of LabVIEW and NI CompactRIO Device Drivers.

Tip If you have recently upgraded LabVIEW, you must reinstall NI

CompactRIO Device Drivers.

• Temporarily disable any network firewalls or other security software.

Configure the IP and other network settings by completing the following steps.

1. Use a standard Category 5 (CAT-5) or better shielded, twisted-pair Ethernet cable to

connect the sbRIO-9607 Ethernet port to a host computer. The sbRIO-9607 attempts to

initiate a DHCP network connection at powerup.

NI sbRIO-9607 Getting Started Guide | © National Instruments | 7

2. In MAX, expand your system under Remote Systems and select Troubleshoot Remote

System Discovery.

System Reset

The following figure shows the reset behavior of the sbRIO-9607.

Figure 3. Reset Button Behavior

Press and hold RESET button for ≥5 s

Press and hold RESET button for <5 s

Run Mode

Safe Mode

Press and hold RESET button for <5 s

Press and hold RESET button for ≥5 s

Press and hold

RESET button for ≥5 s

Press and hold

RESET button for <5 s

• Console Out enabled

• Network settings reset

• RT Startup App disabled

• FPGA Startup App disabled

• Console Out enabled

• RT Startup App disabled

• FPGA Startup App disabled

Safe Mode

STATUS LED Indicators

The following table lists the STATUS LED indicators.

8| ni.com | NI sbRIO-9607 Getting Started Guide

Table 1. STATUS LED Indicators

LED Pattern Indication

Blinks twice and

pauses

The sbRIO-9607 is in safe mode. Software is not installed, which is the

factory default state, or software has been improperly installed on the

sbRIO-9607.

An error can occur when an attempt to upgrade the software is

interrupted. Reinstall software on the sbRIO-9607. Refer to the

Measurement & Automation Explorer (MAX) Help for information

about installing software on the sbRIO-9607.

Blinks three times

and pauses

The sbRIO-9607 is in user-directed safe mode, or the sbRIO-9607 is in

install mode to indicate that software is currently being installed.

This pattern may also indicate that the user has forced the sbRIO-9607

to boot into safe mode by pressing the reset button for longer than five

seconds or by enabling safe mode in MAX. Refer to the Measurement

& Automation Explorer (MAX) Help for information about safe mode.

Blinks four times

and pauses

The sbRIO-9607 is in safe mode. The software has crashed twice

without rebooting or cycling power between crashes.

This usually indicates that the sbRIO-9607 has run out of memory.

Review your LabVIEW Real-Time application to resolve any memory

leaks.

Continuously blinks The sbRIO-9607 has not booted into NI Linux Real-Time. The

sbRIO-9607 either booted into an unsupported operating system, was

interrupted during the boot process, or detected an unrecoverable

software error.

On momentarily The sbRIO-9607 is booting. No action required.

Off The sbRIO-9607 is in run mode. Software is installed and the

operating system is running.

NI sbRIO-9607 Getting Started Guide | © National Instruments | 9

Otros manuales para sbRIO-9607

Tabla de contenidos

Otros manuales de Hardware de computadora de National Instruments

National Instruments

National Instruments SCXI-1321 Manual de usuario

National Instruments

National Instruments USRP-2940 Manual de usuario

National Instruments

National Instruments PCMCIA-GPIB Manual de usuario

National Instruments

National Instruments NI PCI-GPIB Manual de usuario

National Instruments

National Instruments PXIe-8100 Manual de usuario

National Instruments

National Instruments Network Adapter NI PXIe-1075 Manual de usuario

National Instruments

National Instruments USB-6211 OEM Manual de usuario

National Instruments

National Instruments NI PXIe-1062Q Manual de usuario

National Instruments

National Instruments NI PXI-8185 Manual de usuario

National Instruments

National Instruments SC Express PXIe-4331 Manual de usuario

National Instruments

National Instruments NI PXI-1042 Series Manual de usuario

National Instruments

National Instruments 9260 Manual de usuario

National Instruments

National Instruments PCI-6034E Manual de usuario

National Instruments

National Instruments SCB-19 Manual de usuario

National Instruments

National Instruments IMAQTM Manual de usuario

National Instruments

National Instruments GPIB-120B Manual de usuario

National Instruments

National Instruments NI PXIe-8105 Manual de usuario

National Instruments

National Instruments NAT7210 Manual de usuario

National Instruments

National Instruments ExpressCard Strain-Relief Manual de usuario

National Instruments

National Instruments NI PXIe-8130 Manual de usuario

National Instruments

National Instruments DAQ PCI-1200 Manual de usuario

National Instruments

National Instruments 8221 Manual de usuario

National Instruments

National Instruments NI sbRIO-960x Manual de usuario

National Instruments

National Instruments PXI-8170 Series Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario

Advantech

Advantech ASMB-935 Series Manual de usuario

National Instruments sbRIO-9607 Manual de usuario

Manuales populares de Hardware de computadora de otras marcas
