Select Radiator Series

Installation Guide MYSON

Revised 6/12

Select Radiator Series

Table of Contents

MYSON

Information Symbols...............................................................................3

Before You Begin....................................................................................4

Rough-In..................................................................................................5

Connection Arrangements .....................................................................6

Connection Options................................................................................7

Optional Piping Arrangements...............................................................8

Conventional Wall Installation ................................................................9

Concrete Wall Installation ....................................................................10

Valve Installation..............................................................................11-12

System Start-Up & Maintenance ..........................................................13

Myson, Inc. Limited Warranty

Myson, Inc warrants the following products against defects in material and workmanship to the original owner

for the duration listed from date of installation or three months after date of shipment, whichever comes first.

The remedy in all cases shall be to repair or replace the product at Myson’s discretion upon verification of a

factory defect. If replacement is required, and an exact replacement product is no longer available, Myson

reserves the right to furnish a similar product of equal value.

NO REMOVAL, SHIPPING OR INSTALLATION EXPENSES ARE REIMBURSIBLE

The original purchaser is responsible for determining the suitability of the Myson product for their installation.

Installation and troubleshooting should be performed by a competent technician with knowledge of hydronic

heating and/or basic electricity.

Damages occurring during shipment, transit, storage or handling, abuse, neglect, accident, misapplication,

incorrect power line voltage, improper water source or connection, fire, flood or other Acts of God are not

covered. Freight damage claims MUST be made within 10 days of receipt from Myson. No Exceptions.

STEEL PANEL RADIATORS — SELECT, T6, DÉCOR, COLUMN AND BENCH

The duration of warranty for steel panel radiators is 5 Years.

What is covered:

• Painted finishes will not peel or flake from the surface of the radiator.

• The body of the radiator and its welded joints will not leak when the product is properly installed and

maintained according to Myson’s instructions.

What is not covered:

• Rust occurring from improperly sealed threaded connections or oxygen corrosion.

• Electrolytic corrosion caused by failure to flush the system properly after initial installation.

NOTE: You will see these symbols within the text of this manual, drawing your

attention to important information.

Myson products are designed to be installed by professional tradespeople.

Myson instructions are meant to be thorough; however it is assumed that the

installer has the appropriate technical knowledge related to building codes,

standard trade practices, and proper use of the tools of the trade. Should a

homeowner without such knowledge or skill take it upon him/herself to attempt

the installation, Myson will not be responsible for any damages, injuries or

unsatisfactory performance of the Myson product used.

Information following this symbol indicates that it is important for the correct

installation or use of the product. Failure to heed this information may affect the

performance or useful life of the product. Risk of property damage or personal

injury is low.

Information following this symbol must be followed without exception.

Failure to follow these directions could result in moderate property

damage or the possibility of personal injury.

Information following this sign must be carefully followed without exception.

Failure to do so could result in significant and extensive property damage or

serious personal injury or death.

Select Radiator Series

Information Symbols MYSON

INSPECT FOR DAMAGE

NOTE: Inspect materials for concealed shipping damage. You only have 11 days to file a

freight claim. If items are damaged or missing, please call Myson at 1-800-698-9690.

INSPECTION FOR COMPLETENESS

Unpack the Select Radiator carefully to avoid damage or loss of parts.

The Select Radiator should come with the following parts:

2 - Concrete wall brackets

1 - Stainless steel solid plug

1 - Stainless steel air vent plug

INTRODUCTION

The Myson Select Radiator will keep any room in comfort and style. We at Myson, Inc. thank you

for your purchase of the Select Radiator. Each radiator combines Myson’s compact design and

advanced steel construction with a durable baked epoxy/polyester enamel powder coat finish.

Myson’s sleek styling and thorough testing provides attractiveness and dependability. Myson’s

goal is to assure the highest performance, quality, reliability and outstanding customer service.

CAUTION

Step 1 Read this entire instruction manual thoroughly before beginning installation.

Step 2 To ensure full efficiency of your Myson Select Steel Panel Radiator, please follow all the

instructions carefully observing the caution notes for each step.

Step 3 Failure to follow these instructions will invalidate the manufacturer’s warranty.

APPLICATION

Myson radiators are only for use in recirculating closed loop hydronic heating systems. These

radiators are not recommended for gravity systems. Myson Select Radiators are designed to work

with a maximum working pressure of 78 PSI and no more then 212 degrees F water temperature.

DO NOT USE STEAM IN THESE RADIATORS.

DESIGN AND LAYOUT CONDITIONS

Myson Select Radiators should only be used with a recirculating pump closed loop hydronic

heating system. Please consult national and local codes for specific restrictions that may be

imposed on your installation. Position your radiator away from your circulator pump to avoid

either excess pressure that could force water out the air vent or excess suction that could draw

air into the system. The preferred positioning for the Select radiator is below a window where

it can minimize downdrafts from glazed areas.

Myson Radiators may be hot to the touch. Generally the surface temperature is at 10-12

degrees Fahrenheit below system water temperature. Care must be taken to consider room

occupant’s ability to sense or understand that radiators may be hot. Should radiator surface or

system water temperature be an issue, please contact MYSON at 1-800-698-9690 for information

on the MYSON LST radiators. LST (Low Surface Temperature) Radiators can be a viable solution

where temperatures are a safety concern.

Select Radiator Series

Before You Begin

MYSON

Rough-ins given are for MYSON TRV and Control Valves only. Valve specifications vary by

manufacturer. Myson will not be responsible for damage or repair of property for rough-in with

non-Myson Valves. Prior to committing pipe work behind finish floor or wall materials, consult

Myson for assistance at 1-800-698-9690.

Dimensions are in inches. All valves are by MYSON and are 1/2” thread engagement in a vertical

pattern. For two LKD valves, use LKD and TRV dimensions.

It is not recommended to route piping through the walls for single panel radiators (TYPE 11) as

there is generally insufficient room to leave the wall and make the angle into the radiator.

Select Radiator Series

Rough-in MYSON

Nominal

Height Size C

12” 30 9-11/16”

16” 40 13-5/8”

24” 60 21-1/2”

28” 70 25-7/16”

Actual LKD & FF LKD & TRV (2) DAV12 TRV & DAV12

Model Length Valves Valves Valves Valves

A B B B B

40G 15-3/4” 19-3/8” 19-1/8” 18-3/4” 19-”

50G 19-11/16” 23-5/16” 23-3/16” 22-11/16” 22-15/16”

60G 23-5/8” 27-1/4” 27-1/8” 26-3/8” 26-7/8”

70G 27-9/16” 31-3/16” 31-1/16” 30-9/16” 30-13/16”

80G 31-1/2” 35-1/8” 35-” 34-1/2” 34-3/4”

90G 35-7/16” 39-1/16” 38-15/16” 38-7/16” 38-11/16”

100G 39-3/8” 43-” 42-7/8” 42-3/8” 42-5/8”

110G 43-5/16” 46-15/16” 46-13/16” 46-5/16” 46-9/16”

120G 47-1/4” 50-7/8” 50-3/4” 50-1/4” 50-1/2”

130G 51-3/16” 54-13/16” 54-11/16” 54-3/16” 54-7/16”

140G 55-1/8” 58-3/4” 58-5/8” 58-1/8” 58-3/8”

160G 63-” 66-5/8” 66-1/2” 66-” 66-1/4”

180G 70-7/8” 74-1/2” 74-3/8” 73-7/8” 74-1/8”

* Using optional EZ-Brackets

CONNECTIONS: Myson Radiators come with two 1/2” BSP connections located at the

bottom of both sides on the radiator.

All Myson Radiators are shipped with nylon paint plugs. All plugs must be

removed and replaced by the appropriate plug, vent or valve. Failure to use

Myson supplied plugs may result in significant water damage!

Select Radiator Series

Connection Arrangements

MYSON

Preferred methods A, B, C, and D

For alternate methods E, F, G, and H, derate the radiation by 5%

PPlug VVent SSupply R Return

AB C D

EFGH

SVVS

RSRPPR

PRRPPS

VSR VVR

888

TRV thermostatic valve and LKD lockshield valve

2TRV1/2ANS

2TRV RS Remote sensor 2TRV RA Remote adjuster

2TRV1/2ANS

DCK12

2TRV1/2ANS

FF WAC

FF 16 WAC

LKD 16AN

TRV head with vertical

angle body head

TRV head with

straight body head

TRV head with inverted

angle body head

LKD 16AN

FF LAC

DAV12

DAV12DAV12

LKD 16AN

FF WAC Wheelhead angle valve & LKD lockshield valve

For best accuracy 2TRV2 head should be in a horizontal position

away from heat source. Remote Sensor or Adjuster heads are available

2 LKD lockshield valves

2 Decorative manual angle valves

TRV thermostatic valve & FF LAC Lockshield angle valve

FF WAC Wheelhead angle & FFLAC lockshield angle valve.TRV thermostatic valve & Decorative manual angle valve

NOTE:

See Radiator Range Technical Specifications

for Mounting Details of Radiators.

Copper pipe

Copper pipe Copper pipe

Copper pipe

Select Radiator Series

Connection Options MYSON

(FF LAC) Valve is set full open and white knob will not turn. Angle only.

(FF WAC) Valve white knob can turn to open or close the valve. Angle only.

(LKD) Manual valve, has chrome cap that can be removed exposing an adjustment screw to open or close the valve. Angle or straight.

(TRV) Valve is a non-electric thermostatic valve that modulates water flow in response to changes in room temperature and closes when set

temperature is achieved. NOTE: This valve will not turn on or shut off your heating system. Horizontal angle, vertical angle or straight pattern.

(DCK12) Pipe extension with compression fitting and escutcheon for use with the 2TRV1/2ANS valve.

(DAV12) Manual valve, adjust flow with Allen wrench. Valve comes with chrome pipe extension with compression fitting and escutcheon.

MYSON Select Radiator Series

Optional Piping Arrangements

General information on the use of Monoflo tees:

• Scoop type is placed on the supply

• Venturi type on the return

• If heating unit is below main or more than 4 feet

horizontally from the main, use two monoflo tees

facing each other

The following drawings are general examples.

Consult a certified heating professional for your specific application.

Step 1 Locate studs in wall where the radiator is to be mounted.

Step 2 Mount the brackets so the radiator is a minimum of 4 inches off the floor.

• Failure to allow 4” minimum clearance below radiator can significantly reduce

radiator performance.

• Attach brackets firmly to the studs using appropriate hardware making sure

the spring loaded connection on brackets is on top.

• All Select Radiators use 2 brackets except the 180G which uses 3 brackets.

• Use a level to assure bracket is plumb.

Step 3 To install the radiator on the brackets, set the top edge of the top grill into the upper

part of the bracket then gently lift and snap the bottom into the lower part of the bracket.

Step 4 Position radiator to line up with the supply and return pipes.

Many MYSON products are in excess of 70 pounds. Care should be taken to have help to lift

larger radiators into place to avoid lifting injuries.

Select Radiator Series

Conventional Wall Installation Using Optional EZ-Brackets

Step 1 Position radiator to line up with the supply and return pipes.

Step 2 Position brackets on wall so that they line up with the centerline of the brackets on

the rear of the Select Radiator.

Step 3 Mount the brackets so the radiator is a minimum of 4 inches off the floor.

• Failure to maintain 4” minimum clearance to floor can significantly reduce

radiator’s performance.

• Attach brackets firmly to the wall using appropriate hardware.

• Use a level to assure bracket is plumb.

Step 4 Lift and seat the radiator onto the brackets.

Nominal

Height A B C

12” 11-13/16” 6-1/4” 6-1/4”

16” 15-3/4” 8-3/16” 6-1/4”

24” 23-5/8” 9-” 12-3/8”

28” 27-9/16 10-15/16” 12-3/8”

MYSON Select Radiator Series

Concrete Wall Installation

Many MYSON Radiators are in excess of 70 pounds. Care should be taken to have

help to lift larger radiators into place to avoid lifting injuries.

Select Mounting Bracket Locations

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Calentador de Myson

Myson

Myson FINESSE Manual de usuario

Myson

Myson WHISPA WE50K Manual de usuario

Myson

Myson ELECTRIC DECOR H EXX20060 Series Guía de mantenimiento y servicio

Myson

Myson WHISPA III 5000 WM Manual de usuario

Myson

Myson 2-Pipe Manual de usuario

Myson

Myson ULOW-E2 Guía de inicio rápido

Myson

Myson iVector S2 Manual de usuario

Myson

Myson T6 Series Manual de usuario

Myson

Myson KICKSPACE 500 DUO Instrucciones de instalación

Myson

Myson Kickspace 500E Manual de usuario

Myson

Myson RIO Series Manual de usuario

Myson

Myson Finesse EC Guía rápida

Myson

Myson LO-LINE RC 6-4 Manual de usuario

Myson

Myson Kickspace 500 Manual de usuario

Myson

Myson SLIM-LINE RC Manual de usuario

Myson

Myson Kickspace 500 Instrucciones de instalación

Myson

Myson Kickspace 500 Manual de operación y mantenimiento

Myson

Myson T621-3-92 Manual de usuario

Myson

Myson LO-LINE RC 9-6 Manual de usuario

Myson

Myson Kickspace 500E ECO Instrucciones de instalación

Myson

Myson HEK Manual de usuario

Myson

Myson SELECT Guía de inicio rápido

Myson

Myson iV080 Manual de usuario

Myson

Myson FINESSE Manual de usuario

Manuales populares de Calentador de otras marcas

oventrop

oventrop Regucor Series Manual de usuario

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manual de usuario

ELMEKO

ELMEKO ML 150 Manual de usuario

BN Thermic

BN Thermic 830T Manual de usuario

KING

KING K Series Guía

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guía de inicio rápido

Well Straler

Well Straler RC-16B Manual de usuario

EUROM

EUROM 333299 Manual de usuario

Heylo

Heylo K 170 Manual de usuario

Eterna

Eterna TR70W Manual de usuario

Clarke

Clarke GRH15 Manual de instrucciones

IRSAP

IRSAP The Radiator Company Ovali Manual de usuario

Empire Heating Systems

Empire Heating Systems WCC65 Manual de usuario

Wetekom

Wetekom 92 86 43 Manual de usuario

Desa

Desa SPC170-F Manual de usuario

Watlow

Watlow Watrod Electric Tubular Heaters Manual de usuario

Haverland

Haverland ECO-DRY GPS Series Manual de lista de piezas

Stelpro

Stelpro ASILVC2060 Series Manual de usuario
