MuxLab 500464 Manual de usuario

HDMI 2.0 Fiber

Extender Kit

Installation Guide

500464

HDMI 2.0 Fiber Extender Kit Installation Guide

SAFETY PRECAUTIONS

To insure the best from the product, please read all instructions carefully before using

the device. Save this manual for further reference.

Follow basic safety precautions to reduce the risk of fire, electrical shock and injury

to persons.

Do not dismantle the housing or modify the module. It may result in electrical shock

or may burn.

To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this

product near water. Keep the product away from liquids.

Spillage into the housing may result in fire, electrical shock, or equipment damage. If

an object or liquid falls or spills on to the housing, unplug the module immediately.

Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to

the device before cleaning.

Using supplies or parts not meeting the product’s specifications may cause damage,

deterioration or malfunction.

Refer all servicing to qualified service personnel.

Install the device in a place with good ventilation to avoid damage caused by

overheating.

Unplug the power cord when left unused for a long period of time.

Do not put any heavy items on the unit.

Do not remove the housing of the device as you may be exposed to dangerous

voltage or other hazards.

Do not twist or pull with force ends of the optical cable attached to the unit, as it may

cause damage.

Information on disposal of devices: do not burn or mix with general household waste,

please treat this device as normal electrical wastes.

Unpack the equipment carefully and save the original box and packing material for

possible future shipment

NOTICE:

Please read this user manual carefully before using the product.

HDMI 2.0 Fiber Extender Kit Installation Guide

Contents

1. Introduction.................................................................................................................4

1.1 Introduction to the 500464.................................................................................4

1.2 Features ............................................................................................................4

1.3 Package Contents.............................................................................................4

2. Specifications..............................................................................................................5

3. System Requirement for Installation...........................................................................5

3.1 Hardware requirements.....................................................................................5

3.2 Software requirements ......................................................................................6

3.3 AC/DC Power Adapter (Technical Advisory) ......................................................6

4. System Connection.....................................................................................................6

4.1 Safety Precautions ............................................................................................6

4.2 System Diagram................................................................................................6

4.3 Connection Procedure.......................................................................................7

5. Troubleshooting & Maintenance .................................................................................9

Maintenance..........................................................................................................10

Technical Support and Service..............................................................................10

Certification of Eye Safety.....................................................................................10

Regulatory Compliance ................................................................................................11

HDMI 2.0 Fiber Extender Kit Installation Guide

1. Introduction

1.1 Introduction to the 500464

The HDMI 2.0 Fiber Extender Kit, 500464 enables the user to transmit 4K (4096x2160)

video at 60Hz signal up to 330ft (100m), with any form of scaling or data compression

being applied to the signal. This device supports a total data throughput of 18Gbps

(6Gbps per lane).

The unit supports two (2) LC connectors and may be connected with OM3 multi-mode

fiber between the Transmitter and Receiver, providing a clean, secure and easy

installation with ideal electrical isolation, and immune to electrical hazard and

interference. The 500464 Transmitter may be powered via USB power (with the

included power supply), or from the 5V supplied from pin #18 of the HDMI connector of

the source side only. Note that if the source does not adequately supply this power on its

HDMI connector, then the included power supply must be used.

1.2 Features

Supports the HDMI 2.0 standard

Up to 330ft (100m) over 50/125m multi-mode fiber (OM3) at 4K (4096x2160)

resolution, @ 60Hz refresh rate

Bandwidth of 18Gbps, supporting up to 4K (4096X2160) @ 60Hz

Supports CEC, EDID & HDCP 2.2

High retention HDMI connector to prevent accidental disconnection

Compact Metal Enclosure for a robust and easy installation

1.3 Package Contents

One (1) HDMI 2.0 Fiber Transmitter

One (1) HDMI 2.0 Fiber Receiver

Two (2) Power Supplies, 5VDC @ 1A with interchangeable US, UK & Euro

Blades

Two (2) USB type A to micro USB cables

One (1) User Manual

Notes：Confirm that the product and accessories are all included, if not please contact

your dealer.

HDMI 2.0 Fiber Extender Kit Installation Guide

2. Specifications

Environment

HDMI 2.0

Devices

Plasma, projectors, monitors, Television, PC, laptops, and

servers supporting HDMI.

Transmission

Transparent to the user

Video Bandwidth

18 Gbps (6 Gbps per lane)

Video Resolution

Up to 4096x2160 @ 60Hz

Signals

HDMI 2.0

Connectors per

unit

One (1) HDMI Male Connector

Two (2) LC Optical Connectors

One (1) Micro USB connector for external power

Maximum Distance

330ft (100 m) over 50/125m multi-mode fiber (OM3)

Cable

Two (2) LC multi-mode fibers, having a 50/125m core

Power Supply

Two (2) 110-240V to 5VDC, 1Apower supply with

interchangeable blades for US, UK & Euro

Temperature

Operating: 0° to 50°C Storage: -30° to 70°C

Humidity: Up to 85% non-condensing

Enclosure

Metal

Dimensions

1.02” x 2.83” x 0.57” (26 x 72 x 15 mm)

Weight

1.0 lbs (0.45 kg)

Compliance

Regulatory: FCC, CE, RoHS

Warranty

2 years

Order Information

500464 HDMI 2.0 Fiber Extender Kit

3. System Requirement for Installation

3.1 Hardware requirements

1) A HDMI source and display is required, supporting the graphic resolution of the

HDMI 2.0 Fiber Extender Kit.

2) No special requirements for memory size, CPU speed and chipsets are needed,

assuming the HDMI graphic controllers or cards have already been properly

installed.

HDMI 2.0 Fiber Extender Kit Installation Guide

3.2 Software requirements

No special restrictions, considering that the HDMI graphic controller and OS have

already been properly installed.

3.3 AC/DC Power Adapter (Technical Advisory)

The included power supply adaptors and USB cables can provide power to both the

Transmitter and Receiver. Although the HDMI interface of the source typically provides

5VDC on pin #18 of the HDMI connector, the USB power supply option is recommended

as a more stable power source for the Transmitter.

4. System Connection

4.1 Safety Precautions

This system should be installed in a clean environment with temperature and

humidity within the specified operating levels (see the specifications table).

4.2 System Diagram

HDMI 2.0 Fiber Extender Kit Installation Guide

4.3 Connection Procedure

a) Connect the Transmitter to the source equipment (such as a Blu-Ray Player), and

connect the Receiver to the sink equipment (such as a display). Connect the USB

Power Supply to the Receiver. Power on the HDMI source and display. The

Transmitter will be turned on due to the 5V supplied by pin #18 of HDMI interface

of the source. Even though the units are being powered, it is recommended that

the USB Power Supply be used as well for a more stable power source for the

Transmitter, since some sources may not be capable of providing sufficient power.

b) The Power LED will illuminate when the 500464 is connected to the HDMI

interface of the source and display, and the Status LED will blink three (3) times.

After which the Status LED will blink again once a reliable link is established with

the end equipment.

c) Connect an LC terminated duplex optical fiber between the Transmitter and

Receiver, where each of the individual fibers are connected as (A) to (A) and (B) to

(B). Ensure the duplex connectors are fully inserted and the top LED will begin to

blink.

Position of the LEDs

HDMI 2.0 Fiber Extender Kit Installation Guide

Note1: DO NOT look directly into the LC receptacles of the Transmitter, while it is

powered on, even though this product is strictly regulated to operate under

LASER Class I, classified by CDRH/FDA for eye safety.

Note2: Units support an extension distance up to 100m using OM3 multimode fiber.

Note3: Do not make use of any intermediate cable or adapter between these units or

between these units and the end equipment to avoid any undesirable

performance degradation.

a) Connect the Transmitter directly to the HDMI connector of the source.

b) Connect the Receiver directly to the HDMI connector of the display.

c) These units should be connected together with a single length of duplex

multimode fiber cable meeting the spec herein, while ensuring that the

optical LC connector end-faces are clean.

d) To ensure proper connectivity, confirm that the Status LEDs on both the

Transmitter and Receiver are ON.

HDMI 2.0 Fiber Extender Kit Installation Guide

5. Troubleshooting & Maintenance

The following section describes some of the symptoms, probable causes and possible

solutions in regard to the installation of the 500464 HDMI 2.0 Fiber Extender Kit.

The display only shows a blank (black) screen.

- Ensure that the USB power supplies are firmly connected and that both Transmitter

and Receiver Power LEDs are ON.

- Ensure that the HDMI connectors are firmly plugged into the HDMI connector of the

source and display.

- Ensure that the Transmitter and Receiver modules are plugged in the correct order

to the source and display, respectively (reversing the order will not work).

- Check if the source and display are powered on.

- Ensure that the duplex fiber is properly inserted into both the Transmitter and

Receiver.

- Reset the system by disconnecting and reconnecting the Transmitter HDMI or

Receiver HDMI side units, or by disconnecting and reconnecting the USB power

cables that are plugged in the Transmitter and Receiver modules.

- If necessary try to re-boot the system and re-connect the HDMI 2.0 Fiber Extender

Kit.

Screen is distorted or the display is noisy.

- Check if the graphic resolution is properly set. Go to the display properties and

confirm the settings.

- Ensure that the resolution is set to a maximum of 4K (4096x2160) at 60Hz refresh

ratio.

- Reset the system.

- Disconnect and reconnect the HDMI Fiber Extender Kit units or their power supply

adapters.

If you still cannot diagnose the problem, please call MuxLab Customer Technical

Support at 877-689-5228 (toll-free in North America) or (+1) 514-905-0588

(International).

HDMI 2.0 Fiber Extender Kit Installation Guide

Maintenance

No special maintenance is required for the HDMI 2.0 Fiber Extender Kit and power

adapters. Ensure that the HDMI modules and power adapters are stored or used in an

environment free from high humidity or dust/dirt contamination.

There are no user serviceable parts inside these units. Refer all service and repair

issues to MuxLab.

Technical Support and Service

For commercial or general product support, contact your reseller. For technical service,

contact MuxLab by email [email protected] or visit MuxLab’s website at

www.muxlab.com

Certification of Eye Safety

This laser component is using the following wavelength: 825, 850, 930, 980, 990nm LD

Transceivers, which are all certified by CDRH/FDA referred as classified in Laser Class

1 (IEC60825-1).

Caution –Use of controls, adjustments or performance of procedures other than those

specified herein may result in hazardous radiation exposure.

Tabla de contenidos

Otros manuales de Extensor de MuxLab

MuxLab

MuxLab 500502 Manual de usuario

MuxLab

MuxLab 500465 Manual de usuario

MuxLab

MuxLab 500040 Manual de usuario

MuxLab

MuxLab 500459 Manual de usuario

MuxLab

MuxLab VideoEase 500090 Manual de usuario

MuxLab

MuxLab VideoEase MonoPro XLR Guía del usuario

MuxLab

MuxLab 500757 Manual de usuario

MuxLab

MuxLab 500464-V2 Manual de usuario

MuxLab

MuxLab 500459-100 Manual de usuario

MuxLab

MuxLab 100518 Manual de usuario

MuxLab

MuxLab 500462 Manual de usuario

MuxLab

MuxLab 500800 Manual de usuario

MuxLab

MuxLab VideoEase Manual de usuario

MuxLab

MuxLab 500417 Manual de usuario

MuxLab

MuxLab 500759-TX-HLO Manual de usuario

MuxLab

MuxLab 500041-WP-UK Manual de usuario

MuxLab

MuxLab 500759 Manual de usuario

MuxLab

MuxLab 500070 Manual de usuario

MuxLab

MuxLab 500770-TX Manual de usuario

MuxLab

MuxLab 500733 Manual de usuario

MuxLab

MuxLab Broadcast 500734 Manual de usuario

MuxLab

MuxLab 500770 Manual de usuario

MuxLab

MuxLab ProDigital 500485 Manual de usuario

MuxLab

MuxLab 500451 Manual de usuario

Manuales populares de Extensor de otras marcas

SY HDBT-60T Manual de usuario

Appsys ProAudio

Appsys ProAudio ADX-16 Manual de usuario

Atlona

Atlona RS232 Manual de usuario

IDK

IDK OPF-TH1000-A Manual de usuario

Enable-IT

Enable-IT 824WP Manual de usuario

Worx

Worx Landroid RadioLink WA0864 Hoja de especificaciones

TP-Link

TP-Link TL-WA730RE Manual de usuario

Camplex

Camplex CMX-HDMI-SFPL Manual de usuario

SC&T

SC&T HE03-4K Manual de usuario

Marmitek

Marmitek MegaView70 Manual de usuario

Samsung

Samsung SCS-26UC4 Manual de usuario

Foxun

Foxun SX-GES24 Manual de usuario

foxunhd

foxunhd SX-AEX01 Manual de usuario

TERK Technologies

TERK Technologies LFIRX2 Manual de usuario

Devolo

Devolo Audio Extender Manual

Edimax

Edimax EW-7438RPn V2 Manual de usuario

Shinybow USA

Shinybow USA SB-6335T5 Manual de usuario

SECO-LARM

SECO-LARM ENFORCER EVT-PB1-V1TGQ Manual de usuario
