MUTOH XpertJet XPJ-1641SR Guía del usuario

Site Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Assembling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Connecting Power and Network . . . . . . . . . . . . . . . 13

Printer Initial Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Test printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Installing MUTOH Status Monitor . . . . . . . . . . . . . . 38

Viewing Operation Manual . . . . . . . . . . . . . . . . . . . . 39

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

• Unauthorized copying or duplication of the whole or part of the contents of this Guide is prohibited.

• Every care has been taken in writing the contents of this Guide, but please contact MUTOH or the dealer you purchased the

product from if you find any unclear, erroneous or otherwise unsatisfactory content in the Guide.

• Please be aware that MUTOH will not be liable in any way for failures or accidents that result from handling or operating the

printer according to any procedures other than those set forth in this Guide.

• Company names and product names that appear in this Guide are registered trademarks of the respective companies.

Unpacking and Initial Setup

Startup Guide

XPJ-1641SR / XPJ-1682SR

2 Site Preparation

1 Site Preparation

Choose the location which satisfies the requirements below.

• The floor must be level.

• Avoid vibration from the neighboring devices.

• Low humidity and free from dust.

• Less chance of temperature and humidity changes.

• Avoid direct sunlight.

•Avoidwater.

• Avoid direct air onto the printer.

• Low levels of electromagnetic waves.

The following space is required for installation.

Installation Location Requirements

• Choose the floor that can safely support the weight of this product.

The total weight of printer and stand is 280 kg.

If the floor does not have sufficient load capacity, it can lead to injury from a fall.

• This equipment is not suitable for use in locations where children are likely to be present.

• Keep the work area well ventilated while operating.

Ink odor may cause health problem such as headache, dizziness, or dull. If you experience these symptoms,

stop printer operation and move to fresh air. Seek medical attention if vomit persists.

Minimum Space Requirements

Site Preparation

Connecting Power

and Network

Printer Initial

Setup

Viewing

Operation Manual

Safety

Precautions

Unpacking Assembling Test printing Installing MSMSite Preparation

CAUTION

4,400 mm

2,895 mm

1,000 mm

650 mm

1,000 mm

Rear

Front

Width x Depth:2,750 mm x 895 mm

Height :1,611 mm *1

Printer Size

*1Wheninstallinginkbagcases.

Theroomheightshouldbeatleast

1,760mm.

Site Preparation 3

The installation site must meet the power specification and environmental requirements below.

•Printer:

Input voltage: AC 100V to 120V±10% / AC 200V to 240V±10%

Input frequency: 50 / 60Hz ±1Hz

Input load current: 9 A (AC 100V - 120V), 6 A (AC 200V - 240V)

•Heater:

Input voltage: AC 100V to 120V±10% / AC 200V to 240V±10%

Input frequency: 50 / 60Hz ±1Hz

Input load current: 10 A (AC 100V - 120V), 5 A (AC 200V - 240V)

• Operating condition:

Temperature: 20°C to 32°C, Humidity: 40% to 60%, non condensing

• Printing Condition:

Temperature: 22°C to 30°C, Humidity: 40% to 60%, non condensing

Change rate

Temperature: No more than 2 °C per 1 hour

Humidity: No more than 5% per 1 hour

• Printer Storage Condition:

Without ink filled: Up to 6 months (Temperature: -20°C to 60°C, Humidity: 20% to 80%, non condensing)

With ink filled: Up to 1 week (Temperature: -10°C to 40°C, Humidity: 20% to 80%, non condensing)

Storage up to 4 days maximum when stored between 32 °C to 40 °C.

• Ink Storage Condition:

Black / Cyan / Magenta / Yellow/ Light Cyan / Light Magenta / Light Black (1,000 ml each)

Temperature: -20°C to 40°C, Humidity: 5% to 85%, non condensing

Cleaning bag (300 ml)

Temperature: 5°C to 40°C, Storage up to 6 months maximum when stored between -5 °C to 5 °C or 30 °C to 40 °C.

Humidity: 80% or less non condensing

Power Specification

Important!

This product has two power cords for printer and heater and requires the total load current as follows:

• XPJ-1641SR/XPJ-1682SR: 19 A (AC 100V - 120V),11 A (AC 200V - 240V)

If the total current exceeds the maximum capacity of the wall outlet with two or more jacks, connect one of the two power plugs

into another wall outlet.

Environmental Requirements

Connecting Power

and Network

Printer Initial

Setup

Viewing

Operation Manual

Safety

Precautions

Unpacking Assembling Test printing Installing MSMSite Preparation

4 Unpacking

1Unpacking

Before unpacking, read the instructions below and prepare the necessary items.

• Minimum 4 people are required for unpacking, assembling and installation.

• The items listed below are required for installation and initial setup.

Unpacking Preparation

Use the designated power cords.

Failure to do so may result in electric shock or fire.

Important!

Your computer must meet the following minimum requirements:

• OS: Windows 10 (64bit), Windows 8/8.1 (64bit), Windows 7 (64bit)

• CPU: Intel (R) Core (TM) i5 / i7

• Memory: 8GB minimum

•Network:

XPJ-1641SR: Use a network port that supports Ethernet port, Ethernet cable (Category 5 or later)

XPJ-1682SR: Use a network port that supports Gigabit Ethernet port, Gigabit Ethernet cable (Category 6 or later)

Note

Items marked with an asterisk (*) above are accessories or supplies.

Unpacking

Connecting Power

and Network

Printer Initial

Setup

Viewing

Operation Manual

Safety

Precautions

Unpacking Assembling Test printing Installing MSMSite Preparation

Roll media* : 1

Computer : 1 Power cord : 2

Gigabit

Ethernet cable: 1

（XPJ-1682SR）

Ink bag

(1,000ml)

XPJ-1641SR : 4

XPJ-1682SR : 8

Ink bag case

(1,000ml)

XPJ-1641SR : 4

XPJ-1682SR : 8

* Usable size

Media core diameter: 2 inches or 3 inches

Outer diameter: Φ150 mm or less

Width: 1,000 mm to 1,625 mm

Weight: 30 kg or less

Ethernet

cable : 1

(XPJ-1641SR)

Phillips-head

screwdriver: 1

WARNING

Unpacking 5

Unpack the product.

Unpacking the printer

• Minimum four people are required for unpacking and moving this product.

• When taking out the product from the packing box, remove the plastic sheet wrapped around the

product, then take out the product. Failure to do so may cause slip and damage to the product.

• Keep the product level while moving it.

[1] Open the packing box and take out the items listed below.

Connecting Power

and Network

Printer Initial

Setup

Viewing

Operation Manual

Safety

Precautions

Unpacking Assembling Test printing Installing MSM

Site Preparation

CAUTION

Accessory box

Printerbody

6 Unpacking

[2] Check that the following items are included.

Note

Items marked with an asterisk (*) above are in the accessory box.

Operation Manual CD :1

Cabletie:1

Waste ink tank : 1

Paper towel :5

Cleaning stick :10

Flushing box sponge : 5

Tweezers :1

Inkslotlabel:1

(XPJ-1682SR)

Startup Guide :

Japanese/English (each)

Cleaning wiper :2

Media flange :2Printer :1

Connecting Power

and Network

Printer Initial

Setup

Viewing

Operation Manual

Safety

Precautions

Unpacking Assembling Test printing Installing MSMSite Preparation

Unpacking 7

Unpacking Stand

[1] Open the packing box and take out the items listed below.

[2] Check that the following items are included.

Note

Items marked with an asterisk (*) above are in the accessory box.

Connecting Power

and Network

Printer Initial

Setup

Viewing

Operation Manual

Safety

Precautions

Unpacking Assembling Test printing Installing MSM

Site Preparation

Leg (Left)

Leg (Right)

Foot (x2)

Brace

Stand box

Hex wrench:1

Wing bolt:8

Waste ink tank

holder:1

Round head screw:12

Spring washer:8

Fixing bracket:2

Leg (Right):1

Leg (Left) :1 Brace :1 Foot:2

Hex head bolt :8

8 Assembling

2 Assembling

Follow the steps below to assemble the stand.

Assembling Stand

Minimum two people are required for assembling the stand.

[1] Attach the left leg and right leg to the brace.

• Face the groove on the brace toward the rear side of the printer and attach it to both legs.

• The leg with two warning labels attached is the right leg.

• Put the spring washers on the hex head screws (4 each), then tighten the screws.

[2] Attach the foot to the leg.

• Face the screw holes on the foot toward the front side of the printer and attach it to the leg.

• Put the spring washers on the hex head screws (4 each), then tighten the screws.

• Use the round head screws (×8) to fix the fixing brackets (×2) on the brace and both legs.

Assembling

Connecting Power

and Network

Printer Initial

Setup

Viewing

Operation Manual

Safety

Precautions

Unpacking Assembling Test printing Installing MSMSite Preparation

CAUTION

× 4

Front

Leg (Right)

Warning Label

× 4

× 8

Front

Leg (Right)

Assembling 9

Follow the steps below to attach the printer to the stand.

[3] Use the round head screws (×4) to attach the waste ink tank holder to

the right leg.

[4] Shake the stand to make sure that each part is firmly attached.

[5] Turn the leveling adjusters (×4) as shown on the left until the stand

does not move.

Attaching Printer

• Minimum four people are required for this process.

• When taking out the product from the packing box, remove the plastic sheet wrapped around the

product, then take out the product. Failure to do so may cause slip and damage to the product.

• Keep the product level while attaching.

[1] Lift the printer with at least four people and mount it on the stand.

• Use two lifting bars to insert into the guide holes at the bottom left and right of the printer, and lift up on the stand.

Leg (right)

Screws

Waste ink tank holder

× 4

Stand

Adjusters Adjusters

Connecting Power

and Network

Printer Initial

Setup

Viewing

Operation Manual

Safety

Precautions

Unpacking Assembling Test printing Installing MSMSite Preparation

CAUTION

10 Assembling

Remove packing materials from the product.

Important!

Make sure to remove two front cover locks before opening the front cover. Otherwise it will cause damage to the cover.

(If you do not have lifting bars) Lift the printer with at least four people and mount it on the stand.

• Use the handholds at the front bottom of the printer.

[2] Use the wing bolts (×8) and attach the printer to the stand.

Removing Packing Materials

[1] Remove the packing tapes from all the covers.

[2] (XPJ-1682SR only) Remove two screws each (M3 x 45) to remove two front cover locks.

× 8

Connecting Power

and Network

Printer Initial

Setup

Viewing

Operation Manual

Safety

Precautions

Unpacking Assembling Test printing Installing MSMSite Preparation

× 4

Otros manuales para XpertJet XPJ-1641SR

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora de MUTOH

MUTOH

MUTOH VJ-1324 Manual de usuario

MUTOH

MUTOH VJ-2638 Manual de usuario

MUTOH

MUTOH ValueJet VJ-1638UH Manual de instalación y operación

MUTOH

MUTOH VJ-1324 Manual de usuario

MUTOH

MUTOH Toucan Hybrid PJ-162-FE Manual de usuario

MUTOH

MUTOH Blizzard Manual de usuario

MUTOH

MUTOH ValueJet VJ-1604 Instrucciones de funcionamiento

MUTOH

MUTOH DrafStation RJ-901X Manual de usuario

MUTOH

MUTOH Rockhopper 3 Extreme Instrucciones de funcionamiento

MUTOH

MUTOH RJ600EX-B-01 Manual de usuario

MUTOH

MUTOH VJ-1948WX Guía del usuario

MUTOH

MUTOH Rockhopper 38 Manual de usuario

MUTOH

MUTOH ValueJet VJ-1604W Manual de usuario

MUTOH

MUTOH VJ-2606 Manual de usuario

MUTOH

MUTOH ValueJet VJ-1604 Manual de usuario

MUTOH

MUTOH RJ-6000 Series Manual de usuario

MUTOH

MUTOH ValueJet VJ-1624 Manual de usuario

MUTOH

MUTOH ValueJet VJ1324X Manual de usuario

MUTOH

MUTOH ValueJet VJ-1204 Manual de usuario

MUTOH

MUTOH UniFixer 65 Manual de usuario

MUTOH

MUTOH DrafStation RJ-900X Manual de usuario

MUTOH

MUTOH VJ-1614 Manual de usuario

MUTOH

MUTOH VJ-2638X Manual de usuario

MUTOH

MUTOH vj-1617h Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario
