MSI MS-6507E Manual de usuario

Version 1.0

G52-MA00561

MS-6507E (v1.X) Micro ATX Mainboard

MSI

MICRO-STAR INTERNATIONAL

Manual Rev: 1.0

Release Date: March 2002

FCC-BRadioFrequencyInterferenceStatement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be required to correct

the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party respon-

sible for compliance could void the user’s authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU

RESEAU.

Micro-StarInternational MS-6507E

Testedtocomply

withFCCStandard

ForHome orOffice Use

iii

Edition

March 2002

The material in this document is the intellectual property of MICRO-STAR

INTERNATIONAL. We take every care in the preparation of this document,

but no guarantee is given as to the correctness of its contents. Our products

are under continual improvement and we reserve the right to make changes

without notice.

Trademarks

All trademarks are the properties of their respective owners.

Intel®and Pentium®are registered trademarks of Intel Corporation.

PS/2 and OS®/2 are registered trademarks of International Business Machines

Corporation.

Windows®95/98/2000/NT/XP are registered trademarks of Microsoft

Corporation.

Netware®is a registered trademark of Novell, Inc.

Award®is a registered trademark of Phoenix Technologies Ltd.

AMI®is a registered trademark of American Megatrends Inc.

Revision History

Revision Revision History Date

V1.0 First release March 2002

1. Always read the safety instructions carefully.

2. Keep this User’s Manual for future reference.

3. Keep this equipment away from humidity.

4. Lay this equipment on a reliable flat surface before setting it up.

5. The openings on the enclosure are for air convection hence protects the

equipmentfrom overheating. DONOT COVERTHEOPENINGS.

6. Make sure the voltage of the power source and adjust properly 110/220V

before connecting the equipment to the power inlet.

7. Place the power cord such a way that people can not step on it. Do not

place anything over the power cord.

8. AlwaysUnplugthe PowerCord beforeinserting anyadd-on cardor module.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage or cause electri-

cal shock.

11. If any of the following situations arises, get the equipment checked by a

service personnel:

zThe power cord or plug is damaged

zLiquid has penetrated into the equipment

zThe equipment has been exposed to moisture

zThe equipment has not work well or you can not get it work according

to User’s Manual.

zThe equipment has dropped and damaged

zIf the equipment has obvious sign of breakage

12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT

UNCONDITIONED,STORAGETEMPERATUREABOVE600C(1400F),IT

MAYDAMAGETHEEQUIPMENT.

Safety Instructions

CAUTION: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer.

CONTENTS

Chapter1.GettingStarted ........................................................................ 1-1

Mainboard Specification ......................................................................1-2

Mainboard Layout ...............................................................................1-4

Quick Components Guide ....................................................................1-5

Key Features ........................................................................................1-6

MSI Special Features ...........................................................................1-7

PCAlert™ III .................................................................................1-7

Chapter2.HardwareSetup ....................................................................... 2-1

Central Processing Unit: CPU .............................................................. 2-2

CPU Installation Procedures ......................................................... 2-2

Installing the CPU Fan ..................................................................2-3

CPU Core Speed Derivation Procedure .........................................2-4

Memory................................................................................................2-5

Introduction to DDR SDRAM....................................................... 2-5

DDR Module Combination ............................................................ 2-6

Installing DDR Modules ............................................................... 2-6

Power Supply ....................................................................................... 2-7

ATX 20-Pin Power Connector .......................................................2-7

ATX 12V Power Connector: JPW1 ................................................2-7

BackPanel ............................................................................................2-8

Mouse Connector ......................................................................... 2-8

Keyboard Connector ..................................................................... 2-9

USB Connectors ............................................................................2-9

Serial Port Connector: COM A & COM B ................................... 2-10

Joystick/Midi Connectors ........................................................... 2-10

Audio Port Connectors ............................................................... 2-10

Parallel Port Connector ................................................................ 2-11

LANJack(RJ-45) ......................................................................... 2-12

Connectors......................................................................................... 2-13

Floppy Disk Drive Connector: FDD1........................................... 2-13

Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-14

CD-InConnector:JCD1 ............................................................... 2-15

Aux Line-In Connector: JAUX1 .................................................. 2-15

Modem-In Connector: JPHN1 ..................................................... 2-15

Fan Power Connectors: C_FAN1/S_FAN1 .................................. 2-16

Chassis Intrusion Switch Connector: JCI1 .................................. 2-17

IrDA Infrared Module Header: JIR1 ............................................ 2-17

Wake On Ring Connector: JMDM1 ............................................. 2-18

Wake On LAN Connector: JWOL1.............................................. 2-18

SPDIF Connector: JSP1 ............................................................... 2-19

Front Panel Audio Connector: JAUD1 ........................................ 2-20

Modem Connector: MC1 ............................................................. 2-21

Front Panel Connectors: JFP1 & JFP2 ......................................... 2-22

Front USB Connector: JUSB1 or JUSB2 ...................................... 2-23

Jumpers .............................................................................................. 2-24

Clear CMOS Jumper:JBAT1 ........................................................ 2-24

Slots ................................................................................................... 2-25

AGP (Accelerated Graphics Port) Slot......................................... 2-25

PCI Slots ...................................................................................... 2-25

CNR(Communication NetworkRiser) ......................................... 2-25

PCI Interrupt Request Routing .................................................... 2-26

Chapter3.AWARD® BIOSSetup............................................................ 3-1

Entering Setup......................................................................................3-2

Control Keys ................................................................................. 3-2

Getting Help .................................................................................. 3-3

The Main Menu ................................................................................... 3-4

Standard CMOS Features .................................................................... 3-6

vii

Advanced BIOS Features .................................................................... 3-8

Advanced Chipset Features............................................................... 3-12

Integrated Peripherals ........................................................................ 3-14

Power Management Setup ................................................................. 3-18

PNP/PCI Configurations..................................................................... 3-22

PC Health Status ................................................................................ 3-24

Frequency/Voltage Control ................................................................ 3-25

LoadFail-Safe/OptimizedDefaults ..................................................... 3-27

Set Supervisor/User Password........................................................... 3-28

Glossary ....................................................................................................G-1

Getting Started

1-1

Chapter 1. Getting Started 1

Getting Started

Thank you for purchasing the MS-6507E v1.X Micro ATX mainboard.

The MS-6507E is based on Intel®Brookdale-E & ICH4 chipsets for optimal

system efficiency. Designed to fit the advanced Intel®Pentium®4 processors

in the 478 pin package, the MS-6507E delivers a high performance and profes-

sional desktop platform solution.

TOPICS

Mainboard Specification 1-2

Mainboard Layout 1-4

Quick Components Guide 1-5

Key Features 1-6

MSI Special Features 1-7

Chapter 1

1-2

CPU

Supports Intel®Pentium®4 processor in 478-pin package.

Supports 1.5GHz, 1.6GHz, 1.7GHz, 1.8GHz, 1.9GH z, 2GHz and up.

Chipset

Intel®Brookdale-E chipset

- Support 100MHz/133MHz system clock.

- Intel NetBurst micro-architecture supports 400MHz/533MHz system bus.

- 1.5V AGP interface with 4x data transfer and 4x fast write capability.

Intel®ICH4 chipset

- 2 channel Ultra ATA 100 bus Master IDE controller.

- PCI Master 2.2.

- I/O APIC.

- AC’97 2.2 interface.

- 3 UHCI Host controllers and 1 EHCI Host controller.

MainMemory

Supports four memory banks using two 184-pin DDR DIMM.

Supports up to 2GB PC2100/PC1600 DDR SDRAMs.

Supports 2.5v DDR SDRAM.

Slots

One AGP(Accelerated Graphics Port) slot.

- Support AGP2.0 including 1x/2x/4x AGP data transfer.

- AGP 1.5V support only. No support for 3.3V or Universal AGP connector.

Three PCI 2.2 32-bit Master PCI bus slots (support 3.3V/5V PCI bus interface).

One CNR (Communication Network Riser) slot.

On-BoardIDE

Support Ultra ATA 100/66/33, BMIDE and PIO operation modes.

2 channel ATA 100 IDE controller integrated.

Can connect up to four IDE devices.

On-Board Peripherals

External

- PS2 KBD + PS2 Mouse

- Parallel x 1 + Serial x 2 (COM A + COM B)

- USB 2.0 x 2 + Lan (RJ-45) x 1

Mainboard Specification

Getting Started

1-3

- Game port + Audio (Mic_in, Line_in, Line_out)

Internal

- Floppy port x 1, IDE x 2, ATX 12V Power Connector

- Front Panel (2 x 5 pin, Intel FPIO pin-define + 2 x 4 pin MSI pin-define)

- Front Audio (2 x 5 pin Intel FPIO pin-define)

- USB2.0 pin header x 2 sets (2 x 5 )

- Front IR, Chassis Intrusion, Onboard buzzer, JBAT1

- CPU Fan, System Fan, Audio (CD-in, Aux-in, Modem-in)

- S/PDIF output (1 x 3) with housing

- Modem Header for optional MSI proprietary modem MS6961

Audio

AC97 2.2 interface provided by ICH4

2 channel S/W audio codec

- AC'97 2.2 Compliant

- Meet PC2001 audio performance requirement

LAN(optional)

PCI local bus single-chip Fast Ethernet Controller, RealTek RTL8101L.

- Integrated Fast Ethernet MAC and PHY in one chip.

- Supports 10Mb/s and 100Mb/s auto-negotiation operation.

- Compliance with PCI v2.2.

- Compliance with PC99 and PC2001 standard.

- Supports Wake-On-LAN and remote wake-up.

- Supports ACPI power management.

Modem(optional with LAN)

MSI proprietary design.

BIOS

PnP (Plug & Play) BIOS to detect peripheral devices and expansion cards

automatically.

DMI (Desktop Management Interface) function to record motherboard

specification.

Provide WOL, chassis intrusion and SMBus for system management.

Dimension

Micro-ATX Form Factor (9.6" x 9.1").

Mounting

6 mounting holes.

Tabla de contenidos

Otros manuales de Placa madre de MSI

MSI

MSI PRO B650-P WIFI Manual de usuario

MSI

MSI Z490 GAMING CARBON WIFI Manual de usuario

MSI

MSI 890GXM-G65 MS-7642 Manual de usuario

MSI

MSI 870A-G54 series Manual de usuario

MSI

MSI GAMING PRO MAX X470 Manual de usuario

MSI

MSI 990FXA Manual de usuario

MSI

MSI PM8M2-V Series Manual de usuario

MSI

MSI MS-7395 Manual de usuario

MSI

MSI Intel 500 Series Manual de usuario

MSI

MSI B550 GAMING GEN3 Manual de usuario

MSI

MSI 865PE Neo2-P Platinum Edition Manual de usuario

MSI

MSI 790XT Manual de usuario

MSI

MSI Creator X299 Manual de usuario

MSI

MSI B650M GAMING PLUS WIFI Manual de usuario

MSI

MSI G31M3 Series Instrucciones de uso

MSI

MSI K8MM-V Manual de usuario

MSI

MSI P55A Fuzion Series Manual de usuario

MSI

MSI MPG Z390 GAMING EDGE AC Manual de usuario

MSI

MSI MEG B550 UNIFY-X Manual de usuario

MSI

MSI H310M PRO-VDH Manual de usuario

MSI

MSI MS-6507 Manual de usuario

MSI

MSI PRO H610M-E DDR4 Manual de usuario

MSI

MSI MEG Z690 GODLIKE Manual de usuario

MSI

MSI K7N420 Pro Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
