MSI 990FXA Manual de usuario

990FXA GAMING

Motherboard

G52-78931X1

Chapter 1

Getting Started

Thank you for choosing the 990FXA GAMING Series (MS-7893 v1.X) ATX

motherboard. The 990FXA GAMING Series motherboards are based on

AMD® 990FX & SB950 chipset for optimal system e󰘲ciency. Designed to 󰘰t

the advanced AMD®AM3/ AM3+ processor, the 990FXA GAMING Series

motherboards deliver a high performance and professional desktop platform

solution.

Chapter 1

Packing Contents

* These pictures are for reference only and may vary without notice.

* The packing contents may vary according to the model you purchased.

SATA Cable

Drivers & Utilities

Disc Motherboard

User Guide I/O Shield

Motherboard

SLI Cable

Chapter 1

Assembly Precautions

■The components included in this package are prone to damage from electrostatic

discharge (ESD). Please adhere to the following instructions to ensure successful

computer assembly.

■ Always turn o󰘯 the power supply and unplug the power cord from the power outlet

before installing or removing any computer component.

■Ensure that all components are securely connected. Loose connections may cause

the computer to not recognize a component or fail to start.

■Hold the motherboard by the edges to avoid touching sensitive components.

■It is recommended to wear an electrostatic discharge (ESD) wrist strap when

handling the motherboard to prevent electrostatic damage. If an ESD wrist strap is

not available, discharge yourself of static electricity by touching another metal object

before handling the motherboard.

■Store the motherboard in an electrostatic shielding container or on an antistatic pad

whenever the motherboard is not installed.

■Before turning on the computer, ensure that there are no loose screws or metal

components on the motherboard or anywhere within the computer case.

■Do not use the computer in a high-temperature environment.

■Do not boot the computer before installation is completed. This could cause

permanent damage to the components as well as injury to the user.

■ If you need help during any installation step, please consult a certi󰘰ed computer

technician.

Important

A screwdriver (not included) may be required for computer assembly.

Chapter 1

Motherboard Speci󰘰cations

CPU Support ■Supports AMD®FXTM/ PhenomTM II/ AthlonTM II and SempronTM

processors for the AM3/ AM3+ socket

Hypertransport ■HyperTransport™ 3.0, supports up to 5.2 GT/s

Chipset ■AMD® 990FX & SB950

Memory

Support ■4x DDR3 memory slots supporting up to 32GB

■ Supports DDR3 2133(OC)/ 1866/ 1600/ 1333/ 1066 MHz

■Dual channel memory architecture

Expansion

Slots ■3x PCIe 2.0 x16 slots

- PCI_E2, PCI_E5 support up to PCIe 2.0 x16 speed

- PCI_E4 supports up to PCIe 2.0 x4 speed

■2x PCIe 2.0 x1 slots

■1x PCI slot

Multi-GPU

Support ■Supports 3-Way AMD®CrossFireTM Technology*

■Supports 2-Way NVIDIA®SLITM Technology

* Supports Windows 7 and Windows 8/ 8.1.

Storage ■AMD®SB950 Chipset

- 6x SATA 6Gb/s ports

- Supports RAID 0, RAID1, RAID5 and RAID 10

USB ■AMD®SB950 Chipset

- 14x USB 2.0 ports (8 ports on the back panel, 6 ports

available through the internal USB 2.0 connectors)

■VIA®VL806 Chipset

- 2x USB 3.0 ports available through the internal USB 3.0

connector*

■Asmedia®1142 Chipset

- 2x USB 3.1 ports on the back panel

* These USB 3.0 ports do not support M-Flash recovery function.

Audio ■Realtek®ALC1150 Codec

- 7.1-Channel High De󰘰nition Audio

- Supports S/PDIF output

LAN ■Killer E2205 Gigabit LAN controller*

- 1x LAN port on the backpanel

* The Killer Network Manager is only available for Windows 7 and Windows 8/ 8.1

currently. The supported drivers for other operating systems would be available on

the website if provided by vendor.

Back Panel

Connectors ■1x PS/2 keyboard/ mouse combo port

■8x USB 2.0 ports

■2x USB 3.1 ports

■1x Optical S/PDIF-Out connector

■1x LAN (RJ45) port

■6x OFC audio jacks

Chapter 1

Internal

Connectors ■1x 24-pin ATX main power connector

■1x 8-pin ATX 12V power connector

■6x SATA 6Gb/s connectors

■3x USB 2.0 connectors (supports additional 6 USB 2.0 ports)

■1x USB 3.0 connector (supports additional 2 USB 3.0 ports)

■1x 4-pin CPU fan connector

■2x 4-pin system fan connectors

■2x 3-pin system fan connectors

■1x Front panel audio connector

■2x Front panel connectors

■1x Chassis Intrusion connector

■1x TPM module connector

■1x Serial port connector

■1x S/PDIF-Out connector

■1x Clear CMOS jumper

■1x Slow mode booting switch

I/O Controller ■Fintek 71878 Controller Chip

Hardware

Monitor ■CPU/System temperature detection

■CPU/System fan speed detection

■CPU/System fan speed control

BIOS Features ■ 64 Mb 󰘱ash

■UEFI AMI BIOS

■ACPI 5.0, PnP 1.0a, SM BIOS 2.7, DMI 2.0

■Multi-language

Special

Features ■Military Class 4

■Military Class Essentials

■OC Genie 4

■CLICK BIOS 4

■AMD CrossFire

■NVIDIA SLI

■USB 3.1

■SATA 6Gb/s

■Command Center

■Fast Boot

■GAMING APP

■Super Charger

■Live Update 6

■M-Flash

Software ■Drivers

■MSI

- Command Center

- Live Update 6

- Fast Boot

■7-ZIP

■Sound Blaster Cinema 2

■Killer Network Manager

■Norton Internet Security Solution

Form Factor ■ATX Form Factor

■12 in. x 9.6 in. (30.5 cm x 24.4 cm)

Chapter 1

Connectors Quick Guide

Back Panel

CPU Socket

CPUFAN

DIMM2

JUSB4

JPWR1

SATA1_2

JAUD1

JUSB1

JTPM1

DIMM1

JPWR2

JCI1

SYSFAN1

JBAT1

SATA5_6

JUSB3

JFP2

JFP1

PCI_E1

PCI_E2

PCI_E3

PCI_E4

PCI_E5

SYSFAN2

SYSFAN3

JUSB2

JCOM1

PCI1

SYSFAN4

SATA3_4

SLOW_MODE

DIMM3

DIMM4

JSP1

Chapter 1

Connectors Reference Guide

Port Name Port Type

Back Panel I/O Ports

CPU AM3/ AM3+ Socket

CPUFAN,SYSFAN1~4 Fan Power Connectors

DIMM1~4 DDR3 Memory slots

JAUD1 Front Panel Audio Connector

JBAT1 Clear CMOS Jumper

JCI1 Chassis Intrusion Connector

JCOM1 Serial Port Connector

JFP1, JFP2 System Panel Connectors

JPWR1~2 ATX Power Connectors

JSP1 S/PDIF-Out Connector

JTPM1 TPM Module Connector

JUSB1～3 USB 2.0 Expansion Connectors

JUSB4 USB 3.0 Expansion Connector

PCI1 PCI Expansion Slot

PCI_E1~5 PCIe Expansion Slots

SATA1~6 SATA Connectors

SLOW_MODE Slow Mode Booting Switch

Chapter 1

Back Panel Quick Guide

▶PS/2 Keyboard/ Mouse combo Port

The PS/2®keyboard/ mouse DIN connector for PS/2®keyboard/ mouse.

▶Optical S/PDIF-Out

This S/PDIF (Sony & Philips Digital Interconnect Format) connector is provided for

digital audio transmission to external speakers through an optical 󰘰ber cable.

▶USB 2.0 Port

The USB 2.0 port is for attaching USB 2.0 devices such as keyboard, mouse, or other

USB 2.0-compatible devices.

▶USB 3.1 Port

USB 3.1 port is backward-compatible with USB 3.0/ 2.0 devices. It supports data

transfer rate up to 10 Gb/s (SuperSpeed USB 10 Gbps).

Important

In order to use USB 3.0/ 3.1 devices, you must connect to a USB 3.0/ 3.1 port. If a

USB cable is used, it must be USB 3.0/ 3.1 compliant.

▶LAN Port

The standard RJ-45 LAN jack is for connecting to a Local Area Network (LAN).

LINK/ACT

LED SPEED

LED

LED LED Status Description

Link/ Activity LED

O󰘯 No link

Yellow Linked

Blinking Data activity

Speed LED

O󰘯 10 Mbps connection

Green 100 Mbps connection

Orange 1 Gbps connection

Line-In

Line-Out

Mic

USB 2.0 Port

LAN Port

PS/2 Keyboard/

Mouse combo Port

USB 2.0 Port

USB 3.1 Port RS-Out

CS-Out

SS-Out

Optical

S/PDIF-Out

USB 2.0 Port USB 2.0 Port

Chapter 1

▶Audio Ports

These connectors are used for audio devices.

■Line in: Used for connecting external audio outputting devices.

■Line out: Used as a connector for speakers or headphone.

■Mic: Used as a connector for a microphone.

■RS-Out: Rear surround sound line out in 4/ 5.1/ 7.1 channel mode.

■CS-Out: Center/ subwoofer line out in 5.1/ 7.1 channel mode.

■SS-Out: Side surround sound line out in 7.1 channel mode.
