MSI 845PE-V2 Series Manual de usuario

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to

part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference, in which case the user will be required to correct the

interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party responsible for compliance could void the

user’s authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to comply with the emission

limits.

VOIR LANOTICE D’NSTALLATION AVANT DE RACCORDER AU RESEAU.

Micro-Star International

MS-7154

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired

operation

G52-M7154X1

The material in this document is the intellectual property of MICRO-STAR INTERNATIONAL. We take every

care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our

products are under continual improvement and we reserve the right to make changes without notice.

Trademarks

All trademarks are the properties of their respective owners.

AMD, Athlon™ Athlon™XP, Thoroughbred™ and Duron™ are registered trademarks of AMD Corporation.

Intel® and Pentium® are registered trademarks of Intel Corporation.

PS/2 and OS® 2 are registered trademarks of International Business Machines Corporation.

Microsoft® is a registered trademark of Microsoft Corporation. Windows® 98/2000/NT/XP are registered

trademarks of Microsoft Corporation.

NVIDIA, the NVIDIA logo, DualNet, and nForce are registered trademarks or trademarks of NVIDIA

Corporation in the United States and/or other countries.

Netware® is a registered trademark of Novell, Inc.

Award® is a registered trademark of Phoenix Technologies Ltd.

AMI® is a registered trademark of American Megatrends Inc.

Kensington and MicroSaver are registered trademarks of the Kensington Technology Group.

PCMCIA and CardBus are registered trademarks of the Personal Computer Memory Card International

Association.

Revision History

Revision Revision History Date

V1.0 First release December 2004

iii

Safety Instructions

1. Always read the safety instructions carefully.

2. Keep this User Manual for future reference.

3. Keep this equipment away from humidity.

4. Lay this equipment on a reliable flat surface before setting it up.

5. The openings on the enclosure are for air convection hence protects the equipment from overheating.

Do not cover the openings.

6. Make sure the voltage of the power source and adjust properly 110/220V before connecting the

equipment to the power inlet.

7. Place the power cord such a way that people can not step on it. Do not place anything over the power

cord.

8. Always Unplug the Power Cord before inserting any add-on card or module.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage or cause electrical shock.

11. If any of the following situations arises, get the equipment checked by a service personnel:

- The power cord or plug is damaged.

- Liquid has penetrated into the equipment.

- The equipment has been exposed to moisture.

- The equipment does not work well or you can not get it work according to the User’ Manual.

- The equipment has dropped and damaged.

- The equipment has obvious sign of breakage.

12. Do not leave this equipment in an environment unconditioned, storage temperature above 60° C (140°F),

it may damage the equipment.

Table of Contents

ENGLISH..................................................................1

简体中文...................................................................17

BATT

ICH4

JCD1

JFP2

JFP1

JBAT1

JPUSB1

JUSB1

JAUD1

JCI1

PWR1

SYS_FAN1

CPUFAN1

PCI Slot 2

PCI Slot 1

PCI Slot 3

PCI Slot 4

IDE1

Top: Parallel Port

Bottom:

COMA

Top: Mouse

Bottom: Keyboard

Top: LAN Jack

Bottom: USB

Ports

USB

Ports

Codec

JPW1

T: Line-In

B: Mic

Line-Out

FDD 1

Winbond

W83627THF

Broadcom

BCM4401KQL

AGP Slot

Intel 845PE

BIOS

Introduction

Thank you for purchasing 845PE-V2Series (MS-7154) v1.X Micro ATX mainboard. The 845PE-V2

Series is based on Intel ®845PE & Intel ®ICH4 chipsets and provides 6USB 2.0 ports for high-speed

data transmission. With all these special designs, the 845PE-V2 Series delivers a high performance

and professional desktop platform solution.

Layout

Specifications

CPU

lSocket478forP4processors(Northwood/Prescott)at400MHz/533MHz/800MHz(800MHzfor

overclocking)

lSupportsupto3.4GHzorfaster.

(Forthelatest information aboutCPU,pleasevisit

http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_cpu_support.php )

Chipset

lIntel 845PE

-SupportsFSB 400MHz/533MHz/800MHz(800MHzforoverclocking)

-SupportsDDR266/333/400(DDR400foroverclocking)technology.

lIntel ICH4

-AC97ControllerIntegrated.

-6portsHi-SpeedUSB 2.0controller,480Mb/sec.

-SupportsbothACPI and legacyAPMpowermanagement.

-Legacyfreesupport.

Main Memory

lSupports2memorybanksusingtwo184-pinunbuffered DDR266/333/400(DDR400for

overclocking)DIMMs.

lSupportsupto2GBmemorysizewithoutECC.

(Fortheupdatedsupportingmemorymodules,pleasevisit

http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_trp_list.php )

Slots

lOneAGP(AcceleratedGraphics Port)slot that supportsAGP2.04X/2X.

lFourPCI2.232-bitMasterPCIBusslots(support3.3V/5VPCI businterface).

On-Board IDE

lDual IDEcontrollersintegrated in Intel ICH4.

lSupportsBusMaster, UltraDMA33/66/100operation modes.

lCanconnectuptofourIDEdevices.

On-BoardPeripherals

lOn-BoardPeripheralsincludes:

-1floppyportsupports1FDD with360K,720K,1.2M,1.44Mand 2.88Mbytes.

-1serialport (COMA)

-1parallel portsupportsSPP/EPP/ECPmode

-6USB2.0/1.1ports(Rear*4/ Front *2)

-1Line-In/Line-Out/Mic-Inport

-1RJ-45LANconnector

Audio

lAC97linkcontrollerintegratedinIntel ICH4.

l6channelsS/WaudiocodecAD1888codec

-CompliancewithAC972.2Spec

-MeetsPC2001audioperformancerequirement

LAN

lBroadcom4401PCI2.2LAN

-Supports10Mb/sand100Mb/sauto-negotiation operations.

-CompliancewithPCI2.2andPC99standard.

BIOS

l2MBAwardBIOSwithPNPBIOS,ACPI, SMBIOS2.3, GreenandBoot Block.

lProvidesDMI2.0, WFM2.0,WOL, chassisintrusion,andSMBusforsystemmanagement.

Dimension

lATXFormFactor:30.5cm(L)x17.5cm(W).

Mounting

l6mountingholes.

Rear Panel

The backpanelprovidesthefollowing connectors:

HardwareSetup

ThischaptertellsyouhowtoinstalltheCPU, memorymodules,andexpansioncards,aswellashowto

setupthejumpersonthemainboard. Italsoprovidestheinstructionson connectingtheperipheral

devices,suchasthemouse, keyboard,etc. Whiledoingtheinstallation,becareful in holdingthe

componentsandfollowtheinstallationprocedures.

Central ProcessingUnit: CPU

The mainboardsupportsIntel Pentium4Northwood&Prescott Celeron processorinthe478pin

package.ThemainboardusesaCPUsocketcalled PGA478foreasyCPUinstallation. Whenyouare

installingtheCPU, makesuretheCPUhasaheatsinkandacoolingfanattachedonthetoptoprevent

overheating.If you donot findtheheat sinkandcoolingfan, contactyourdealertopurchaseand install

thembeforeturningonthecomputer. (Forthelatestinformationabout CPU,pleasevisit

http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_cpu_support.php )

ExampleofCPUCore Speed Derivation Procedure

IfCPUClock=133MHz

Core/Busratio =23

thenCPUcorespeed=Host ClockxCore/Busratio

=133MHzx23

=3.06 GHz

Memory Speed/CPUFSBSupportMatrix

Memory

FSB DDR 266 DDR 333 DDR 400*

400MHz OK OK OK

533MHz OK OK OK

800MHz* OK OK OK

*Foroverclockingonly.

MSIRemindsYou...

Overheating

Overheatingwill seriouslydamagethe CPUandsystem,always makesurethe coolingfancanwork

properlytoprotect the CPUfromoverheating.

Replacing theCPU

WhilereplacingtheCPU,always turnoff the ATXpowersupplyorunplugthepowersupply’spower

cordfromgroundedoutlet first toensurethesafetyof CPU.

CPUInstallation Procedures forSocket478

1.Pleaseturnoffthepowerandunplug thepowercordbeforeinstallingtheCPU.

2.Pulltheleversidewaysawayfromthesocket.Makesuretoraisetheleveruptoa90-degree

angle.

3.Lookforthegoldarrow.Thegoldarrowshouldpointtowardstheleverpivot. TheCPUcan only

fit in thecorrectorientation.

4.IftheCPUiscorrectlyinstalled, thepinsshouldbecompletelyembedded intothesocketand

can notbeseen.Pleasenotethatanyviolation of thecorrectinstallationproceduresmaycause

permanentdamagestoyourmainboard.

5.Press theCPUdownfirmlyintothesocket and closethelever.Asthe CPUislikelytomove

whiletheleverisbeing closed,alwaysclosetheleverwithyourfingerspressingtightlyontop of

theCPUtomakesuretheCPUisproperlyandcompletelyembeddedintothesocket.

InstallingtheCPUFan

Asprocessortechnologypushestofasterspeedsandhigherperformance, thermal management

becomesincreasinglyimportant.Todissipateheat,youneedtoattachtheCPUcoolingfanand

heatsinkon top oftheCPU.FollowtheinstructionsbelowtoinstalltheHeatsink/Fan:

1.LocatetheCPUand itsretention mechanismon themotherboard.

2.Positiontheheatsinkontotheretention mechanism.

3.Mount thefan on top oftheheatsink. Press downthefanuntilitsfourclipsgetwedged inthe

holesoftheretentionmechanism.

4.Press thetwoleversdowntofasten thefan. Eachlevercanbepressed downin onlyONE

direction.

5.Connectthefanpowercablefromthemounted fantothe3-pinfan powerconnectoron the

board.

Memory

Themainboardprovidestwo184-pin unbuffered DDR266/DDR333/DDR400SDRAM,andsupportsthe

memorysizeup to2GB.Tooperateproperly,atleastoneDIMMmodulemustbeinstalled. (Forthe

updatedsupportingmemorymodules,pleasevisit

http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_trp_list.php )

Installat least oneDIMMmoduleon theslots.Memorymodulescan beinstalled ontheslotsinany

order.You can install eithersingle-ordouble-sided modulestomeetyourownneeds.

Installing DDRModules

1.The DDR DIMMhasonlyonenotchonthecenterof module.Themodulewillonlyfitintheright

orientation.

2.InserttheDIMMmemorymoduleverticallyintotheDIMMslot.Then pushitinuntilthegolden

fingeron thememorymoduleisdeeplyinserted inthesocket.

3.The plasticclipat eachsideoftheDIMMslot willautomaticallyclose.
