MSI MS-6382 Manual de usuario

Version 2.0

G52-MA00563

MS-6382 (v2.X) Micro ATX Mainboard

MSI

MICRO-STAR INTERNATIONAL

Micro-Star International MS-6382

Tested to comply

with FCC Standard

For Home or Office Use

Manual Rev: 2.0

Release Date: March 2002

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be required to correct

the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party respon-

sible for compliance could void the users authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIR LA NOTICE DINSTALLATION AVANT DE RACCORDER AU

RESEAU.

iii

Edition

March 2002

The material in this document is the intellectual property of MICRO-STAR

INTERNATIONAL. We take every care in the preparation of this document,

but no guarantee is given as to the correctness of its contents. Our products

are under continual improvement and we reserve the right to make changes

without notice.

Trademarks

All trademarks are the properties of their respective owners.

Intel®and Pentium®are registered trademarks of Intel Corporation.

PS/2 and OS®/2 are registered trademarks of International Business Machines

Corporation.

Windows®95/98/2000/NT/XP are registered trademarks of Microsoft

Corporation.

Netware®is a registered trademark of Novell, Inc.

Award®is a registered trademark of Phoenix Technologies Ltd.

AMI®is a registered trademark of American Megatrends Inc.

Revision History

Revision Revision History Date

2.0 First Release for PCB 2.X March 2002

Safety Instructions

1. Read the safety instructions carefully.

2. Save this Users Guide for possible use later.

3. Keep this equipment away from humidity.

4. Lay this equipment on a stable and flat surface before setting it up.

5. The openings on the enclosure are used for air convection and to prevent

the equipment from overheating. Note: Do not cover the openings.

6. Make sure that the power voltage is within its safety range and has been

adjusted properly to the value of 110/220V before connecting the equip-

ment to the power inlet.

7. Place the power cord in a way that people are unlikely to step on it. Do not

place anything on the power cord.

8. Always unplug the power cord before inserting any add-on card or module.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage the equipment

or cause an electrical shock.

11. If any of the following situations arises, get the equipment checked by a

service personnel:

lthe power cord or plug is damaged

lliquid has penetrated into the equipment

lthe equipment has been exposed to moisture

lthe equipment has not work well or you can not get it work according

to Users Guide

lthe equipment was dropped and damaged

lthe equipment has obvious signs of breakage

12. Do not leave the equipment in an unconditioned environment with a stor-

age temperature of 600 C (1400F) or above, which may damage the

equipment.

CAUTION: To prevent explosion caused by improper battery

replacement, use the same or equivalent type of battery recommended

by the manufacturer only.

CONTENTS

Chapter 1. Getting Started ........................................................................ 1-1

Mainboard Specification ...................................................................... 1-2

Mainboard Layout ............................................................................... 1-4

Quick Components Guide .................................................................... 1-5

Chapter 2. Hardware Setup ....................................................................... 2-1

Central Processing Unit: CPU .............................................................. 2-2

CPU Installation Procedures ......................................................... 2-2

Thermal Issue for CPU .................................................................. 2-3

CPU Core Speed Derivation Procedure ......................................... 2-3

Memory ................................................................................................ 2-4

Introduction to DDR SDRAM ....................................................... 2-4

DDR Module Combination ............................................................ 2-5

Installing DDR Modules ............................................................... 2-5

Power Supply ....................................................................................... 2-6

ATX 20-Pin Power Connector: JWR1 ............................................ 2-6

Back Panel ............................................................................................ 2-7

Mouse Connector ......................................................................... 2-7

Keyboard Connector ..................................................................... 2-8

USB Connectors ............................................................................ 2-8

Serial Port Connectors: COM A & COM B.................................... 2-9

Joystick/Midi Connectors ............................................................. 2-9

Audio Port Connectors ................................................................. 2-9

Parallel Port Connector: LPT1 ...................................................... 2-10

RJ-45 LAN Jack (optional) ........................................................... 2-11

Connectors ......................................................................................... 2-12

Floppy Disk Drive Connector: FDD1........................................... 2-12

Chassis Intrusion Switch Connector: J1 ...................................... 2-12

Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-13

CD-In Connector: CD_IN ............................................................ 2-14

Aux Line-In Connector: AUX_IN ................................................ 2-14

Modem-In Connector: MODEM_IN ........................................... 2-14

Fan Power Connectors: CFAN1/SFAN1 ...................................... 2-15

Power Saving LED Connector: JGL1 ........................................... 2-16

Power Saving Switch Connector: JGS1........................................ 2-17

IrDA Infrared Module Header: FPIR ........................................... 2-17

Front Panel Audio Connector: JAUD1 ........................................ 2-18

Front Panel Connectors: JFP1 & JFP2 ......................................... 2-19

Front USB Connector: USB1 ....................................................... 2-20

Jumpers .............................................................................................. 2-21

Clear CMOS Jumper: JBAT1 ........................................................ 2-21

CPU Clock Frequency Selection: SW1 ........................................ 2-22

Slots ................................................................................................... 2-23

AGP Slot ...................................................................................... 2-23

PCI Slots ...................................................................................... 2-23

CNR (Communication Network Riser) ......................................... 2-23

PCI Interrupt Request Routing .................................................... 2-24

Chapter 3. AWARD® BIOS Setup ............................................................ 3-1

Entering Setup...................................................................................... 3-2

Control Keys ................................................................................. 3-2

Getting Help .................................................................................. 3-3

The Main Menu ................................................................................... 3-4

Standard CMOS Features .................................................................... 3-6

vii

Advanced BIOS Features .................................................................... 3-8

Advanced Chipset Features............................................................... 3-12

Integrated Peripherals ........................................................................ 3-16

Power Management Setup ................................................................. 3-21

PNP/PCI Configurations..................................................................... 3-26

PC Health Status ................................................................................ 3-29

Frequency/Voltage Control ................................................................ 3-30

Load Fail-Safe/Optimized Defaults ..................................................... 3-31

Set Supervisor/User Password ........................................................... 3-32

Glossary .................................................................................................... G-1

Getting Started

1-1

Chapter 1. Getting Started 1

Getting Started

The MS6382 v2.X Micro-ATX mainboard is a high performance

computer mainboard based on VIA KT266A & VT8233A chipsets. The

KT266A chipset is ideal for high quality and high integration desktop and

notebook AGP/PCI/LPC computer systems based on Socket A processors.

The VT8233A V-Link Client controller is a highly integrated PCI/LPC

controller. It supports three PCI slots of arbitration and decoding for all

integrated functions and LPC bus.

For sophisticated power management, the KT266A chipset provides

independent clock stop control for the SDRAM, PCI buses and Dynamic

CKE control for powering down of the SDRAM. A seperate suspend-well

plane is implemented for the SDRAM control signals for the Suspend-to-

DRAM operation.

TOPICS

Mainboard Specification 1-2

Mainboard Layout 1-4

Quick Components Guide 1-5

Chapter 1

1-2

Mainboard Specification

CPU

Socket 462 (Socket A) for AMD®DuronTM/AthlonTM processor with 200/

266MHzFSB

Support 600MHz up to 1.5GHz processor

Chipset

VIA®KT266A Chipset

- Support 66MHz V-Link Host interface with peak bandwidth of 266MB/s

- Advanced ECC memory controller supporting PC133/PC100 SDR

SDRAM and PC2100/1600 DDR SDRAM

- Full featured AGP Controller: AGP v2.0 compliant

VIA®VT8233A Chipset

- High bandwidth V-Link client controller

- Integrated faster Ethernet controller

- Direct sound ready AC97 digital audio controller

- Ultra DMA 33/66/100/133 master mode EIDE controller

- Support both ACPI and legacy APM power management

Clock Generator

Cypress CY28341OC rev. D (support 2 DDR DIMM)

MainMemory

Support four memory banks using two 184-pin (100/133MHz) DDR DIMM

Support a maximum memory size of 2GB

Slots

One (Accelerated Graphics Port) AGP slot

One CNR (Communication Network Riser) slot

Three 32-bit Master PCI Bus slots

- 3rd PCI with MEDION specification reserved

Supports 3.3v/5v PCI bus Interface

On-BoardIDE

Dual Channel master mode IDE controller on the VIA®VT8233A Chipset

provides IDE HDD/CD-ROM with PIO, Bus Master and Ultra DMA 33/66/

100/133 operation modes

Can connect up to four IDE devices

Getting Started

1-3

Audio

2 channels S/W Audio CODEC, Realtek ALC201A

AC97s digital link controller was integrated in VIA VT8233A

On-Board Peripherals

On-Board Peripherals include:

- 1 floppy port supports 2 FDD with 360K, 720K, 1.2M, 1.44M and 2.

88Mbytes.

- 2 serial ports (COMA + COM B)

- 1 parallel port supports SPP/EPP/ECP mode

- 4 USB ports (2 x Rear / 2x Front)

- 1 Audio/Game port

- 1 optional RJ-45 LAN jack (Reaktek RTL8100BL)

BIOS

The mainboard BIOS provides Plug & Play BIOS which detects the

peripheral devices and expansion cards of the board automatically.

The mainboard provides a Desktop Management Interface (DMI) func-

tion which records your mainboard specifications.

Dimension

M-ATX Form Factor: 9.6 in. x 8.25 in.

Mounting

6 mounting holes

Others

Support STR/STD (S3/S4)

Support PS2/USB KBD/Mouse Wakeup function in S3 mode

PC 2001 Compliance

Support Chassis Intrusion Detection & SIR

Otros manuales para MS-6382

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Placa madre de MSI

MSI

MSI PRO B550M-VC WIFI Manual de usuario

MSI

MSI MICRO ATX AL12 Manual de usuario

MSI

MSI B450 TOMAHAWK MAX Manual de usuario

MSI

MSI MS-7226 (V1.X) Manual de usuario

MSI

MSI GAMING PLUS MPG Z590 Manual de usuario

MSI

MSI A320M PRO-M2 V2 Manual de usuario

MSI

MSI MAG B550M MORTAR WIFI Manual de usuario

MSI

MSI H61MU-E35 series Manual de usuario

MSI

MSI G31M2 V2 Manual de usuario

MSI

MSI 845 Pro Manual de usuario

MSI

MSI MAG B550 TOMAHAWK Manual de usuario

MSI

MSI B460M PRO-VDH WIFI Manual de usuario

MSI

MSI X570-A PRO Manual de usuario

MSI

MSI MAG B660 TOMAHAWK WIFI DDR4 Manual de usuario

MSI

MSI G4m-P23 Manual de usuario

MSI

MSI K8N Neo Platinum Manual de usuario

MSI

MSI PRO B660M-A CEC WIFI Manual de usuario

MSI

MSI MAG Z390 TOMAHAWK Manual de usuario

MSI

MSI 865G Neo2 Manual de usuario

MSI

MSI 915GVM-V Manual de usuario

MSI

MSI PRO A620M-E Manual de usuario

MSI

MSI 645 Ultra Manual de usuario

MSI

MSI Z87-G43 GAMING Manual de usuario

MSI

MSI G52-74111X2 Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
