MrHeater MHVFGH30LPBT Instrucciones de montaje

OPERATING INSTRUCTIONS

AND OWNER’S MANUAL

INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.

Model #

MR. HEATER, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 · 800-251-0001

WARNING:

- WHAT TO DO IF YOU SMELL GAS

WARNING

2018 - CB

UNVENTED LP-GAS FIRED GARAGE HEATER

30,000 BTU Blue Flame Heaters

READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe

place for future reference. Do not allow anyone who has not read these instructions to assemble,

light, adjust or operate the heater.

CAUTION:

MHVFGH30LPBT

MHVFGH30LPT

2Installation Instructions and Owner’s Manual

Unvented LP-Gas Vent Free Heaters

IMPORTANT

WARNING:

WARNING: Do not use any accessory not

WARNING:

•

CONTENTS

WARNINGS ........................................................................2

SPECIFICATIONS ................................................................3

PRECAUTIONS ...................................................................3

IGNITION SYSTEM BATTERY INSTALLATION ......................4

BLOWER FAN CONTROL SWITCH OPERATION ...................4

DETERMINING THE TYPE OF HEATER LOCATION SPACE ....5

INSTALLATION ...................................................................6

FASTENING HEATER TO WALL ...........................................7

FLOOR MOUNTING AWAY FROM WALL ...........................8

CONNECTING TO GAS SUPPLY ..........................................8

OPERATING YOUR HEATER ..............................................10

CLEANING AND MAINTENANCE ......................................12

TROUBLESHOOTING ................................................... 13-14

EXPLODED-VIEW PARTS DRAWING ..................................15

PARTS LIST ......................................................................15

WARRANTY ....................................................................16

CAUTION: Never connect heater directly

to the Propane supply. This heater requires

an external regulator (not supplied). Install

the external regulator between the heater and

Propane/LP supply.

The installer must supply an external

regulator. The external regulator will reduce

the incoming gas pressure to between 11

and 14 inches of water. If you do not reduce

incoming gas pressure heater regulator

damage could occur. Install external regulator

with the vent pointing down. Pointing the

vent down protects it from freezing rain or

sleet.

In order to provide the best service possible Mr. Heater is now giving you

more ways to get in touch with us:

WEBSITE: Mr. Heater’s full line of product are now at:

WWW.MRHEATER.COM

FACEBOOK: Find us on Facebook

TWITTER: Find us on twitter

YouTube: There are now informational videos on YouTube.

SOCIAL MEDIA

3Installation Instructions and Owner’s Manual

Unvented LP-Gas Vent Free Heaters

Operating heater above elevations of 4,500 feet

could cause pilot/ODS to shutdown heater.

DANGER

Carbon Monoxide Poisoning:

Propane/LP Gas:

PRECAUTIONS:

Fresh Air for

Combustion and Ventilation

WARNING:

•

stored

•

SPECIFICATIONS

30,000

LP-Gas Only

Yes

Sides

**Operating heater above elevations of 4,500 feet could cause pilot/ODS to shutdown heater.**

4Installation Instructions and Owner’s Manual

Unvented LP-Gas Vent Free Heaters

Product Features

Figure 1

SAFETY DEVICE

IGNITION SYSTEM / BATTERY INSTALLATION

(AA Battery included)

To install or replace battery unscrew the igniter cap

(red button), insert battery positive (+) terminal up

and replace cap.

(AA Battery included)

THERMOSTATIC CONTROL

BLOWER FAN CONTROL SWITCH OPERATION

LOCAL CODES

Installation must conform to local codes or in the

UNPACKING

FRESH AIR FOR COMBUSTION AND

VENTILATION

WARNING

ESTABLISHING ADEQUATE VENTILATION

National Fuel Gas

Code, NFPA 54/ ANSI Z223.1, Section 5.3, Air for

Combustion and Ventilation

Unusually Tight Construction

Ventilation Air

from Outdoors

where:

windows and doors, and

If your home does not meet all of the three criteria

Determining the Type of Heater Location

Space

The National Fuel Gas Code, NFPA 54/ ANSI Z223.1

Ignitor Button

Control Knob

Grill

Front Panel

Burners

Heater

Cabinet

Fan Blower

Switch

(located on back

of heater)

5Installation Instructions and Owner’s Manual

Unvented LP-Gas Vent Free Heaters

DETERMINING THE TYPE OF HEATER

LOCATION SPACE:

Note:

WARNING:

National Fuel Gas Code, NFPA 54/ ANSI Z223.1,

You must provide additional fresh air. Your options

are as follows:

VENTILATION AIR

Ventilation from Inside Building

Ventilation

Gills into

Adjoining

Room -

Option 1

Ventilation Gills into

Adjoining Room - Option 2

12”

Or remove

door into

Adjoining

Room -

Option 3

OUTLET

Figure 2.

Figure 3.

6Installation Instructions and Owner’s Manual

Unvented LP-Gas Vent Free Heaters

LOCATING HEATER

•

CAUTION:

WARNING:

•

• In windy or drafty areas

WARNING:

Ventilation from Outdoors

*IMPORTANT:

IMPORTANT: Vent-free heaters add moisture to

INSTALLATION

NOTICE: -

WARNING:

CHECK GAS TYPE

Use only LP-gas. LP-gas, do

THIS INSTALLATION REQUIRES:

•

7Installation Instructions and Owner’s Manual

Unvented LP-Gas Vent Free Heaters

Figure 4

FASTENING HEATER TO WALL

Mounting Bracket

Figure 5

Figure 6

WARNING: Maintain minimum clearances shown in

Figure 7

Note:

Adjoining Wall

18” Min.

SEE CLEARANCE

SPECIFICATIONS ON PG. 3

16” (Lg)

12-9/64” (Sm)

Mark mounting hole locations

and drill holes where indicated.

Allow for minimum clearances

Left

Side

from sides

Floor

Mounting

Bracket

8Installation Instructions and Owner’s Manual

Unvented LP-Gas Vent Free Heaters

Figure 8.

Figure 9.

Figure 10

Horizontal Slots

Mounting Bracket

mounted to wall

FLOOR MOUNTING AWAY FROM WALL:

Figure 11

CONNECTING TO GAS SUPPLY

WARNING:

Screw

hole

Screw

hole

9Installation Instructions and Owner’s Manual

Unvented LP-Gas Vent Free Heaters

CAUTION:

IMPORTANT:

CAUTION: LP-Gas

IMPORTANT:

CHECKING GAS CONNECTIONS

WARNING:

PRESSURE TESTING GAS SUPPLY PIPING

SYSTEM

Figure 12

10 Installation Instructions and Owner’s Manual

Unvented LP-Gas Vent Free Heaters

Pressure Testing Heater Gas Connections:

Operating Your Heater

To Turn OFF Gas to Appli-

ance ELECTRICAL WIRING DIAGRAM:

WARNING:

OPERATING YOUR HEATER

FOR YOUR SAFETY READ BEFORE LIGHTING

WARNING: If you do not follow these instructions

WHAT TO DO IF YOU SMELL GAS

•

• Do not touch any electrical switch; do not use any

•

Control Valve

Equipment

To regulated propane

source

Figure 13

Figure 14

Equipment

Open

Closed

Figure 15

Caution:

to disconnection

errors can
