MP-Man MP-FUB30 Manual de usuario
DIGITAL MUSIC PLAYER
MP3&WMA
USER MANUAL
MP-FUB30
www.mpmaneurope.com
___________________________________________________________________
Before connecting, operating or adjusting this product please read these
instructions completely.
The player characteristics
♠Supports MP3 and WMA music format.
♠Supports USB function
♠Supports two lines of lyrics display synchronization
♠Big display (128*32) LCD display
♠Voice equalizer
♠GUI (graphical user interfaces).
Inside the box:
(1) MP3 player one
(2) Stereo earphone one pair
(3) Installation disk one
(4) User’s manual one
(5) USB cable one
(6) Battery 1.5V/”AAA” one
PCneeds
(1) Pentium 100 MHz or faster
(2) Windows 98/2000/ ME/XP
(3) USB port
(4) 4 X CD- ROM driver or higher
(5) 15 MB of free space on harddisk
(6) 32 MB system memory
1.1 The player appearance interface
1.2 The buttons
(1) PLAY “” ⇒OPEN/PLAY/PAUSE/STOP/POWER OFF
(2) “REC” ⇒Rec/A-B
(3) “HOLD” ⇒Keyboard lock switch
(4) “VOL-”⇒Volume decrease/fast decrease
(5) “VOL+”⇒Volume increase/fast increase
(6) “” ⇒NEXT/FWD
(7)“” ⇒PREV/REV
(8) “MODE” ⇒Switch modes, menu selection by pressing on button
(9) ⇒USB interface
(10) LCD⇒Liquid crystal display
(11) PHONE “” ⇒Earphone input jack
(12) MIC ⇒Built-in microphone
(13) ⇒USB cover
(14) ⇒Cord hole
(15) ⇒battery cover
1.3 Push-button definition
Push-button includes four operation methods as short push, long push, push and hold, single
push.
1.4 Display
This player adopts big LCD of 128*32
2 Operating instruction
2.1 Turning on the MP3 player
Push the “PLAY” button for several seconds. The LCD display will light up.
2.2 Main menu
Press the “MODE” button for several seconds, from any point in the menu, and the
player returns automatically back to the main menu.
Four options:
- 1) MUSIC
- 2) RECORD
- 3) VOICE REPLAY
4) SYSTEM
Music
Record
Replay
System
You can switch between options by sliding the “MODE” button right “”or left “”.
Then push shortly on the “MODE” button to enter the submenu or confirm a function.
2.3 “Music” mode
Select “Music” mode in the main menu.
2.3.1 Stop submenu
Press "Mode" button once to enter the stop submenu.
Four options:
- Local Folder
- Delete file
- Delete all
- Exit
2.3.1.1 Local folder
主盘目录
X
X
Local folde
r
Files can be stored in different folders (maximum 10 folders including root folder).
Create new folders in Windows explorer when MP3 is connected.
Open “external drive”.
Create new folder
- Press "Mode" button to open Local folder
- Move mode button left or right to select the catalog
- Press “Mode” button to confirm
2.3.1.2 Delete file
2.3.1.3 Delete all
Deletes all files of the current catalog
2.3.2 Play submenu
During playback, press "MODE "button to enter "Play submenu “:
Six options:
- Repeat
- Equalizer
- Tempo Rate
- Replay
- Replay times
- Replay gap
- Exit
2.3.2.1 Repeat
Normal All songs are played once
Repeat One Repeats the current song
Folder Plays all the music of a specific folder
Repeat Folder Repeats the music of a specific folder
Repeat All Repeats all the music.
Random Plays music at random.
Intro First 10 seconds of each song is played.
2.3.2.2 Equalizer
Seven options: - Natural
- - Rock
- - Pop
- - Classic
- - Soft
- - Jazz
-DBB
2.3.2.3 Tempo Rate
The music can be played faster or slower (only with MP3 files)
Change the rate by pushing the “Mode” Button left or right.
2.3.2.4 Replay mode
- A-B replay
When replay mode is selected, the A-B icon is visible .
Select the start point A (flashing) by sliding “Mode” button right.
Select the end point B(flashing) by sliding “Mode” button right.
The A-B section will be repeated continuously
Press “Mode” button to return to normal playback
-During replay, the play-rate can be changed with VOL+ or VOL-".
- Adding your voice to the A-B section
During playback of the A-B section, slide “Mode” button to the right. The microphone icon
appears and your voice is recorded. Slide “Mode” button right again to stop the
recording.
The A-B section + the voice recording will be repeated
2.3.2.5 Replay times
Here you are able to choose how many times (1-10) the A-B section will be repeated.
2.3.2.6 Replay gap
Choose the time (1-10 sec) between each A-B section.
2.3.3 Lyrics
This MP3 player supports "*. lrc "Lyric files
Lyrics can be downloaded from the internet. Make sure that lrc-file has the same name as the
corresponding song. For example:
If the song name is “Yesterday.mp3 “, the lyric file should be named “Yesterday.lrc”
MP3 and LRC file must be stored in the same folder!
No Lyric
Lyric included
Attention: A lyric can not be larger then 500 words.
2.4 Record mode
-Select "Record mode " in the main menu.
The unit can store 99 recordings in each folder with a maximum of 10 folders (including root
folder)
- Press “PLAY” button to start recording.
- Press “PLAY” button again to pause the recording (Time flashes).
- Press “PLAY” again to continue recording.
- Press and hold the “PLAY” button to stop recording.
2.4.1 Record submenu
In the Record mode, press mode button once
3 options:
- Local folder
- REC type
- Exit
2.4.1.1 Local folder
cfr 2.3.1.1
2.4.1.2 REC type
Four options:
- “Fine REC”: high quality recording, wav format, good quality.
- “Long REC”: lower quality recording, act format, uses less space
- “Fine VOR”: wav format
- “Long VOR”: act format
When using “VOR recording”, the player enters into the state of “pause recording” if
no sound is detected by the microphone. Recording starts again when sound is
detected.
2.5 Replay mode
In this mode you can listen to the recordin s created in “Record mode”g
Select in the main menu "Replay mode ".
2.5.1 Replay stop submenu
When playback is stopped, press “Mode” button to enter the Replay submenu.
2.5.1.1 Local folder (Stop submenu)
cfr 2.3.1.1
2.5.1.2 Delete file (Stop submenu)
2.5.1.3 Delete all (Stop submenu)
Deletes all files of the current catalog
