Moxa Technologies UC-7101 Instrucciones de uso

UC-7101

Hardware User’s Manual

Second Edition, June 2008

www.moxa.com/product

Reproduction without permission is prohibited.

UC-7101 Hardware User’s Manual

The software described in this manual is furnished under a license agreement and may be used only in

accordance with the terms of that agreement.

Reproduction without permission is prohibited.

Trademarks

MOXA is a registered trademark of Moxa Inc.

All other trademarks or registered marks in this manual belong to their respective manufacturers.

Disclaimer

Information in this document is subject to change without notice and does not represent a commitment on the

part of Moxa.

Moxa provides this document “as is,” without warranty of any kind, either expressed or implied, including, but

not limited to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this

manual, or to the products and/or the programs described in this manual, at any time.

Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no

responsibility for its use, or for any infringements on the rights of third parties that may result from its use.

This product might include unintentional technical or typographical errors. Changes are made periodically to the

information in this manual to correct such errors, and these changes are incorporated into new editions of the

publication.

Technical Support Contact Information

www.moxa.com/support

Moxa Americas:

Toll-free: 1-888-669-2872

Tel: +1-714-528-6777

Fax: +1-714-528-6778

Moxa China (Shanghai office):

Toll-free: 800-820-5036

Tel: +86-21-5258-9955

Fax: +86-10-6872-3958

Moxa Europe:

Tel: +49-89-3 70 03 99-0

Fax: +49-89-3 70 03 99-99

Moxa Asia-Pacific:

Tel: +886-2-8919-1230

Fax: +886-2-8919-1231

Table of Contents

Chapter 1 Introduction..................................................................................................1-1

Overview.................................................................................................................................. 1-2

Package Checklist .................................................................................................................... 1-2

Product Features ...................................................................................................................... 1-3

Product Specifications ............................................................................................................. 1-3

Hardware Specifications............................................................................................... 1-3

Software Specifications—UC-7101 (μClinux)............................................................. 1-4

Hardware Block Diagrams....................................................................................................... 1-5

Chapter 2 Hardware Introduction.................................................................................2-1

Appearance .............................................................................................................................. 2-2

Dimensions .............................................................................................................................. 2-3

Panel Views.............................................................................................................................. 2-4

LED Indicators......................................................................................................................... 2-5

Internal SD Socket ................................................................................................................... 2-5

Additional Functions................................................................................................................ 2-5

Reset Button ................................................................................................................. 2-5

Real Time Clock........................................................................................................... 2-6

Chapter 3 Hardware Connection Description .............................................................3-1

Wiring Requirements ............................................................................................................... 3-2

Connecting the Power................................................................................................... 3-2

Grounding the UC-7101 Embedded Computer ............................................................ 3-2

Connecting Data Transmission Cables .................................................................................... 3-3

Connecting to the Network........................................................................................... 3-3

Connecting to a Serial Device ...................................................................................... 3-4

Serial Console Port ....................................................................................................... 3-4

Installing a Secure Digital (SD) Memory Card........................................................................ 3-4

Chapter 1 Introduction

The Moxa UC-7101 series of embedded computers are mini, RISC-based, box-type computers that

feature 10/100 Mbps Ethernet ports, RS-232/422/485 serial ports, and an ARM9 processor. The

computers come with Linux pre-installed. In addition, the UC-7101 has an internal SD socket for

storage expansion to offer high performance communication with unlimited storage in a

super-compact, palm-size box. The UC-7101 series of embedded computers are the right solution

for embedded applications that call for a small computer, but that can store large amounts of

memory and provide good computing performance.

In this chapter, we cover the following topics:

Overview

Package Checklist

Product Features

Product Specifications

¾Hardware Specifications

¾Software Specifications—UC-7101 (μClinux)

Hardware Block Diagrams

UC-7101 Hardware User’s Manual Introduction

Overview

The UC-7101 series of mini, RISC-based communication platforms are ideal for embedded

applications. All computers in the series come with RS-232/422/485 serial ports and 10/100 Mbps

Ethernet LAN ports to provide users with a versatile communication platform.

The UC-7101 series computers use the Moxa ART ARM9 192 MHz RISC CPU. Unlike the x86

CPU, which uses a CISC design, the ARM9’s RISC design architecture and modern

semiconductor technology provide these computers with a powerful computing engine and

communication functions, but without generating too much heat. The built-in NOR Flash ROM (8

MB for UC-7101) and SDRAM (16 MB for UC-7101) give you plenty of storage capacity, and the

SD socket provides greater flexibility for running various applications. The LAN ports built into

the ARM9 allow the UC-7101 computers to be used as communication platform for basic data

acquisition and protocol conversion applications, and the RS-232/422/485 serial ports allow you to

connect a variety of serial devices.

The UC-7101 comes with the µClinux operating system pre-installed. Software written for desktop

PCs is easily ported to the UC-7101 computers with a GNU cross complier, so that you will not

need to spend time modifying existing software code. The operating system, device drivers, and

your own software can all be stored in the computers’ Flash memory.

Package Checklist

The UC-7101 series currently includes two models:

Standard Operating Temperature Models (-10 to 60°C)

UC-7101-LX

Mini RISC-based Ready-to-Run Embedded Computer with 1 Serial Port, 1 Ethernet Port,

μClinux OS.

Wide Operating Temperature Models (-40 to 75°C)

UC-7101-T-LX

Mini RISC-based Ready-to-Run Embedded Computer with 1 Serial Port, 1 Ethernet Port,

μClinux OS, Wide Temperature.

Each model is shipped with the following items:

y1 UC-7101

yQuick Installation Guide

yDocument & Software CD

y100 cm RJ45-to-RJ45 Ethernet cross-over cable

y100 cm console port cable (CBL-4PINDB9F-100)

yUniversal Power Adaptor

yProduct Warranty Statement

Optional Accessories

y35 mm DIN-Rail Mounting Kit (DK-35A)

NOTE: Please notify your sales representative if any of the above items are missing or damaged.

1-2

UC-7101 Hardware User’s Manual Introduction

Product Features

The UC-7101 series computers have the following features:

yMoxa ART ARM9 32-bit 192 MHz processor

y16 MB RAM (about 12 MB of user programmable space)

y8 MB Flash ROM (about 4 MB of user programmable space)

yOne 10/100 Mbps Ethernet port for network redundancy

yOne software-selectable RS-232/422/485 ports

ySelect Any Baudrate from 50 bps to 921.6 Kbps

ySD socket for storage expansion

yBuilt-in RTC, Buzzer, WDT

yBuilt-in μClinux Kernel 2.6 platform

y-40 to 75oC wide temperature models available

yDIN-Rail or wall mountable

yRobust fanless design

Product Specifications

Hardware Specifications

System

CPU Moxa ART ARM9 32-bit RISC CPU, 192 MHz

DRAM UC-7101: 16 MB

Flash UC-7101: 8 MB

Storage Expansion UC-7101: SD slot ¯1

Console port RS-232 ¯1 (TxD, RxD, GND), 4-pin header output, “19200, n, 8, 1”

Button Reset button ¯1, supports “Reset to Factory Default”

Other RTC, buzzer, Watchdog Timer

OS UC-7101: Built-in μClinux, based on Linux Kernel 2.6

Network Communication

LAN UC-7101: 10/100 Mbps RJ45 ¯1, auto-sensing

Protection 1.5 KV built-in magnetic isolation protection

Serial Communication

Serial Port UC-7101: Software-selectable RS-232/422/485 DB9 male ¯1

Protection 15 KV built-in ESD protection for all signals

Data bits 5, 6, 7, 8

Stop bit(s) 1, 1.5, 2

Parity None, Even, Odd, Space, Mark

Flow Control RTS/CTS, XON/XOFF, RS-485 ADDC™

Speed 50 bps to 921.6 Kbps; ANY BAUDRATE supported

LEDs

System Ready ¯1

LAN 10 M/Link¯1, 100 M/Link ¯1 (located on RJ45 connector)

Serial TxD ¯1, RxD ¯1 (UC-7101)

1-3

UC-7101 Hardware User’s Manual Introduction

Power Requirements

Power Input 12 to 48 VDC

Power Consumption 300 mA @ 12 VDC (UC-7101)

Mechanical

Dimensions (W¯D¯H) 67 ¯100.4 ¯22 mm (UC-7101)

Weight 130 g

Construction Material aluminum, 1 mm

Mounting DIN-rail, Wall-mounting

Environment

Operating Temperature -10 to 60°C (14 to 140°F), 5 to 95% RH

-40 to 75°C (-40 to 167°F) for -T models

Storage Temperature -20 to 80°C (-4 to 176°F), 5 to 95% RH

-40 to 85°C (-40 to 185°F) for -T models

Regulatory Approvals

EMC FCC, CE (Class A)

FCC Part 15, CISPR 22 Class A

CE Class A: EN55022 Class A, EN61000-3-2 Class A,

EN61000-3-3, EN55024

Safety UL/cUL: UL60950, CAN/CSA-C22.2 No. 60950-00, LVD: EN60950-1

Other RoHS, CRoHS, WEEE

Warranty 5 years

Software Specifications—UC-7101 (μClinux)

Kernel Version: 2.6.19

Protocol Stacks: TCP, UDP, IPv4, SNMP V1/V2c, ICMP, ARP, HTTP, CHAP, PAP,

DHCP, NTP, NFS, SMTP, Telnet, FTP, PPP, PPPoE

File System: JFFS2 (on-board flash) for Kernel, Root File System (Read Only) and

User Directory (Read / Write)

System Utilities: msh, busybox, tinylogin, telnet, ftp

Supported Services and Daemons:

telnetd: Telnet Server daemon

ftpd: FTP server daemon

Boa: Web server daemon

pppd: dial in/out over serial port daemon & PPPoE

snmpd: snmpd agent daemon

inetd: TCP server manager program

Application Development Environment:

Moxa Linux API Library

Linux and Windows Tool Chain:

Arm-elf-gcc: C/C++ PC Cross Compiler

μClibc: POSIX Standard Library

UC Finder: UC’s LAN IP broadcast search utility for Windows and

Linux

Device Drivers: UART, RTC, Buzzer, SD Card

1-4

UC-7101 Hardware User’s Manual Introduction

Hardware Block Diagrams

UC-7101

RS-232/422/485 RS-232

Ethernet

1-5

16 MB

SDRAM

MOXA ART CPU

32-bit ARM9

192 MHz

LAN

PHY

MAC

Power

Circuit

8 MB

Flash

RTC

Watchdog

UART UART

Serial

Port

Console

Port

Chapter 2 Hardware Introduction

The UC-7101 is compact, rugged embedded computers designed for industrial applications. The

LED indicators on the computers’ outer casing help you monitor the performance of the computers,

and assist in identifying trouble spots. The hardware platform is both reliable and stable, and

allows you to devote the bulk of your attention to developing your own application. In this chapter,

we cover the basic hardware of the UC-7101 series embedded computers.

In this chapter, we cover the following topics:

Appearance

Dimensions

Panel Views

LED Indicators

Internal SD Socket

Additional Functions

¾Reset Button

¾Real Time Clock

UC-7101 Hardware User’s Manual Hardware Introduction

Appearance

UC-7101

Ethernet

(10/100BaseTx)

RS-232

Console Terminal

Internal SD Slot for

Storage Expansion

(remove cover to access)

12 to 48 VDC

Serial Port

(RS-232/422/485)

2-2

Otros manuales para UC-7101

Tabla de contenidos

Otros manuales de De oficina de Moxa Technologies

Moxa Technologies

Moxa Technologies RKP Series Manual de usuario

Moxa Technologies

Moxa Technologies DA-661 Instrucciones de uso

Moxa Technologies

Moxa Technologies DA-681 Series Manual de usuario

Moxa Technologies

Moxa Technologies V2616 Series Manual de usuario

Moxa Technologies

Moxa Technologies MC-5157-AC/DC Manual de usuario

Moxa Technologies

Moxa Technologies ThinkCore V481 Instrucciones de uso

Moxa Technologies

Moxa Technologies UC-7410-LX Plus Manual de usuario

Moxa Technologies

Moxa Technologies V2403 Series Instrucciones de uso

Moxa Technologies

Moxa Technologies UC-8100 Series Manual de usuario

Moxa Technologies

Moxa Technologies UC-7408-LX Plus Manual de usuario

Moxa Technologies

Moxa Technologies DA-720-C5-DPP Manual de usuario

Moxa Technologies

Moxa Technologies V2406A Series Manual de usuario

Moxa Technologies

Moxa Technologies MPC-2120 Series Instrucciones de uso

Moxa Technologies

Moxa Technologies DA-662A Series Manual de usuario

Moxa Technologies

Moxa Technologies UC-8410 Manual de usuario

Moxa Technologies

Moxa Technologies THINKCORE W321 Manual de usuario

Moxa Technologies

Moxa Technologies UC-8112-ME-T-LX Instrucciones de uso

Moxa Technologies

Moxa Technologies V2406C Series Instrucciones de uso

Moxa Technologies

Moxa Technologies UC-7112 LX Plus Instrucciones de uso

Moxa Technologies

Moxa Technologies UC-7408 series Manual de usuario

Moxa Technologies

Moxa Technologies V2416 Series Manual de usuario

Moxa Technologies

Moxa Technologies MC-5150-AC Series Manual de usuario

Moxa Technologies

Moxa Technologies DA-710 Series. DA-710-XPE Manual de usuario

Moxa Technologies

Moxa Technologies UC-2200A Series Manual de usuario

Manuales populares de De oficina de otras marcas

HP m9060n - Pavilion - Elite Hoja de especificaciones

Asus

Asus E210 Series Manual de usuario

Dell

Dell Inspiron 600m Manual de usuario

Dell

Dell Inspiron 3662 Manual de usuario

TotalFlow

TotalFlow uFLO Manual de usuario

HP Presario SV7000 - Desktop PC Manual de usuario

HP ProDesk 400 G5 Manual

Logitech

Logitech MK320 Manual de usuario

Dell

Dell XPS 730 H2C Manual de usuario

Sony

Sony Vaio Series Manual de usuario

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manual de usuario

Alto

Alto MD 250 Manual de usuario

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series Manual de usuario

Sony

Sony VAIO VGX-TP1 Series Manual de usuario

Asus

Asus Eee Box B204 Manual de usuario

Dell

Dell Optiplex 9010 All In One Manual de usuario
