Motorola TX500 Manual de usuario
Motorola Mobility, Inc. and the Stylized M Logo are trademarks or registered
trademarks of Motorola Mobility, Inc. Trademark Holdings, LLC. All other
product or service names are the property of their respective owners.
The Bluetooth trademark and logos are owned by the Bluetooth SIG, Inc.
and any use of such marks by Motorola Mobility, Inc. is under license.
© 2011 Motorola Mobility, Inc. All rights reserved.
68014301075
motorola.com
MOTOROLA TX500
MOTOROLA TX500
English
1
Figure 1
1
2
3
4
ONOFF
2
Figure 2
Figure 3
sun visor
3
English
4
Congratulations
The MOTOROLA TX500 car speakerphone delivers hands-free conversation
in a sleek design. The speakerphone is perfect for receiving and making calls
wirelessly via Bluetooth®from your phone.
• Drive safely with wireless control of phone calls
• Simultaneously connect with two phones
• Hear voice prompts for calls, battery level, and other functions
The voice prompts are only in English.
Your speakerphone
See figure 1 on page 1.
Take a moment to familiarize yourself with your new hands-free speakerphone.
Mute button
Volume up
Volume down
Call button/Status light
1 Speaker
2 Microphone
3 Power switch
4 Micro-USB charging connector
English
5
Congratulations
The MOTOROLA TX500 car speakerphone delivers hands-free conversation
in a sleek design. The speakerphone is perfect for receiving and making calls
wirelessly via Bluetooth®from your phone.
• Drive safely with wireless control of phone calls
• Simultaneously connect with two phones
• Hear voice prompts for calls, battery level, and other functions
The voice prompts are only in English.
Your speakerphone
See figure 1 on page 1.
Take a moment to familiarize yourself with your new hands-free speakerphone.
Mute button
Volume up
Volume down
Call button/Status light
1 Speaker
2 Microphone
3 Power switch
4 Micro-USB charging connector
A few essentials to know
Turn it on & off
See figure 1 on page 1.
Install it
See figure 2 on page 2.
Change settings
Turn voice prompts on & off
With the speakerphone turned on and not on a call, press and hold either
Volume button and the Call button until you hear “voice instructions on” or
“voice instructions off”.
Note: The voice prompts are only in English.
Reset
Caution: This action erases all pairing information stored in your speakerphone.
With your speakerphone turned on, press and hold , and
buttons until the mute and status lights begin flashing.
1Press and hold , , and buttons until the lights turn off.
2Slide Power switch to OFF then ON to restart your speakerphone.
English
6
Check battery level
Press both Volume buttons while not on a call.
Status light Voice prompts
Red “battery is low”
purple “battery is medium”
blue “battery is high”
To save battery power, turn off the speakerphone when not using it for an
extended time.
Charge it
See figure 3 on page 2.
You can use your speakerphone while unplugged or plugged into the charger.
Battery Charge Status
Red, Purple = charging
Blue= fully charged
Note: Your battery is designed to last the life of your product. It should only
be removed by a recycling facility. Any attempt to remove or replace your
battery will damage your speakerphone.
English
7
Pair & connect
Note: The voice prompts are only in English.
Pair & connect with your phone
1Turn off any Bluetooth devices previously paired with your speakerphone.
2Turn on the Bluetooth feature on your phone.
3Turn on your speakerphone
The status light becomes steady blue to indicate the speakerphone is in
discoverable mode and you hear “ready to pair”.
4Follow the voice prompts to connect your phone to your speakerphone.
Note: If prompted for the passkey, enter 0000.
When your speakerphone successfully pairs with your phone, the status
light flashes in blue and purple and you hear “phone 1 connected”.
For daily use, make sure your speakerphone is turned on, and your phone’s
Bluetooth feature is on. Your speakerphone and phone will connect
automatically.
