Motorola RFS6000 - Wireless RF Switch Manual de usuario

May 2009 Edition

1725-36197-001

Version A

VIEW Certified Configuration Guide

Motorola

RFS6000 Wireless Switch

Configuration Guide

PN: 1725-36197-001_A.doc

Trademark Information

Polycom® and the logo designs

SpectraLink®

LinkPlus

Link

NetLink

SVP

Are trademarks and registered trademarks of

Polycom, Inc. in the United States of America

and various countries. All other trademarks

used herein are the property of their respective

owners.

Patent Information

The accompanying product is protected by one

or more US and foreign patents and/or pending

patent applications held by Polycom, Inc.

pan-American copyright Conventions.

No part of this manual, or the software

described herein, may be reproduced or

transmitted in any form or by any means, or

translated into another language or format, in

whole or in part, without the express written

permission of Polycom, Inc.

Do not remove (or allow any third party to

remove) any product identification, copyright or

other notices.

Every effort has been made to ensure that the

information in this document is accurate.

Polycom, Inc. is not responsible for printing or

clerical errors. Information in this document is

subject to change without notice and does not

represent a commitment on the part of Polycom,

Inc.

Notice

Polycom, Inc. has prepared this document for

use by Polycom personnel and customers. The

drawings and specifications contained herein

are the property of Polycom and shall be neither

reproduced in whole or in part without the prior

written approval of Polycom, nor be implied to

grant any license to make, use, or sell equipment

manufactured in accordance herewith.

Polycom reserves the right to make changes in

specifications and other information contained

in this document without prior notice, and the

reader should in all cases consult Polycom to

determine whether any such changes have been

made.

NO REPRESENTATION OR OTHER

AFFIRMATION OF FACT CONTAINED IN

THIS DOCUMENT INCLUDING BUT NOT

LIMITED TO STATEMENTS REGARDING

CAPACITY, RESPONSE-TIME

PERFORMANCE, SUITABILITY FOR USE, OR

PERFORMANCE OF PRODUCTS DESCRIBED

HEREIN SHALL BE DEEMED TO BE A

WARRANTY BY POLYCOM FOR ANY

PURPOSE, OR GIVE RISE TO ANY LIABILITY

OF POLYCOM WHATSOEVER.

Contact Information

Please contact your Polycom Authorized

Reseller for assistance.

Polycom, Inc.

4750 Willow Road,

Pleasanton, CA 94588

http://www.polycom.com

Motorola: RFS6000 Wireless Switch with AP300

PN: 1725-36197-001_A.doc 3

Introduction

Polycom’s Voice Interoperability for Enterprise Wireless (VIEW)

Certification Program is designed to ensure interoperability and high

performance between SpectraLink 8020/8030 Wireless Telephones

and WLAN infrastructure products.

The products listed below have been thoroughly tested in Polycom’s

lab using the VIEW Certification Test Plan. This document details

how to configure the RFS6000 Wireless Switch and the AP300 access

point (AP) to best support SpectraLink 8020/8030 Wireless

Telephones.

Certified Product Summary

Manufacturer: Motorola

Approved products: RFS6000 Wireless Switch with AP300†

RF technology: 802.11a/b/g

Radio: 2.4 GHz (802.11b/g), 5 GHz (802.11a)

Security: WPA-PSK, WPA2-PSK

AP and WLC software version certified: 3.3.1.0-003R

SpectraLink handset models certified: ** e340/h340/i640 8020/8030†

SpectraLink handset software certified: 89.135 or greater 122.021 or greater

SpectraLink radio mode: 802.11b 802.11b 802.11a

Maximum telephone calls tested per AP: 12 12 12*

Network topology: Switched Ethernet (recommended)

†Denotes products directly used in VIEW Certification testing.

* Maximum calls tested during VIEW Certification. The certified product may actually support a higher

number of maximum calls for 802.11a and 802.11g radio modes.

** SpectraLink handset models 8020/8030, e340/h340/i640 and their OEM derivates are VIEW Certified

with the WLAN hardware and software identified in the table. Throughout the remainder of this

document they will be referred to collectively as “SpectraLink Wireless Telephones”.

Service Information

If you encounter difficulties or have questions regarding the

configuration process, please contact Motorola technical support at

(800) 653-5350, or at

http://www.symbol.com/services/contactsupport.

Configuration Guide

PN: 1725-36197-001_A.doc

Network Topology

The following topology was used during VIEW Certification testing.

Motorola: RFS 6000 Wireless Switch with AP300

PN: 1725-36197-001_A.doc 5

Configuration Settings

Installing a New Image

The VIEW Certified firmware release can be obtained from Motorola’s

Developer Zone at

http://support.symbol.com/support/product/softwaredownloads.do.

Upgrading the RFS6000 Wireless Switch to the new firmware can be

done through the Web interface or through the command line

interface (CLI). Place the image on the FTP server, TFTP server or

through Compact Flash card, depending on the file transfer

mechanism chosen.

Installing firmware through the CLI

1. Enter your username and password to log into the CLI. The

defaults are login: cli user, admin password: superuser.

The serial interface parameters are 19200, 8, n, 1, n.

2. Connect the FTP/TFTP server to subnet 1.

a. For TFTP, issue the following commands:

RFS6000>en

RFS6000#upgrade

tftp://TFTP_SERVER_IP_ADDR/RFS6000_FIRMWARE_FILENAME

b. For FTP, issue the following commands:

RFS6000>en

RFS6000#upgrade

ftp://FTP_USERNAME:FTP_PASSWD@FTP_SERVER_IP_ADDR/

_FIRMWARE_FILENAME

3. After the upgrade is successful issue the following command:

RFS6000#reload

Configuration Guide

PN: 1725-36197-001_A.doc

Installing firmware through the Web interface

1. Open the RFS6000 applet by entering the IP address of the

wireless switch: http://192.168.2.103

2. In the navigation pane under Switch, click Firmware.

3. In the Firmware screen, click the Update Firmware button located at

the lower right of the page.

4. In the Update dialog box, select TFTP from the Using drop-down list.

5. At File, enter the RFS6000 firmware image filename.

6. At IP Address, enter the TFTP server IP address.

7. Click the Do Update button.

8. After the RFS6000 Wireless Switch performs the upgrade,

navigate to the Switch window.

Motorola: RFS 6000 Wireless Switch with AP300

PN: 1725-36197-001_A.doc

9. In the navigation pane under Switch, click Configurations.

10. Click the Restart button to reboot the switch.

Configuration Guide

PN: 1725-36197-001_A.doc

Installing the AP license through the CLI

For the RFS6000 to adopt AP300s, a license has to be installed. Obtain

the license key and then install based on the following steps:

RFS6000>en

RFS6000#conf t

RFS6000(config)#license AP <LICENSE_KEY>

Installing the AP license through the Web interface

1. Open the RFS6000 applet by entering the IP address of the

wireless switch: http://192.168.2.103

2. In the navigation pane under Switch, click Licenses.

3. Enter the License Key and Feature Name as seen in the figure below.

4. Click the Install button to install the license.

Motorola: RFS 6000 Wireless Switch with AP300

PN: 1725-36197-001_A.doc 9

Configuring the Wireless Switch from the

Default Configuration

Radio Settings

Configuring radio settings through the CLI

The parameters for default-11bg will be configured on the switch.

When an AP is adopted on the switch it will inherit all the default-

11bg or 11a parameters. To configure radio settings for the wireless

switch, use the following commands.

When SpectraLink Wireless Telephones are configured for

802.11b & b/g mixed mode:

RFS6000>en

RFS6000#conf t

RFS6000 (config)#wireless

RFS6000 (config-wireless)#country-code us

RFS6000 (config-wireless)#radio add 1 00-A0-F8-CD-ED-EC

11bg ap300

RFS6000 (config-wireless)#radio 1 beacon-interval 100

RFS6000 (config-wireless)#radio 1 dtim-period 3

RFS6000 (config-wireless)#radio 1 bss 1 1

RFS6000 (config-wireless)#radio 1 speed basic1 basic2

basic5p5 6 9 basic11 12 18 24 36 48

When SpectraLink Wireless Telephones are configured for

802.11g only mode:

RFS6000>en

RFS6000#conf t

RFS6000 (config)#wireless

RFS6000 (config-wireless)#country-code us

RFS6000 (config-wireless)#radio add 1 00-A0-F8-CD-ED-EC

11bg ap300

RFS6000 (config-wireless)#radio 1 beacon-interval 100

RFS6000 (config-wireless)#radio 1 dtim-period 3

RFS6000 (config-wireless)#radio 1 bss 1 1

RFS6000 (config-wireless)#radio 1 speed 1 2 5p5 basic6 9

11 basic12 18 basic24 36 48 54

Configuration Guide

PN: 1725-36197-001_A.doc

When SpectraLink Wireless Telephones are configured for

802.11a mode:

RFS6000>en

RFS6000#conf t

RFS6000 (config)#wireless

RFS6000 (config-wireless)#country-code us

RFS6000 (config-wireless)#radio add 2 00-A0-F8-CD-ED-EC

11a ap300

RFS6000 (config-wireless)#radio 2 beacon-interval 100

RFS6000 (config-wireless)#radio 2 dtim-period 3

RFS6000 (config-wireless)#radio 2 bss 1 1

RFS6000 (config-wireless)#radio 2 speed basic6 9 basic12

18 basic24 36 48 54

Channel selection

You can specify the desired channel manually by using the following

commands.

For 802.11b/g radio:

RFS6000(config-wireless)#radio 1 channel-power indoor 11

For 802.11a radio:

RFS6000(config-wireless)#radio 2 channel-power indoor 36

For configuring power and data rate settings,please consult your

facility’s RF site survey, designed for voice traffic, to determine if you

have sufficient coverage to support all data rates. SpectraLink

Wireless Telephones require the following minimum dBm reading to

support the corresponding Basic data rate setting in the access point.

802.11

Radio Standard Minimum Available

Signal Strength (RSSI) Maximum

“Basic” Data Rate

-70 dBm 1 Mb/s

802.11b -60 dBm 11 Mb/s

-63 dBm 6 Mb/s

802.11g -47 dBm 54 Mb/s

-60 dBm 6 Mb/s

802.11a -45 dBm 54 Mb/s

For additional details on RF deployment please see the Deploying

Enterprise-Grade Wi-Fi Telephony white paper and the Best

Practices Guide for Deploying SpectraLink 8020/8030 Wireless

Telephones.

Otros manuales para RFS6000 - Wireless RF Switch

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Motorola

Motorola

Motorola M68LC302CAF20VCT Manual de usuario

Motorola

Motorola WS2000 - Wireless Switch - Network Management... Manual de usuario

Motorola

Motorola WS2000 - Wireless Switch - Network Management... Manual de instrucciones

Motorola

Motorola WS5100 Series Manual de usuario

Motorola

Motorola WS2000 - Wireless Switch - Network Management... Manual de usuario

Motorola

Motorola AP-PSBIAS-1P2-AFR Manual de usuario

Motorola

Motorola RFS Series Manual de usuario

Motorola

Motorola 549478-001-00 - PowerBroadband EthernetXD M2a WallPlate... Manual de usuario

Motorola

Motorola RFS6000 Series Manual de usuario

Motorola

Motorola RFS7000 Series Manual de usuario

Motorola

Motorola T2-2500 Manual de usuario

Motorola

Motorola RLN5929 Manual de usuario

Motorola

Motorola RFS Series Manual de usuario

Motorola

Motorola WS5100 Series Manual de usuario

Motorola

Motorola RFS6000 - Wireless RF Switch Manual de usuario

Motorola

Motorola WS5100 Series Manual de instrucciones

Motorola

Motorola RFS7000GR Manual de usuario

Motorola

Motorola AP-PSBIAS-1P2-AFR Manual de usuario

Motorola

Motorola RFS Series Manual de usuario

Motorola

Motorola RFS4010 Series Manual de usuario

Motorola

Motorola WS2000 - Wireless Switch - Network Management... Manual de usuario

Motorola

Motorola RFS7000 Series Manual de usuario

Motorola

Motorola M68ICS08JB Manual de usuario

Motorola

Motorola RFS7000 Series Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
