Motorola FOCUS89 Manual de usuario

USER’S GUIDE

Wi-Fi®Home Video Camera

The features described in this user’s guide are subject to modifications without prior notice.

MODELS: FOCUS89, FOCUS89-2, FOCUS89-3, FOCUS89-4

FOCUS89-W, FOCUS89-W2, FOCUS89-W3, FOCUS89-W4

Welcome...

to your new Motorola Wi-Fi®Home Video Camera!

Thank you for purchasing your new Motorola Wi-Fi®Home Video Camera.

If you have always wondered what happens when you are away, wonder no

more. Now you can monitor your children, pets or property with this easy to

use system. You can install the Camera only from your iPhone®/iPad®or

Android™ devices and view the Camera video from your PC or Notebook, as

well as from your iPhone®/iPad®or Android™ devices.

Please keep your original dated sales receipt for your records. For warranty

service of your Motorola product, you will need to provide a copy of your dated

sales receipt to conrm warranty status. Registration is not required for warranty

coverage.

For product related questions, please call:

US and Canada 1-888-331-3383

Email: [email protected]

This User’s Guide has all the information you need to make the most out of your

product.

Please read the Safety Instructions on pages 5 - 6 before you install the unit.

Inside the Box

• 1 x Wi-Fi®Camera Unit

• 1 x Power Adapter

• 1 x Quick Start Guide

In multi-camera packs, you will find one or more additional Camera Units with

power adapter units.

Overview of your Camera

Important guidelines for installing your Wi-Fi®Camera Unit

• Use of other 2.4 GHz products, such as other wireless networks, Bluetooth™

systems or microwave ovens may cause interference with this product. Keep the

Wi-Fi®Camera Unit away from these types of products, or turn them off if they

appear to be causing interference.

• Always ensure that you have a good Wi-Fi®connection available.

1. Light Sensor (for night mode

detection)

2. Power / Status indicator

3. Microphone

4. Camera Lens

5. Infrared LEDs (for night vision)

6. Speaker

7. Micro USB socket

8. PAIR Button

9. SD Card slot

4Table of contents

Table of contents

1. Safety Instructions ..................................................................................... 5

2. Minimum System Requirements............................................................... 7

3. Getting started - Connecting Devices...................................................... 8

3.1 Setup .............................................................................................................. 8

3.2 User Account and Camera Setup on Android™ Devices ............................ 9

3.2.1 Power ON and Connect the Camera ............................................... 9

3.2.2 Download Hubble for Motorola Monitors App ................................. 9

3.2.3 Run Hubble for Motorola Monitors App on Android™ device ........ 9

3.2.4 Add the Camera to your account.................................................... 10

3.3 User Account and Camera Setup on iPhone®/iPad®.............................14

3.3.1 Power ON and Connect the Camera ............................................. 14

3.3.2 Download Hubble for Motorola Monitors App ............................... 14

3.3.3 Run Hubble for Motorola Monitors App on iPhone®/iPad®........14

3.3.4 Add the Camera to your account.................................................... 15

4. Camera Functions ................................................................................... 19

4.1 Connecting the Camera Unit to power ...................................................... 19

4.2 Overview of the Features on Hubble App................................................... 19

5. Working with PC/Notebook ................................................................... 21

6. Procedure for Resetting the Camera ...................................................... 22

7. Help.......................................................................................................... 23

8. General Information................................................................................ 29

9. TechnicalSpecications.......................................................................... 35

ENGLISH

Safety Instructions

1. Safety Instructions

WARNING:

STRANGULATION HAZARD - In case this unit is being used to monitor

infants or children, keep the unit and adapter cord more than 1 metre

away from the cot and out of their reach. Never place the Camera or

cords within a cot or near a bed. Secure the cord away from children’s

reach. Never use extension cords with AC Adapters. Only use the AC

Adapters provided.

As with any electrical device, supervision of your pet’s usage should

be exercised until your pet is acclimated to the product. If your pet is

prone to chewing, we strongly recommend you keep this and all other

electrical devices out of its reach.

Wi-Fi®CAMERA UNIT SET UP & USE:

• Place the Wi-Fi®Camera Unit on a flat surface, such as a chest of

drawers, desk, shelf or wall-mount it using the provided self adhesive

pad.

• NEVER place the Wi-Fi®Camera Unit or cords within the cot.

6Safety Instructions

WARNING

This Wi-Fi® Camera Unit is compliant with all relevant electromagnetic eld

standards and is, when handled as described in the User’s Guide, safe to use.

Therefore, always read the instructions in this User’s Guide carefully before

using the device.

• Adult assembly is required due to small parts. Keep all small parts away from

children.

• This product is not a toy. Do not allow children to play with it.

• This Wi-Fi®Camera Unit is not a substitute for responsible adult

supervision.

• Keep this User Guide for future reference.

• Do not place the Wi-Fi®Camera Unit or cords in the cot or within reach of

the baby (the unit should be at least 1 metre away).

• Keep the cords out of reach of children.

• Do not cover the Wi-Fi®Camera Unit with a towel or blanket.

• Test the Wi-Fi®Camera Unit and all its functions so that you are familiar with

it prior to use.

• Do not use the Wi-Fi®Camera Unit near water.

• Do not install the Wi-Fi®Camera Unit near a heat source.

• Only use the Power Adapter provided. Do not use other power adapters as

this may damage the device.

• Never use extension cords with Power Adapters.

• Do not touch the plug contacts with sharp or metal objects.

ENGLISH

Minimum System Requirements

2. Minimum System Requirements

Web Portal

• Windows®7

• Mac OS®10.7

• Chrome™ 24

• Internet Explorer®9

• Safari®6

• Java™ 7

• Firefox®18.0

• Adobe®Flash®Player 15.0

Android™ System

• Version 4.4.2 or above

iPhone®/iPad®iOS

• Version 9.0 or above

High Speed (Wi-Fi®) Internet

• At least 0.6 Mbps upload bandwidth per camera (you can test your internet

speed on this site: http://www.speedtest.net)

• If using a MicroSD Card it can be up to 32MB, and must be speed class 4 or

above for best video quality.

8Getting started - Connecting Devices

3. Getting started - Connecting Devices

How does it work?

When a user tries to access the Camera, our Hubble server authenticates the

user’s identity and permits access to the Camera.

3.1 Setup

Connect the Camera to the Power Adapter, then plug into an electrical outlet.

The Camera must be within range of the Wi-Fi® router with which you want to

connect. Make sure the password of the router is available for entering during

the in-app setup process.

Status of LED Indication:

- Pair / Setup state: LED cycles from Blue to Purple to Red

- Unconnected state: LED is Red and Flashing

- Connected state: LED is Blue and always on

- Live Streaming: LED is Blue and Flashing

Ready for connection state:

LED is Red and Flashing

Note: You can only setup via a compatible smartphone or tablet and not via a

PC.

Access your

Camera locally

View your Camera from any

compatible device remotely

Wi-Fi RouterFOCUS89

Camera

Hubble

Service

ENGLISH

Getting started - Connecting Devices

3.2 User Account and Camera Setup on Android™ Devices

What you need

• Wi-Fi®Camera Unit

• Power adapter for the Camera

• Device with Android™ system version 4.4.2 and above

3.2.1 Power ON and Connect the Camera

• Connect the power adapter to an electrical outlet and insert the plug into

the micro USB socket on the back of the Camera Unit.

• The Camera’s Red LED Flashes after the Camera has finished booting.

3.2.2 Download Hubble for Motorola Monitors App

• Go to Google Play™ Store to search for “Hubble for Motorola Monitors”.

• Download “Hubble for Motorola Monitors” App from Google Play™ Store

and install it on your Android™ device

3.2.3 Run Hubble for Motorola Monitors App on Android™ device

• Ensure that your Android™ device is connected to your Wi-Fi®router.

• Run “Hubble for Motorola Monitors” App, enter your account information,

read through the Terms of Service, then select “By signing up you agree to

our Terms & Conditions” before you tap SIGNUP. (Picture A1)

10 Getting started - Connecting Devices

Note:

If you already have a Hubble App account, please select Already have an

Account? to go to the next step.

3.2.4 Add the Camera to your account

• Tap on the lower right corner of the screen to add camera. (Picture A2)
