INSTALLATIONINSTRUCTIONS

Professional Installation is Recommended

Technical Support

ForAuthorized Dealers - (800) 34-MOPAR

Hours: 9:00 a.m. - 6:00 p.m. EST Monday thru Friday

10:00 a.m. - 2:00 p.m. EST Saturday

1031263

REV.A

5/06 K6859657

2007 Jeep Wrangler (JK)

Security System

Note: ForEVSIinstallations,bothFactoryRKEKeyfobsare

requiredforoptionprogramming&Driver’sDoorPriority

Unlockfeaturemust be enabled.

This device complies with part 15 of the FCC rules and with RSS-210 of the

industry Canada. Operation is subject to the following two conditions: (1) this

device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired

operation.

This product was manufactured in environmentally friendly manufacturing

facility and may contain certain recycled materials. All materials meet or

exceed original specifications for quality and reliability.

JeepWrangler(JK)

Security System

TableofContents

Vehicle Preparation...................................................................................4

Module Preparation...................................................................................5

Custom Harness Installation.....................................................................6

System Programming.............................................................................10

EVS I Programming................................................................................10

EVS II Programming...............................................................................12

Option Bank Chart...................................................................................13

System Testing.........................................................................................14

Reassembly..............................................................................................14

System Layout..........................................................................................15

123456789012345678901234567890121234567890123456789012345678901

2345678901234567890123456789012123456789012345678901234567890

123456789012345678901234567890121234567890123456789012345678901

Note: For EVS I installations, both Factory RKE

Keyfobs are required for option programming &

Driver’s Door Priority Unlock feature must be enabled.

PARTS REQUIRED

PartNumber82209992(EVSI)or82209991(EVSII)

5A 1X 15A 1X 1X 5X

Owner's Manual

VehicleRemote Star t System

FeaturingPowerCodeTechnology

FortheUltimate inComfort,Convenience andSecurity

TOOLS REQUIRED

10mm 1/4”

VEHICLEPREPARATION

1. Lower one or more of the passenger windows so the keys do not get locked

in the vehicle.

2. Disconnect and isolate the negative battery cable. The battery will need to be

re-connected before programming.

3. EVS I System installation requires 2 working factory RKE keyfobs for

programming options.

T-

12345678901234567890123456789012123

234567890123456789012345678901212

12345678901234567890123456789012123

EVS II - additional parts

ARM DISARM

2X 2X each

1234

T20/T30

VehiclePreparation

Removedriver’ssidelowerdashpanels,

&steeringcolumnshroud.

A. Pull down on lower dash. Panel is

held by clips. Start at the top corners.

Remove panel.

B. Remove (3) bolts holding metal panel

in place. Pull up on the panel to

remove.

C. Remove lower plastic dash panel.

Panel is held by clips.

D. Remove (3) screws from steering

column shroud. Separate and remove

steering column shroud.

E. Removedriver’sside kickpanel/sill

plate. Panel is held on by clips.

Overview

The security module harness will interface with the existing ignition switch connec-

tor, horn, parking lights, power doorlock & door trigger connections, and a ground

termination.

Module Preparation

Place fuses into the control module.

A. Observe fuse amperage ratings. Place

the 5 Amp fuse into the “Main B+”

location. Place the 15 Amp fuse into

the positive “PK LIGHTS” location.

Install DNA into the control module.

B. Insert DNA into the control module.

Ensure the DNA assembly snaps

completely in place and no circuit

board pins get bent while closing.

DNA

Custom Harness Installation

Ignition switch connector

A. Locate ignition switch connector,

directly behind the ignition switch.

Release the secondary lock. While

pushing on main release, remove

connector from ignition switch.

B. Connect the harness 5-way female

connector to the vehicle’s ignition

switch.

C. Connect the harness 5-way male

connector to the vehicle’s 5-way

ignition connector previously

removed from the ignition switch.

Ground

D. Using a supplied 1/4” screw,

secure the black ground wire with

ring terminal to the driver’s side left

kickpanel metal.

Parking Light Connection

E. LocatetheWhite/Violet (L217)wirein

harness, found low in the left kick

panel area. Center-splice the

harness Yellow wire into this wire,

following the center-splice proce-

dure as shown. This wire will show

+12V when the parking lights are

turned on.

Center-Splice Procedure

ArmWireConnection(EVSIonly!)

F. Locate the Lt Green/Grey wire in the driver kick

panel. Thiswirewill show+12 voltswhenthedoors

are locked using the keyfob. Center-splice

the harness Lt Blue wire into this wire, fol-

lowing the center-splice procedure.

DisarmWire Connection(EVS Ionly!)

G. LocatetheTan/Brown wire in thedriverkick

panel. Thiswill willshow+12 volts whenthe doors

are unlocked on the first press of the unlock but-

tonon the keyfob. Center-splice theharnessBrown

wire into this wire, following the center-splice pro-

cedure.

Unlock Sense Wire Connection (EVS I only!)

H. Locate the Tan/Brown wire in in the passenger kick

panel. This wire will show +12 volts when the doors

are unlocked only on the second press of the unlock

button on the keyfob. Center-splice the harness Lt

Green wire into this wire, following the center-splice

procedure.

DoorTrigger Connection

I. Locate theYellow/White dome light

feed wire (M24), found at the

underdash courtesy light. Center-

splice to the White wire on the

main security harness.

PowerDoorLockConnections - UsedforEVS Ionly.

SkiptoStepIforEVSII.

LED

J. Drill 9/32” hole in trim panel as

shown in diagram. Exact place-

ment needs to be determined

before drilling. Ensure there is

nothing on the backside of the

panel and there is enough depth for

theLED.

K. Routethe remaining Dk Green wire

through the cowl panel and into the

engine compartment through an existing

grommet.

HornConnections

L.Locate the Grey/Yellow(X21)wire in the

green “C” connector (pin #18) found

underneath the TIPM module. Center-

splice the relay harness Grey wire (pin

30) into this wire, following the center-

splice procedure. Solder the connection.

This wire will show +12V when the horn

is activated.

M. Connect the relay harness Red wire (pin

87) to the positive battery post.

N. Route the remaining relay harness Dk

Greenwire (pin 85) to the Dk Green (-)

HORN output wire on the main security

harness. Solder the connection.

Security Module Connections

O. Connect the 24-way connector into

the PC-12 Security module. Also,

connect the antenna connector (EVS II

Systems only) on end opposite the

main harness connector.

24-Way

Antenna

8685

87a

(+)

20A Fuse

Connect to (-)HORN output (pin #21)

from security module

Dk Green wire Dk Green

Grey

Red

Connect to Grey/Yellow (X21) at

TIPM Green “C” Connector (pin #18)

Option Programming.

The remote security system has several installer programmable options which

can be changed to accomodate different circumstances. In most cases, there

will be a need to change option settings (i.e. adjustment of shock sensor

sensitivity, horn pulse output duration, etc).

A. Open the driver’s door.

B. Turn the ignition to the “on” position.

C. Press and hold the programming/override button; After 10 seconds the

parking lights will flash 3 times indicating the system is now in learn

mode.

D. Release the programming button.

E. Press and release the programming button once more; The parking

lights will flash 4 times indicating the system has entered Option Bank 1.

System Programming

Notes:

1. Reconnect the negative battery terminal prior to programming.

2. EVS I System installation requires 2 working factory RKE keyfobs for

programming options & Driver’s Door Priority Unlock feature to be

enabled for proper operation of the security system. Refer to vehicle’s

Service Manual.

3. This system has 2 option banks. Bank 1 has 8 options, and Bank 2

has 4 options. Refer to the Option Bank Chart for details.

To change the setting of an option: (EVS I Systems only)

A. Press the door trim “Lock” switch or, if the vehicle’s door lock feature is

non-functional with the ignition turned on, press the factory keyfob

“Lock” button (of the keyfob that is not in the ignition cylinder) to advance

to the desired option (refer to the Option Bank Chart).

The parking lights will flash a number of times indicating which option

is selected (i.e. Two flashes indicates that option number two has been

selected).

B. Press the door trim “Unlock” switch to change the setting of an option..

The status LED indicates the setting of the option; LED ON indicates

that the option is on, LED OFF indicates that the option is off.

C. To advance to Option Bank 2, at any point while in Option Bank 1, press

and release the programming/override button to advance to option bank

number two. The parking lights will flash 5 times indicating the system

has entered Option Bank 2.

To return back to Option Bank 1, press and release the programming/

override button once again (4 flashes).
