Moons' SRAC8 Manual de usuario

Yellow A-

Black A+

6 LEAD

MOTOR

Green NC

B+

Red

B-

White

Blue

Black A+

4 LEAD

MOTOR

Green A-

White White A

Brown

Green

Yellow C

Gray B

Pink

Blue

Red D

Green

Brown

Yellow

Gray Blue Red

Pink

Red B+

Blue B-

8 LEAD

MOTOR

8 LEAD

MOTOR

4-Lead Biploar Motor 6-Lead Center Tap Connected

Yellow NC

6 LEAD

MOTOR

Green A-

B+

Red

White

B-

Blue

6-Lead Series Connected8-Lead Series Connected8-Lead Parallel Connected

Connecting to a Motor

Connect the drive to the motor. Four lead

motors can be connected

in only one way. If using a

non MOONS’ motor,

consult the motor specs

for wiring information.

Connect to Power

Use the supplied connector to connect to the AC

supply according to the diagram below. Use 16

AWG wire for Line (L) and Neutral (N). Use 14 AWG

for Earth Ground (G).

The SRAC8 has an internal 10A fast acting fuse.

Care should be taken when working with high voltages.

Selecting the Motor

Each position of the 16-bit rotary selects a different motor, automatically setting the conguration parameters

in the drive. The SRAC8 drive comes programmed with up to 16 typical motors as factory defaults. Drives

can be customized with specially selected motors when required. Available options are listed

on the drive label. Each motor in the loaded database has unique settings to optimize the anti-

resonance.

If the motor selection is changed, the drive power supply will need to be cycled.

Requirements

To use the SRAC8 Step Drive, the following items

are needed:

• Universal AC input of 80 to 265 VAC

• Pulse & Direction signal

• A compatible step motor

SRAC8

AC Input Step Motor Drive Quick Set-Up Guide

Shanghai AMP & MOONS’ Automation Co. Ltd.

No.168 Mingjia Road, Industrial Park North Minhang District,

Shanghai 201107, P.R. China

Tel: 86-21-52634688 Fax: 86-21-62968682

E-mail: [email protected] Web: www.moonsindustries.com

Service Center

+86-400-820-9661

Safety Instructions

• Only qualied personnel should assemble, install, operate, or maintain this equipment.

• Read all available documentation before assembly and operation.

• It is vital to ensure that all system components are connected to earth ground.

• This product contains electrostatically sensitive components that can be damaged by incorrect

handling.

Selection

Switches

Many operational

parameters of the

SRAC8 can be set or

changed by position

switches - either by

a single switch or a

combination of ON/

OFF settings of 2 or

more switches.

SW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8

Running Current

Microstepping

SW9 SW10 SW11 SW12 SW13 SW14 SW15 SW16

Idle Current Anti Resonance

Step Input Mode

Step Input Signal Filter Self Test

Smoothing Filter

Microstepping - 4 switches for a total of 16 settings:

Microstep(step/rev) SW1 SW2 SW3 SW4

200 ON ON ON ON

400 OFF ON ON ON

800 ON OFF ON ON

1600 OFF OFF ON ON

3200 ON ON OFF ON

6400 OFF ON OFF ON

12800 ON OFF OFF ON

25600 OFF OFF OFF ON

1000 ON ON ON OFF

2000 OFF ON ON OFF

4000 ON OFF ON OFF

5000 OFF OFF ON OFF

8000 ON ON OFF OFF

10000 OFF ON OFF OFF

20000 ON OFF OFF OFF

25000 OFF OFF OFF OFF

Idle Current - 2 switches for a total of 4 settings:

Idle SW9 SW10

25% ON ON

50% OFF ON

70% ON OFF

90% OFF OFF

Step Input Mode (SW13) - OFF for Step and

Direction input, ON for CW/CCW input

Step Smoothing Filter (SW15) - ON to enable, OFF to

disable

Running current - 4 switches for a total of 16 settings:

Current(Peak) SW5 SW6 SW7 SW8

0.4A ON ON ON ON

0.6A OFF ON ON ON

0.9A ON OFF ON ON

1.2A OFF OFF ON ON

1.5A ON ON OFF ON

2.0A OFF ON OFF ON

2.5A ON OFF OFF ON

3.0A OFF OFF OFF ON

3.5A ON ON ON OFF

4.0A OFF ON ON OFF

4.5A ON OFF ON OFF

5.2A OFF OFF ON OFF

5.9A ON ON OFF OFF

6.6A OFF ON OFF OFF

7.3A ON OFF OFF OFF

8.0A OFF OFF OFF OFF

Anti-Resonance - 2 switches for a total of 4 settings:

Option SW11 SW12 Inertia

0 ON ON Low

High

1 OFF ON

2 ON OFF

3 OFF OFF

Step Input Signal Filter (SW14) - ON for 150 kHz,

OFF for 2 MHz

Self test (SW16) - ON for 2 rev CW/CCW .5 rps self

test, OFF for none
