Montpellier MSE46W Manual de usuario

Installation

and

Operating

Instructions

MODEL: MSE50W

Free Standing Electric Oven

Please

read

these

instructions

carefully

before

attempting

install

use

this

appliance.

It is

advisable

keep

these

instructions

safe

place

for

future

reference.

MODEL: MSE46W

Free Standing Electric Oven

roduc

ion

Please read these instructions carefully before installing or

using your appliance. It is advisable to keep your purchase

and

installation receipts with these instructions in a safe place for

future reference. Included is some important safety information

in addition to guidelines and recommendations that will enab

you to take full advantage of all the functions available.

his

quali

applian

has

been

and

ied

all

applicable UK electrical and safety standards.

This appliance must be installed and connected in

accordance with current regulations.

After unpacking the appliance ensure that there is no visib

damage. If the appliance has been damaged during transit,

do not use it, contact your retailer immediately.

Thank you for choosing this Montpellier branded appliance. It

has been designed to give years of trouble-free use provided it is

installed and maintained correctly.

Your 1year Manufacturer's guarantee

THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.

Your new montpellier appliance carries a free guarantee which protects you against the cost of

repairs during the first 12 months from date of purchase provided that:

Any claim is accompanied by evidence of the model reference, model serial number and proof of

purchase, such as a Sales Receipt, showing that the appliance was purchased within the 12

months prior to the date of claim.

What is not covered under the Guarantee:

·Any appliance not correctly installed and operated in accordance with the manufacturer's

instructions.

·Any appliance that is used for anything other than domestic purposes.

·Any defect caused by accident, misuse, unauthorized modification or inexpert repair.

·Cost of Call-out where a fault cannot be found with the appliance.

·Cost of Call-out for work covering routine maintenance, such as, but not exclusively,

cleaning of filters or defrosting.

·Cost of Call-out for work required to correct the alignment of doors following door reversal

procedures carried out by you.

·Use of the appliance by anyone other than the Householder.

·Use in any commercial environment.

·Consumable items, such as, but not exclusively, fuses in plugs, bulbs and breakable items

which require routine replacement.

·Repair costs incurred that have not been authorised by Repairtech and/or carried out by a

non-approved Repairtech engineer.

YOUR GUARANTEE IS VALID ONLY IN THE UK.

To Register your Appliance simply complete the card in your appliance pack and return it with a

stamp affixed or Alternatively you can Register online at www.repairtechuk.com

SERVICE HELP-LINE

Should your appliance develop a fault, please call the

Repairtech Service Helpline on:

01527-888133

Please remember to have all your product details available, including the model number, serial

number, date of purchase and your retailers’ details before registering a fault.

Your service call cannot progress without this information.

Description

the

Appliance

CONTENTS:

Section 1. Installation

Section 2. Safety Advice

Section 3. Operating the Appliance

Section 4. Maintenance

Section

Installation

-Remove all packaging and protective film from the appliance.

-Position the appliance in a dry atmosphere.

- The following image is provided as a guide for installation – your installer will carry

out the installation in accordance with the current regulations.

- Your installer will connect the power cable in accordance with the current regulations.

To install this appliance, please proceed as follows:

1.1. Choosing a location for your oven

When choosing a location for your oven, ensure that there are no flammable or

combustible materials in the close vicinity, such as curtains. You may be required to

make changes to the area surrounding your oven.

You must ensure a minimum gap of 50mm between the edge of the hotplate and an

adjacent wall. You must ensure a minimum distance of 750mm between the hotplate

and overhanging cupboards or a cooker hood (see below image).

Note: Do not site your oven next to a cooling appliance.

1.2. Electrical Connection

Power Output

Oven Bottom Element - 1000W

Oven Top Element - 1000W

Grill Element - 1600W

2 x 145mm Hotplates - 2 x 1000W

2 x 180mm Hotplate - 2 x 1500W

1 x 180mm Rapid Hotplate - 2000W

This appliance has a power rating in excess or 3000W and therefore

must be ‘hard wired’ to a suitable fused point adjacent to the appliance

housing and protected with a 25 amp fuse. Please note that a switchable

spur should be accessible above the work surface to allow the power to

be turned off by the consumer.

Your installer will connect this appliance in accordance with current

regulations using the correct grade of electrical cable and making a

suitable connection between the fused spur and the electrical connection

block on the rear of the appliance.

Section 2. Safety Advice

-Please read this booklet thoroughly before installing and switching on the

appliance. The manufacturer accepts no responsibility for incorrect

installation and usage.

-This appliance is guaranteed for Domestic Use Only.

-The appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning the use of the appliance by a person responsible for their

safety. Children should be supervised to ensure that they do not play with

the appliance.

-This appliance must only be used for cooking/heating foods and liquids.

Do not use it for any other purpose.

-If using an adaptor, this must be used in accordance with the

manufacturers instructions and ensure that the electrical circuit is not

overloaded as this could cause overheating.

-Do not twist or bend the cables, and keep them away from hot surfaces.

-Following installation make sure that the power cable is not trapped

underneath the appliance.

-Keep the appliance surfaces clean. Failure to do this could lead to the

appliance malfunctioning.

-The surface of this appliance will get hot during use. The surface of this

appliance will remain hot after it has been turned off.

-If the power supply cord is damaged, it must be replaced by a qualified

person in order to avoid a hazard.

Section 3. Operating the Appliance

3.1. Control Panel

3.2. Oven Functions

You are able to select various difference Oven Functions (explained below) by

adjusting the Oven Function knob on the control panel (shown above).

Oven Lamp

Only the oven light will be turned on. This light will remain on until turned off.

Static Cooking Function

The oven's thermostat and warning lights will be turned on, the lower and upper heating

elements will start to heat.

Lower Heating Function

The oven's thermostat and warning lights will be turned on, the lower heating element will

start to heat.

Upper Heating Function

The oven's thermostat and warning ligh

ts will be turned on, the upper heating element will

start to heat.

3.2 Oven Functions continued.

3.3. Selecting a Temperature

Once you have selected an Oven Function, simply adjust the oven temperature knob

to the desired temperature.

Grilling Function

The oven's thermostat and warning lights will be turned on, the grill heating element will start

to heat.

This function is used for grilling and toasting foods, use the upper shelves of the oven. Lightly

brush the wire grid with oil to stop foods sticking and place food in the center of the grid.

Always place a tray beneath to catch any drips of oil or fat. It is recommended to pre-heat the

oven about 10 minutes.

Warning: When grilling, the oven door must be closed and the oven temperature should be

adjusted to 1900C.

Faster Grilling Function

The oven's thermostat and warni

ng lights will be turned on, the grill and upper heating

elements will start to heat.

The function is used for faster grilling and for covering a larger surface area, such as grilling

meats, use the upper shelves of oven. Lightly brush the wire grid with oil to stop foods sticking

and place foods in the center of the grid. Always place a tray beneath to catch any drips of oil

or fat. It is recommended to pre-heat the oven about 10 minutes.

Warning: When grilling, the oven door must be closed and the oven t

emperature should be

adjusted to 1900C.
