montpellier MON-SFOP58MC Manual de usuario
I
n
s
t
a
ll
a
ti
o
n
a
nd
O
p
era
ti
n
g
I
n
s
t
r
u
c
tio
n
s
MODEL: MON-SFOP58MC (*)
Built-In Single Oven
(*) Part of a Built-In Oven/Hob Pack inc’ MON-CT4)
Please
read
these
instructions
carefully
before
attempting
to
install
or
use
this
appliance.
It
is
advisable
to
keep
these
instructions
in
a
safe
place
for
future
reference.
montpellier
(Picture indicative of model supplied)
2
In
t
roduc
t
ion
Thank you for choosing this Montpellier branded appliance. It
has been designed to give years of trouble-free use provided
it is installed and maintained correctly.
Please read these instructions carefully before installing or
using your appliance. It is advisable to keep your purchase
and
installation receipts with these instructions in a safe place for
future reference. Included is some important safety information
in addition to guidelines and recommendations that will enab
le
you to take full advantage of all the functions available.
This quality appliance has been tested and certified to meet all
applicable UK electrical and safety standards.
This appliance must be installed and connected in
accordance with current regulations.
After unpacking the appliance ensure that there is no visible
damage. If the appliance has been damaged during transit, do
not use it, contact your retailer immediately.
3
Your 2 year Manufacturer's guarantee
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
Your new Montpellier appliance carries a free guarantee which protects you against the cost of
repairs during the first 24 months from date of purchase provided that:
Any claim is accompanied by evidence of the model reference, model serial number and proof of
purchase, such as a Sales Receipt, showing that the appliance was purchased within the 24 months
prior to the date of claim.
What is not covered under the Guarantee:
Any appliance not correctly installed and operated in accordance with the manufacturer's
instructions.
Any appliance that is used for anything other than domestic purposes.
Any defect caused by accident, misuse, unauthorized modification or inexpert repair.
Cost of Call-out where a fault cannot be found with the appliance.
Cost of Call-out for work covering routine maintenance, such as, but not exclusively,
cleaning of filters or defrosting.
Cost of Call-out for work required to correct the alignment of doors following door reversal
procedures carried out by you.
Use of the appliance by anyone other than the Householder.
Use in any commercial environment.
Consumable items, such as, but not exclusively, fuses in plugs, bulbs and breakable items
which require routine replacement.
Repair costs incurred that have not been authorised by Repairtech and/or carried out by a
non-approved Repairtech engineer.
YOUR GUARANTEE IS VALID ONLY IN THE UK.
SERVICE HELP-LINE
Should your appliance develop a fault, please call the
Repairtech Service Helpline on:
01527-888133
Please remember to have all your product details available, including the
serial number, before registering a fault.
Your service call cannot progress without this information.
4
Descri
ption
Of
The
Appliance
1. Function Control
2. Oven Thermostat Control
3. Door Handle
4. Glass Oven Door
5. Interior Oven Light
(Picture indicative of model supplied)
1.
2.
3.
4
.
5
.
5
CONTENTS:
Section 1. Installation
Sect
i
o
n 2.
Safety
A
d
v
i
ce
Section 3. Operating the Appliance
Section 4. Maintenance
6
Section
1.
Installation
-Remove all packaging, protective film and securing tape from
the appliance.
-Position the appliance in a dry atmosphere..
- The following dimensions are provided as a guide for
installation – your installer will carry out the installation in
accordance with the current regulations.
- Your installer will connect the power cable in accordance with
the current regulations.
To install this appliance, please proceed as follows:
1.1. Kitchen Furniture Cut-Out
7
1.2. Electrical Connection
This appliance has a total Power Rating of 2900W and can be
connected to a suitable fused point adjacent to the appliance
housing. Please note that a switchable spur should be
accessible above the work surface in order that the power can
be turned off by the consumer.
Your installer will connect this appliance in accordance with
current regulations.
Function Total power
Top Heat 900W
Top/Bottom Heat 2200W
Grill 2000W
Grill/Top Heat 2900W (With Fan Assist 2925W)
1.3. Secure the Oven in Position
Finally, use the four screws
To secure the oven to the
kitchen cabinetry.
8
Section 2. Safety Advice
-Please read this booklet thoroughly before installing and
switching on the appliance. The manufacturer accepts no
responsibility for incorrect installation and usage.
-This appliance is guaranteed for Domestic Use Only.
-The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the
appliance.
-This appliance must only be used for cooking/heating food
items. Do not use it for any other purpose.
-If using an adaptor, this must be used in accordance with the
manufacturers instructions and ensure that the electrical
circuit is not overloaded as this could cause overheating.
-Do not twist or bend the cables, and keep them away from hot
surfaces.
-Following installation make sure that the power cable is not
trapped underneath the appliance.
-Keep the appliance surfaces clean. Failure to do this could
lead to the appliance malfunctioning.
-The surface of this appliance will get extremely hot during use.
Take care when using the appliance and keep children well
away.
-The interior and surface of this appliance will remain hot after
it has been turned off. Do not touch or clean the appliance
until it has completely cooled down.
-Never lift this appliance using the door handle or ‘open’ door.
-If the power supply cord is damaged, it must be replaced by
the manufacturer, it’s service agent or similarly qualified
persons in order to avoid a hazard.
9
Section 3. Operating the Appliance
3.1. Control Panel
1. Oven Thermostat Control
2. Oven Function Control
3.2. Cooking & Thermostat & Functions
3.2.1. Cooking Functions
Turn the Oven Function Control (2) clockwise to the required
function. An indicator light will show whilst the oven is on:
Light Top/Bottom With Fan Grill Grill+Top With Fan
3.2.2. Oven Temperature
Turn the Oven Thermostat Control (1) to the required oven
temperature. A red indicator light will show whilst the oven is
reaching temperature. When the set temperature has been
achieved, the light will go out.
1.
2
.
10
Section 4. Maintenance
Before any maintenance or cleaning work is carried out,
DISCONNECT the appliance from the ELECTRICITY supply and
ensure that the appliance is completely cool.
4.1. Cleaning the Oven
Clean spillages from inside the oven as soon as possible after use.
Always ensure that the surface has cooled down before cleaning.
Use a cloth with warm soapy water to clean the surface. If the
spillage has dried on the surface you may need to use a specialist
oven cleaner, available from all good supermarkets.
Clean the glass door with warm soapy water – always ensure the
glass is cool before you clean it!.
4.2. Changing the Oven Bulb
Proceed as follows when the
glass is cold:
Unscrew the glass cover
Remove the bulb
Fit new bulb (*)
Replace glass cover
(*) Must be a 300° like for like
replacement oven bulb
available from specialist
hardware & lighting shops
