Montpellier SP200X Manual de usuario

era

tio

MODEL: SP200X

Built-In Domino Electric Hob

Please

read

these

instructions

carefully

before

attempting

install

use

this

appliance.

advisable

keep

these

instructions

safe

place

for

future

reference.

(Please note that this picture is shown for indicative purposes only)

roduc

ion

Please read these instructions carefully before installing or

using your appliance. It is advisable to keep your purchase

and

installation receipts with these instructions in a safe place for

future reference. Included is some important safety informat

ion

in addition to guidelines and recommendations that will enab

you to take full advantage of all the functions available.

This quality appliance has been tested and certified to meet all

applicable UK electrical and safety standards.

This appliance must be installed and connected in

accordance with current regulations.

After unpacking the appliance ensure that there is no visible

damage. If the appliance has been damaged during transit,

do not use it, contact your retailer immediately.

Thank you for choosing this

ontpellier

branded

appliance. It has been designed to give years of trouble-

free use provided it is installed and maintained correctly.

Your 2 year Manufacturer's guarantee

THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.

Your new montpellier appliance carries a free guarantee which protects you against the

cost of repairs during the first 24 months from date of purchase provided that:

Any claim is accompanied by evidence of the model reference, model serial number and

proof of purchase, such as a Sales Receipt, showing that the appliance was purchased

within the 24 months prior to the date of claim.

What is not covered under the Guarantee:

·Any appliance not correctly installed and operated in accordance with the

manufacturer's instructions.

·Any appliance that is used for anything other than domestic purposes.

·Any defect caused by accident, misuse, unauthorized modification or inexpert repair.

·Cost of Call-out where a fault cannot be found with the appliance.

·Cost of Call-out for work covering routine maintenance, such as, but not exclusively,

cleaning of filters or defrosting.

·Cost of Call-out for work required to correct the alignment of doors following door

reversal procedures carried out by you.

·Use of the appliance by anyone other than the Householder.

·Use in any commercial environment.

·Consumable items, such as, but not exclusively, fuses in plugs, bulbs and breakable

items which require routine replacement.

·Repair costs incurred that have not been authorised by Repairtech and/or carried out

by a non-approved Repairtech engineer.

YOUR GUARANTEE IS VALID ONLY IN THE UK.

To Register your Appliance simply complete the card in your appliance pack and return it

with a stamp affixed or Alternatively you can Register online at www.repairtechuk.com

SERVICE HELP-LINE

Should your appliance develop a fault, please call the

Repairtech Service Helpline on: 01527-888133

Please remember to have all your product details available, including the model number,

serial number, date of purchase and your retailer’s details before registering a fault.

Your service call cannot progress without this information.

(Image shown for indicative purposes only)

Electrical Hotplate

Description of the Appliance

CONTENTS:

Section 1. Installation

Section 2. Safety Advice

Section 3. Operating the Appliance

Section 4. Maintenance

Section 1. Installation

-Remove all packaging, protective film and securing tape from the appliance.

-Position the appliance in a dry atmosphere.

- The following dimensions are provided as a guide for installation –your installer will

carry out the installation in accordance with the current regulations.

- This appliance must be connected by a suitably qualified electrician who will connect

the power cable in accordance with the current regulations.

To install this appliance, please proceed as follows:

1.1. Work-Surface Cut-Out

1.2. Position and Air Gaps

Ensure the hob is positioned as follows:

Adjoining Walls

1.3. Attaching the Fixing Brackets

1.4. Electrical Connection

This appliance can be fitted with a 13 amp plug and plugged into a standard 13 amp

socket.

We recommend that this appliance is ‘hard wired’to a suitable fused point adjacent to

the appliance housing and protected with a 20 amp fuse. Please note that a

switchable spur should be accessible above the work surface to allow the power to

be turned off by the consumer.

Your installer will connect this appliance in accordance with current regulations.

The wires in the mains lead are coloured in accordance with the following code:

Brown = L (Live), Blue = N (Neutral), Green/Yellow = Earth

If not supplied with a fitted cable, you should connect the power supply to the

appliance as follows:

Section 2. Safety Advice

-This appliance must be connected by a qualified electrician.

-Please read this booklet thoroughly before installing and switching on the

appliance. The manufacturer accepts no responsibility for incorrect

installation and usage.

-This appliance is guaranteed for Domestic Use Only.

-The appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning the use of the appliance by a person responsible for their

safety. Children should be supervised to ensure that they do not play with

the appliance.

-This appliance must only be used for cooking/heating foods and liquids.

Do not use it for any other purpose.

-Do not twist or bend the cables, and keep them away from hot surfaces.

-Following installation make sure that the power cable is not trapped

underneath the appliance.

-Keep the appliance surfaces clean. Failure to do this could lead to the

appliance malfunctioning.

-The surface of this appliance will get hot during use. Take care when

using the appliance and keep children well away.

-The surface of this appliance will remain hot after it has been turned off.

Do not touch or clean the hotplate until it has completely cooled down.

-If the power supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in order to

avoid a hazard.

Section 3. Operating the Appliance

3.1 Control Panel

3.2 Power and Cooking Functions

3.2.1. On-Off

To turn the required hotplate on or off, turn the control know to the required heat setting. The

red power indicator will be illuminated whilst the hob is on.

To turn the hotplate off, turn the control knob back to zero.

3.2.2. Setting the Hotplate Temperature

Turn the control knob between the low to high settings, 1 being low and 6 being high.

When you have finished with the hotplate, turn the control knob back to zero (0).

Rear Hotplate Front Hotplate

Section 4. Maintenance

Before any maintenance or cleaning work is carried out, DISCONNECT the

appliance from the ELECTRICITY supply and ensure that the appliance is

completely cool.

4.1. Cleaning the Hob Surface

Clean spillages from the hob surface as soon as possible after use. Always ensure

that the surface has cooled down before cleaning.

Use a soft cloth or kitchen paper to clean the surface.

Do not use other abrasive cleaners and/or wire wool etc as this may scratch the

surface of the hob.

4.2. What to do if something goes wrong

There is no power to the appliance:

-Check there is not a power cut

-Check there is power to the electrical connection

If after the pr

evious checks there is still a fault, please contact

the Repairtech Service Helpline below. Please ensure that you

have the model number, serial number, date of purchase and

retailers information available before you make the call.

Should your appliance develop a fault, please call the

Repairtech Service Helpline on:

01527-888133
