Montpellier MON-INT251 Manual de usuario

Installation and Operating Instructions

Models:

MON-INT251, MON-INT451

& MON-INT461F

30cm & 60cm Induction Hobs

(Pictures indicative of models supplied)

Please read these instructions carefully before attempting to install or use this appliance. It is

advisable to keep these instructions in a safe place for future reference.

N.B. Should your appliance require attention, our service agents will not be able to book

a service call without your unique serial number which can be found on the last page of

this manual.

Introduction

Thank you for choosing this Montpellier branded appliance. It

has been designed to give years of trouble-free use provided

it is installed and maintained correctly.

Please read these instructions carefully before installing or

using your appliance. It is advisable to keep your purchase and

installation receipts with these instructions in a safe place for

future reference. Included is some important safety information

in addition to guidelines and recommendations that will enable

you to take full advantage of all the functions available.

This quality appliance has been tested and certified to meet all

applicable UK electrical and safety standards.

This appliance must be installed and connected in

accordance with current regulations.

After unpacking the appliance ensure that there is no visible

damage. If the appliance has been damaged during transit, do

not use it, contact your retailer immediately.

Your 2 year Manufacturer's guarantee

THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.

Your new Montpellier appliance carries a free guarantee which protects you

against the cost of repairs during the first 24 months from date of purchase

provided that:

Any claim is accompanied by evidence of the model reference, model serial

number and proof of purchase, such as a Sales Receipt, showing that the

appliance was purchased within the 24 months prior to the date of claim.

What is not covered under the Guarantee:

Any appliance not correctly installed and operated in accordance

with the manufacturer's instructions.

Any appliance that is used for anything other than domestic

purposes.

Any defect caused by accident, misuse, unauthorized modification or

inexpert repair.

Cost of Call-out where a fault cannot be found with the appliance.

Cost of Call-out for work covering routine maintenance, such as, but

not exclusively, cleaning of filters or defrosting.

Cost of Call-out for work required to correct the alignment of doors

following door reversal procedures carried out by you.

Use of the appliance by anyone other than the Householder.

Use in any commercial environment.

Consumable items, such as, but not exclusively, fuses in plugs,

bulbs and breakable items which require routine replacement.

Repair costs incurred that have not been authorised by Repairtech

and/or carried out by a non-approved Repairtech engineer.

YOUR GUARANTEE IS VALID ONLY IN THE UK.

To Register your Appliance simply complete the card in your appliance pack and return

it with a stamp affixed or Alternatively you can Register online at

www.repairtechuk.com

SERVICE HELP-LINE

Should your appliance develop a fault, please call the

Repairtech Service Helpline on:

01527-888133

Description Of The Appliance

a) MON-INT251

1. 2000W (Plus Boost Function) Cook Zone

2. 1500W Cook Zone

3. Main Function Controls

4. Boost Function Control

b) MON-INT451

4. 3.

1. 2000W (Plus Boost Function) Cook Zone

2. 1500W Cook Zone

3. Main Function Controls

4. Boost Function Control

c) MON-INT461F

4. 5. 3. 5.

1. 2000W (Plus Boost Function) Cook Zone

2. 1500W (Plus Boost Function) Cook Zone

3. Main Function Controls

4. Boost Function Control

5. Flex Zone Controls

CONTENTS:

Section 1. Installation

Section 2. Safety Advice

Section 3. Operating the Appliance

Section 4. Maintenance

Section 1. Installation

-Remove all packaging, protective film and securing tape from

the appliance.

-Position the appliance in a dry atmosphere.

-The following dimensions are provided as a guide for

installation – your installer will carry out the installation in

accordance with the current regulations.

-Your installer will connect the power cable in accordance

with the current regulations.

To install this appliance, please proceed as follows:

1.1. Work-Surface Cut-Out

-Cut out the work-top as shown in the drawing below, ensuring

that the actual sizes used are as per the chart below.

-For installation and use, a minimum of 5cm must be

maintained around the cut-out.

-The work surface must have a thickness of at least 30mm.

-The work surface must be heat resistant.

Model L(mm) W(mm) H(mm) D(mm) A(mm)

B(mm)

X(mm)

MON-INT451 590 520 62 58 560 490 50 mini

MON-INT461F 590 520 55 51 560 490 50 mini

MON-INT251 288 520 62.5 58.5 268＋4 500＋4 50 mini

1.2. Space to Rear or Side Wall

A = 760mm B = 50mm (min) C = 20mm (min)

D = Air Gap/Intake E = Air Exit (5mm)

1.3. Fixing Brackets

1.4. Electrical Connection

These appliances have a total Power Rating of 3500W (MON-

INT251) and 7000W (MON-INT451 & MON-INT461F) and

must be ‘hard wired’ into a suitable fused spur adjacent to the

appliance housing.

The product must be installed by a Qualified Electrician.

Please note that a switchable spur should be accessible

above the work surface in order that the power can be

turned off.

Hob voltage

Total power

2 zone 220-240 3.5 KW

4 Zone 220-240 7.0KW
