MONTAGUE LEGEND C12 Manual de usuario
INSTRUCTION MANUAL
Gas Fired Heavy Duty
Counter Ranges
MONTAGUE
Models:
C12, C18, C24 & C36
Keep area around appliances free and clear from combustibles.
PLEASE RETAIN THIS MANUAL
FOR FUTURE REFERENCE.
These instructions should be read thoroughly before attempting installation.
Set up and installation should be performed by qualified installation personnel.
Effective October 1, 2001: All Montague
heavy duty ranges and broilers will be built
with orifices and regulators set to operate
on 6” W.C. manifold pressure
You must specify the manifold pressure
and gas type listed on the model identifi-
cation plate to order replacement burner
valves, orifices, or pressure regulators.
15
SERVICE
ORIFICE SIZE CHART DRILL SIZE
Type of Burn-
er
ABCD Open
Top
20,000
D Open
Top
30,000 Front Rear
F
Natural Gas
4.0” W.C.
50 46 35 45 37 45 50 45
Natural Gas
6.0” W.C.
48 42 45 52
Propane Gas
10.0” WC
56 55 50 55 55 56 55
D 1/2 Hot Top
