Modway Render MOD-7070 Manual de usuario

A S S E M B L Y I N S T R U C T I O N S

MOD-7070

Questions? Contact us!

609.256.9000 • [email protected]

V2.01.10.22

www.modway.com

Page 2of 12

Let’s get started!

Read through all of

the instructions

before starting

Approx. 60 minutes

assembly time

2 people recommended

for assembly

Care instructions are

listed in the last step

of this manual

Make sure you have all

parts and components

before discarding any

packing materials

Only use hand tools to assemble this item. Do not use power tools.

Do not tighten bolts or screws completely until all hardware is lined

up and inserted into the holes.

Do not over-tighten screws and bolts to avoid stripping the

hardware or cracking the item.

Assemble your item on a flat, carpeted area, with plenty of space to

work. This will prevent damage and scratches to your floors or the item

while you’re assembling the product.

Keep all components and packaging out of reach of children or

animals to avoid risk of choking or suﬀocation.

Furniture components:

Provided hardware: What you need:

Phillips Head Screwdriver

Phillips

Missing parts or hardware? Need assistance?

609.256.9000 • cs@modway.com

R Cam Lock Cap x4

1 Top Panel x1

2 Right Side Panel x1

8 Right Leg Support x1

7 Back Leg Panel x1

6 Front Leg Panel x1

5 Back Panel x1

4 Bottom Panel x1

3 Left Side Panel x1

9 Left Leg Support x1

14 Drawer Back x1

13 Drawer Base x1

12 Drawer Head x1

10 Drawer Right x1

11 Drawer Left x1

A JCBC M6 x 70mm x2

J Drawer Runner Right x1

B Wooden Dowel Ø6 x 30mm x28

C Cam Lock- Ø15 x 12mm x12

D Cam Bolt- Ø6 x 32mm x14

G C/board Runner Left x1

Q Allen Key x1

P C/board Screw Ø4 x 38mm x2

E Floor Glide-B321 x4

F C/board Screw Ø3.5 x 16mm x16

N JCBCW M6 x 50mm x4

M Plastic Corner Block x4

L Cam Lock- Ø12 x 9.9mm x2

H C/board Runner Right x1

I Drawer Runner Left x1

K JCBC M6 X 60mm x2

O Screw Ø4 x ¾ Inch x4

15 Fixed Shelf x1

Page 3of 12

Step 1

Step 2

Wooden Dowel Ø6 x 30mm x24

Floor Glide-B321 x4

C/board Screw Ø3.5 x 16mm x4

Right Side Panel x1

Left Side Panel x1

Front Leg Panel x1

Back Leg Panel x1

Right Leg Support x1

Left Leg Support x1

Cam Bolt- Ø6 x 32mm x8

Top Panel x1

H AR DW A RE

C O M P O N E N T S

Front Leg Panel x1

Back Leg Panel x1

H AR DW A RE

C O M P O N E N T S

Fixed Shelf x1

Cam Bolt- Ø6 x 32mm x4

Page 4of 12

Step 3

Step 4

Cam Lock- Ø15 x 12mm x2

Right Leg Support x1

Left Leg Support x1

Front Leg Panel x1

Cam Lock- Ø15 x 12mm x2

Right Leg Support x1

Left Leg Support x1

Back Leg Panel x1

H AR DW A RE

C O M P O N E N T S

H AR DW A RE

C O M P O N E N T S

Page 5of 12

Step 5

Step 6

C/board Screw Ø3.5 x 16mm x6

Left Side Panel x1

Right Side Panel x1

C/board Runner Left x1

C/board Runner Right x1

H AR DW A RE

C O M P O N E N T S

H AR DW A RE

Cam Lock- Ø15 x 12mm x4

Left Side Panel x1

C O M P O N E N T S

Right Side Panel x1

Fixed Shelf x1

BOTTOM VIEW

Page 6of 12

Step 7

Step 8

JCBCW M6 x 50mm x4

Left Side Panel x1

Right Side Panel x1

JCBCW M6 x 70mm x2

Bottom Panel x1

Right Side Panel x1

Bottom Panel x1

Left Side Panel x1

Front Leg Panel x1

H AR DW A RE

C O M P O N E N T S

H AR DW A RE

C O M P O N E N T S

Allen Key x1

Back Leg Panel x1

Allen Key x1

JCBCW M6 x 60mm x2

Page 7of 12

Step 9

Step 10

Cam Lock- Ø15 x 12mm x4

Top Panel x1

Right Side Panel x1

Left Side Panel x1

Back Panel x1

C O M P O N E N T S

H AR DW A RE

C O M P O N E N T S

Cam Lock Cap x4

Page 8of 12

Step 11

Step 12

Screw Ø4 x ¾ Inch x4

Plastic Corner Block x4

Back Panel x1

Wooden Dowel Ø6 x 30mm x4

Drawer Right x1

Drawer Left x1

Drawer Back x1

H AR DW A RE

C O M P O N E N T S

H AR DW A RE

C O M P O N E N T S

Page 9of 12

Step 13

Step 14

Cam Bolt- Ø6 x 32mm x2

Drawer Head x1

C/board Screw Ø4 x 38mm x2

Drawer Right x1

Drawer Left x1

Drawer Back x1

H AR DW A RE

C O M P O N E N T S

H AR DW A RE

C O M P O N E N T S

Page 10 of 12

Step 15

Step 16

Cam Lock- Ø12 x 9.9mm x2

Drawer Right x1

Drawer Left x1

Drawer Head x1

Drawer Base x1

C/board Screw Ø3.5 x 16mm x6

Drawer Runner Left x1

Drawer Runner Right x1

Drawer Right x1

Drawer Left x1

Drawer Back x1

H AR DW A RE

C O M P O N E N T S

H AR DW A RE

C O M P O N E N T S

Step 15.1

Step 15.2
