Modway MOD-5472 Manual de usuario

Allen Wrench M6 x1

Customer Service 908-368-1025︱www.modwayfurniture.com Page 1 of 3

MOD-5472 TWIN BED FRAME

Hardware:

Component:

A Bolt M8x20mm x16

C Nut M6 x2

D Allen Wrench M8 x1

1 Short Board x2

Thank you for purchasing the MODWAY TWIN BED FRAME！

Before you start, here is some helpful advice:

1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step

instructions.

2.Owing to the size and weight of the bed frame, we recommend that it is assembled by two adults, on a carpeted

or padded area, in the room that it is intended for. Approx assembly time: 30 minutes.

3.Please do not use any tools other than those provided or recommended in these instructions.

4.Please do not throw away any of the packaging or the instruction until you have checked all the components and

hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe

environmentally friendly way.

5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the

components from time to time, so please save the tools that has been provided.

6.Please keep all fitting out of reach of children.

Bolt M6x45mm x2

E Open Wrench x1

F Side Plastic Cover x24

2 Long Board x2 3 Leg x4

4 Stretcher x1 5 Slat x12

Customer Service 908-368-1025︱www.modwayfurniture.com Page 2 of 3

MOD-5472 TWIN BED FRAME

Bx2 Cx2

Gx1

Ex1

STEP 1:

Inert the end of Leg (3) into Short Board (1) and Long Board (2) as shown.

Secure by using 4 pieces of Bolt (A), do not fully tighten Bolts (A) by using Allen Wrench (D) at this step.

Repeat the same steps for the remaining 3 pieces of Leg (3).

Tighten all Bolts (A) by using Allen Wrench (D) clockwise until secure.

STEP 2:

Place Stretcher (4) to the assembled Long Board (2) as shown.

Secure by using 2 pieces of Bolt (B) and 2 pieces of Nut (C) as shown.

Tighten Bolts (B) by using Allen Wrench (G) clockwise until secure.

Hardware & Tool required

Ax16

Dx1 Hardware & Tool required

2 1

A A A A

Customer Service 908-368-1025︱www.modwayfurniture.com Page 3 of 3

MOD-5472 TWIN BED FRAME

Fx24

STEP 3:

Hardware & Tool required

Insert 2 piece of Side Plastic Cover (F) into each end of Slat (5) as shown.

Insert the assembled Side Plastic Covers (F) into the corresponding holes on Long Board (2) as shown.

Repeat the same steps for the remaining 11 pieces Slat (5).

Assembly is complete. Your bed frame is ready to be enjoyed now!
