NOTE!
This guide is only valid for installing and connecting the 2MP Speed Dome Low Light Camera.
For more information on the camera, please refer to the other documents (see Further Reading, p.
8).
Important Installation Notes
nThis camera must be installed by qualified personnel and the installation should conform to
all local codes.
nTo prevent damage, loosen the mounting screws before moving the camera.
nTo ensure that the unit is not affected by vibration, twisting, etc. after adjusting the camera,
tighten all mounting screws properly.
nThis product must not be used in locations exposed to the dangers of explosion.
nInstall this product in a well-ventilated spot and do not close off any vent openings.
nDo not use this product in a dusty environment.
nProtect this product from moisture or water entering the housing.
nInstall this product as outlined in this document. A faulty installation can damage the
product!
nDo not replace batteries of the camera. Risk of explosion may occur if the battery is replaced
by an incorrect type.
nThis equipment is not suitable for use in locations where children are likely to be present.
nExternal power supplies must comply with the LPS requirements and share the same power
specifications with the camera.
nIf using a Class I adapter, the power cord shall be connected to a socket-outlet with proper
ground connection.
nTo comply with the requirements of EN50130-4 regarding the power supply of alarm systems
for 24/7 operation, it is highly recommended to use an uninterruptible power supply (UPS)for
1 / 9
Quick Installation
MOBOTIX 2MP Speed Dome Low Light Camera
Mx-SD1A-230-LL
©2022MOBOTIX AG
Quick Installation 2MP Speed Dome Low Light Camera
powering the product.
nThis equipment is to be connected only to PoE networks without routing to other networks.
NOTE! Observe the MOBOTIX MOVE Installation Hints document to ensure optimum performance
of the camera features.
CAUTION! To prevent damage, loosen all mounting screws before adjusting the camera.
NOTE! To ensure that the unit is not affected by vibration, twisting, etc. after adjusting the camera,
properly tighten all mounting screws.
Camera Connectors
No. Connector Definition
1Power Con-
nector (DC12V)
DC12V power connection
2Console Con-
nector
This connector is used to burn firmware into the camera when the cam-
era is returned for repair/maintenance. Please contact the camera man-
ufacturer for further information.
3RJ-45 Port For network and PoE+ connections
4Power Con-
nector (AC24V)
AC24V power connection (see Power Connector, p. 3 below)
5BNC* For analog video output (available only with max. 2 activated streams)
6Audio/Alarm
I/O & RS485
Connector**
Audio/Alarm I/O & RS485 connection (see Audio/Alarm I/O & RS485 Con-
nector, p. 4 below)
2 / 9
No. Connector Definition
7Reset Button Press the button with a proper tool for at least 20 seconds to restore
the system.
8SD Card Slot Insert the SD card into the card slot to store videos and snapshots. Do
not remove the SD card when the camera is powered on.
*Contact the manufacturer for a compatible BNC cable.
**Do NOT connect external power supply to the alarm I/O connector of the camera.
NOTE!
nTo purchase a power adapter, please contact MOBOTIX for further information.
nThe DC12V power jack and the AC24V power connector cannot be used at the same time
without causing unforeseeable damage.
microSD Card Slot/Reset Button
The positions of microSD card slot and default button are shown in the figure above.
microSD Card Slot
Insert the microSD card into the card slot to store videos and snapshots. Do not remove the
microSD card when the camera is powered on.
NOTE! It is not recommended to record with the microSD card for 24/7 continuously, as it may
not be able to support long-term continuous data read/write. Contact the manufacturer of the
microSD card for information regarding the reliability and the life expectancy.
Reset Button
Press the default button with a suitable tool for at least 20 seconds to restore the system.
Power Connector
Pin Definition
1AC24V L
2GND
3AC24V N
Camera Cabling
Power Connection
To power up the camera, connect the DC12V or AC24V power adaptor to the power connector of the
camera and the power outlet. Refer to the diagram and pin definition below for AC24V power con-
nection.
Quick Installation 2MP Speed Dome Low Light Camera
3 / 9
Quick Installation 2MP Speed Dome Low Light Camera
Alternatively, you can use an Ethernet cable and connect it to the RJ-45 port of the camera and a
PoE+ switch (Class 4).
Zero Downtime Power Switching (ZDT)
When users connect DC12V power jack and the RJ-45 port at the same time, the power input comes
from the DC12V connector. If the DC12V power source fails, the camera will switch power input seam-
lessly to the RJ-45 port until the DC12V power source is restored.
Ethernet Cable Connection
Connect one end of the Ethernet cable to the RJ-45 connector of the All-in-One cable, and plug the
other end of the cable to the network switch or PC.
NOTE!
nIn some cases, an Ethernet crossover cable may be needed when connecting the camera dir-
ectly to the PC.
nCheck the status of the link indicator and the activity indicator LEDs of the switch. If the LEDs
are unlit, please check the LAN connection.
nGreen Link LED indicates good network connection.
nOrange Activity LED flashes for network activity indication.
NOTE! The ITE is to be connected only to PoE networks without routing to the outside plant or
equivalent description.
Audio/Alarm I/O & RS485 Connector
Please refer to the diagram and pin definition tables below for using the audio/alarm I/O & RS485 con-
nection.
Pin Definition
1Audio Out
2GND (Audio I/O)
3Alarm Out A1
4Alarm Out A2
5Alarm Out B1
6Alarm Out B2
7RS485 D+
8RS485 D-
4 / 9
Pin Definition
9Alarm In 4
10 Alarm In 3
11 Alarm In 2
12 Alarm In 1
13 GND (Alarm I/O and RS485)
14 Audio In
Camera Installation Notice
NOTE! For safety reasons, it is recommended to hook up the camera's anti-drop ring ① with the
anti-drop chain ② of the pendant when installing the camera. For more information about the
pendant and anti-drop chain, please contact MOBOTIX.
Accessing the Camera
The 2MP Speed Dome Low Light Camera supports all current browsers without requiring any addi-
tional plug-ins or add-ons (e.g. for H.264/H.265/MJPEG support).
Camera Login
The default IP address of the camera is: 10.x.x.x. By default, the camera starts as DHCP client and
automatically tries to get an IP address from a DHCP server.
Quick Installation 2MP Speed Dome Low Light Camera
5 / 9
Quick Installation 2MP Speed Dome Low Light Camera
1. Enter the camera’s IP address in the URL bar of the web browser and hit “Enter”.
2. Enter the default username (admin) and password (meinsm).
NOTE! User names and passwords are case sensitive.
3. You will be prompted to set a new admin user password.
NOTE! The password can have between 6 and 16 characters (at least one digit, no special char-
acters allowed).
4. After setting a new password, you will be prompted to log in again. Remember to use the new
password.
Browser-Based Viewer
The main page of the IP camera user interface is shown as the figure below. The function buttons
vary depending on the camera model.
6 / 9
Camera Maintenance
It is recommended that you perform the following maintenance tasks at regular intervals to keep
the 2MP Speed Dome Low Light Camera in good working condition:
nClean the using plain water and a soft cloth.
CAUTION! Do not use any detergents or alcohol to prevent damage to the coating!
nCheck the mounting and make sure that all screws are properly tightened to prevent the cam-
era from falling down.
nWhen opening the camera, add a silca gel dry pack to prevent condensation accumulating at
the .
Quick Installation 2MP Speed Dome Low Light Camera
7 / 9
EN_07/22
MOBOTIX AG • Kaiserstrasse • D-67722 Langmeil • Tel.: +49 6302 9816-103 • [email protected] • www.mobotix.com
MOBOTIX is a trademark of MOBOTIX AG registered in the European Union, the U.S.A., and in other countries. Subject to change without
notice. MOBOTIX do not assume any liability for technical or editorial errors or omissions contained herein. All rights reserved. ©MOBOTIX
AG2018
