DIGITAL CLASSIC CAMERA 5.1

Instruction manual

Mode-button

Shutter-button

Up-button

Down-button

Charging the battery

Connect the camera to your computer’s USB port

through the USB cable provided while the camera

is turn off. This starts the charging automatically.

When the battery is being charged, there is a green

LED indicator light up in the USB connector area.

When this indicator is turn off, the charging is

completed.

Switching the camera on

To switch your camera on, press and hold the mode

button. To switch your camera off, press the mode

button until the Setup Screen shows up. Press the

down button to highlighte

Power Off

and then press

the shutter button to switch your camera off.

Battery lock

Playback mode

Review your photos or movies

on the display screen

Press the mode button repeatedly until you reach

the playback mode ( ).

Use the up or down buttons to scroll through the

stored images.

To review a movie clip, press the shutter button

to start viewing, to stop viewing before the end

of the clip press the shutter button again.

Image quality

Low

(*) – 2608 x 1956 px up to 144 images

Normal

(**) – 2608 x 1956 px up to 110 images

High

(***) – 2608 x 1956 px up to 73 images

Press the mode button until you enter the Set-up

menu. Select

Camera

and press the shutter button.

You will enter the camera menu.

Taking your ﬁrst picture

Frame your subject

When the camera is turn on, the camera is in Take

Photo mode, will show on the display screen,

if it is not visible, press mode button until it is.

Frame the subject you want to capture in the display

screen on the back of your camera or through the

viewﬁnder.

Take the picture

Press the shutter button to take the picture. Hold

the camera steady until you hear a

beep

. This tells

you that a photo has been taken.

Setup

Camera

Power Off

Format

Auto Off

Buzzer

Your camera will auto-

matically turn itself off in

60 seconds if unused to

conserve battery power.

Camera

Flash

Quality

Movie

Self Timer

Quality

Low

Normal

High

Select

Quality

and press the shutter button.

You will enter the quality menu where you can

select the different quality settings using the up

and down buttons.

Press the shutter button again to conﬁrm your

selection.

Increase the camera memory

with an SD card

SD (Secure Digital) cards will increase the amount

of memory that your camera will have available.

Enabling you to store more images and videos

between downloads.

The DCC supports SD Cards up to 16 GB (SDHC).

Inserting an SD card

Open the battery compartment and insert the SD

card in the SD card slot with the gold contacts

facing the lens.

Important: When the SD card is locked (protected),

card lock icon will appear on the display screen and

photo and videos cannot be taken.

Downloading your images to your

computer

Note: You do not need to install camera drivers for

Windows versions 2000/ME/XP and Mac OS 9.x or

OS X. Your camera does not support version older

than those stated above.

Note: When your camera is connected, your com-

puter provides power through the USB cable, saving

your camera‘s battery power.

Connecting your camera to the computer

To connect your camera to your computer, the ca-

mera must always be turned on ﬁrst. Then connect

the camera to your computer using the provided

USB cable (the smaller head connect to the ca-

mera side and the larger head side connect to the

computer side).

Deleting unwanted images

Delete your image one at a time

In Playback mode ( ), use the up or down buttons

to select the image you want to delete.

Press shutter button to view the Playback menu,

scroll to

Delete One

and press the shutter button.

Select

Yes

and press the shutter button again. The

selection is deleted from the camera memory.

Delete all your images at once

In Playback mode ( ), press shutter button to view

the playback menu, scroll to

Delete All

and press

the shutter button. Select

Yes

and press the shutter

button again. All saved images will be deleted from

the memory.

Distance Setting

The depth of ﬁeld of the camera extends from

2 m to inﬁnity, i.e. focusing is not required within

this range. For close-focus shots you can inﬁnitely

adjust distances between 0.5 m and 2 m using the

depth of ﬁeld ring.

depth of ﬁeld

ring

• 5.1 Megapixels

• 2.0” TFT/LCD-Display

• 128MB internal memory

• SD cards up to 16GB (optional)

• Compatible with

MINOX Classic Camera ﬂash

• Rechargeable Li-Ion battery

MINOX GmbH

Walter-Zapp-Str. 4

D-35578 Wetzlar, Germany

Tel.: +49 (0) 6441 / 917-0

Fax: +49 (0) 6441 / 917-612

e-mail: info@minox.com

www.minox.com

DIGITAL CLASSIC CAMERA 5.1

99468
