MIMAKI CJV150-75 Manual de usuario

Mimaki Europe B.V.

Sign Graphics Products

The new high quality Print&Cut entry models

Product Guide

The information in this document is subject to change without notice.

07-03-2019

V1.71EU

Mimaki Europe B.V.

Sign Graphics Products

•The contents of this presentation are intended only for Mimaki authorized

resellers. Authorized persons are not permitted to distribute, copy or change

this presentation without explicit approval of Mimaki Europe B.V.

•Contents and technical explanations in this presentation are based on the

test results achieved at Mimaki at the time of testing and are not a guarantee

for performance. Substrates should be tested beforehand.

•In addition, the contents in this presentation do not lead to any legal

obligations from Mimaki and Mimaki does not take any responsibility. Please

verify in advance whether your intended prints will result in sufficient

quality.

•Contents of this presentation are subject to change without prior notice for

improvement. Compositors errors reserved.

Mimaki Europe B.V.

Sign Graphics Products

Features

•Mimaki technologies for exceptional print quality

•Mimaki Advanced Pass System 3 (MAPS3) reduces banding and

produces smoother images

•Variable dot printing produces smoother gradients and quartertones

•Mimaki Expand Color mode is available for more vivid and high contrast

colors with RasterLink6*

•3-way intelligent heaters optimize dot gain

•A wide variety of inks broaden application

•Supports 6 different ink types: SS21, ES3, BS3, BS4, SB53 and SB54

•Printing metallic colors with high-intensity silver ink

•Wider color gamut printing with orange ink

•Light black ink produces accurate grayscale printing without color shifts

•White ink achieves high opacity printing

* Supported by RasterLink6 ver. 4.11 or later, and device profile ver. 3.5

Mimaki Europe B.V.

Sign Graphics Products

Features

•Versatile Print&Cut functions

•Zero margin crop mark reduces the waste of media

•Supports thin media such as heat transfer media by Cut & Print function

•Dotted line cut function cuts backing sheet leaving a few minimal joints

•Over cut and Corner cut functions cut edges sharp even using thick

media

•Segment compensation achieves accurate long-length cutting

•Continuous crop mark detection for unattended Print&Cut operation

•Several functions to support unattended operation

•Nozzle Check Unit allows printing without nozzle clogging

•UISS performs continuous ink supply while unattended printing

•Stable feeding of heavy media, max weight of 40kg and max diameter of

250mm

Mimaki Europe B.V.

Sign Graphics Products

System configuration

Options

MBIS3

Drying fan

Air exhaust unit

Static prevention sheet

Front cover

8x Eco-cartridge for 600ml BS3/BS4 inks

Including Rip software

Works also with:

USB 2 0

5m(15ft) cable is recommended

Connection

Recommended PC configuration

CPU: Core i5 3.5GHz

Memory: 8GB

HDD: 500GB

I/F : USB2.0, 4 ports or more

ODD: DVD-ROM

Network: 1000BASE-T

Compatible OS: Windows Vista(32/64bit)

Windows 7(32/64bit)

Windows 8(32/64bit)

Windows 10(32/64bit)

Monitor: 1366x768

Mimaki Europe B.V.

Sign Graphics Products

Ink type

SS21 ES3 BS3 / BS4* Sb53 Sb54

Eco solvent Eco solvent

(Low odor) Solvent Sublimation Sublimation

Colors 10C*6C 4C 6C* 4C

Ink Sets

6C+WSi: Silver included 4C: High speed printing 4C: High speed printing 4C: High speed printing 4C: High speed printing

4C: High speed printing 6C: Smooth Result 6C: Smooth Result

8C: Smooth result &

vibrant expression

6C+WW: 6C plus white

printing

Lk/Or/W/Si included

Lk/Or/W 2 included

Ink

Capacity

MCYKLcLmLkOr:

-440ml cartridge

-2L Ink pack (for MBIS3)

WSi: 220ml cartridge

-440ml cartridge

600ml Ink pack

(with Eco-cartridge)

-2L Ink pack (for MBIS3)

-440ml cartridge

-2L Ink pack (for MBIS3) 2L Ink pack (for MBIS3)

**Up to 8 colors can be set

out of 10 colors. *BS4 has low odor *K is also available

M C Y KKY C M

M C Y KLc Lm Lk Or

MCYKKY C M

M C Y KKY C M

Ink type / Ink set

MT BLT YT KT KT YT BLT MT

M C Y KLk Or W W

M C Y KLk Or WSi

Mimaki Europe B.V.

Sign Graphics Products

Print head configuration

•1 print head configuration

•Capable of ejecting 7 different drop sizes of 4pl/7pl/8pl/14pl/16pl/24pl/35pl

•Works in high quality and high speed modes

•Delivers precision droplet placement in three sizes

Nozzle row length

Approx.25.4mm

(1 inch)

Nozzle width

Approx.31mm

(1.2 inch)

1-head:1440-nozzle

(180-nozzle x 8-lines)

123 4 5 6 7 8

Mimaki Europe B.V.

Sign Graphics Products

Highly versatile printer

•Larger ink drops

•3 different drop sizes are automatically selected from the 7 drop sizes,

depending on the selected print quality (profile)

•When working with SS21, the 7 drop sizes are 4/7/8/14/16/24/35pl

•For high speed printing with high densities, the variable dot technology with a

maximum dot size of 35pl is used. (45.4m²/h with SS21/BS3/BS4, and 48m²/h

with Sb53/Sb54)

•This gives the printer a wide coverage, from high resolutions, to low resolution

printing with higher densities

Case 1 : Maximum dot size =21pl Case 2 : Maximum dot size =35pl

Large

21ｐ

ｌ

Middle

14ｐ

ｌ

Small

4ｐ

ｌ

1 /360 inch

1 /360

inch

Large

35ｐ

ｌ

Middle

14ｐ

ｌ

Small

4ｐ

ｌ

1 /360 inch

1 /360

inch

Low density due to a gap between the dots

↓

Not suitable for high speed mode (low resolution)

High density with no gap between the dots

↓

Suitable for High speed mode

Mimaki Europe B.V.

Sign Graphics Products

1,7

3,6

5,4

7,1

8,5

10,5

1,9

4,2

6,2

8,2

9,8

12,2

14,3

0 5 10 15 20

Super Smooth

1440x1440,16P,Bi

High Quality

720x1440,12P,Bi

High Quality

720x1080,8P,Bi

Standard②

720x720,6P,Bi

Standard①

720x720,5P,Bi

High Speed

720x720,4P,Bi

Draft

540x720,4P,Bi

CJV150-107

CJV150-75

4,3

7,1

10,5

40,2

5,0

8,2

12,2

14,3

28,5

45,4

010 20 30 40 50

High Quality

720x1440,10P,Bi

Standard②

720x1080,6P,Bi

Standard①

720x720,4P,Bi

High Speed

540x720,4P,Bi

Draft

540x360,2P,Bi

Super Draft

360x360,1P,Bi

CJV150-107

CJV150-75

Print speed (SS21/BS3/BS4)

•Ink set: 4C, CMYK

PVC Banner

The print modes shown in this document are the performance of the printer itself. The profiles are created selectively depending on the media type. When the

profile is not available, use MPM-3 to create the profile for the media.

m²/h

* MAPS works with “Quality priority” setting in RasterLink6

** MAPS does not work

Mimaki Europe B.V.

Sign Graphics Products

1,3

2,4

2,7

3,6

4,3

5,4

1,5

2,8

3,1

4,2

5,0

6,2

0 5 10 15

Super Smooth

1440x1440,20P,Bi

High Quality

720x1440,18P,Bi

Standard②

720x1080,16P,Bi

Standard①

720x1080,12P,Bi

High Speed

720x720,10P,Bi

Draft

720x720,8P,Bi

CJV150-107

CJV150-75 2,4

3,1

4,3

5,4

6,2

12,5

20,7

2,8

3,6

5,0

6,2

7,4

14,3

23,3

0 5 10 15 20 25

Super Smooth

720x1440,18P,Bi

High Quality

720x1080,14P,Bi

Standard②

720x720,10P,Bi

Standard①

720x720,8P,Bi

High Speed

540x720,8P,Bi

Draft

540x360,4P,Bi

Super Draft

360x360,2P,Bi

CJV150-107

CJV150-75

Print speed, SS21, 6C/8C ink set

•Ink set: -6C (CMYKLcLm+WW/WSi) or (CMYKOrLk+WW/WSi)

-8C (CMYKLcLmLkOr)

PVC Banner

m²/h

* MAPS works with “Quality priority” setting in RasterLink6

** MAPS does not work
