Milesight UC100 Manual de usuario

UC100

Quick Start Guide Cloud App

www.milesight-iot.comMilesight IoT Co., Ltd.

All software & files can be downloaded from

https://www.milesight-iot.com/documents-download/

SMART IOT CONTROLLER

1. Packing List 2. Hardware Introduction

3. LED Patterns

1 × Quick Start Guide

1 × UC100 Controller

1 × Terminal Block 1 × Type-C Cable

& Power Adapter

2 × Wall Mounting Kits

Type-C Port 120Ω Terminal

Resistor Switch

Embedded LoRa

Antenna

LED Indicator

DC Power Interface

RS485

Static On

Static On →Slowly Blinks

Static On →Quickly Blinks

Slowly Blinks

Static On

Device Status LED Status

Reboot: hold the reset button inside the device for more

than 3 seconds

Reset to factory default: hold the reset button inside the

device for more than 10 seconds

Fail to acquire data from data interfaces

System is functioning properly

Device upgrade or system error

Loss or damage to the equipment due

If defects or damages are caused by

Limited Warranty Protection

12 months from original purchase date

against all manufacturing defects.

This Warranty does not cover:

to improper maintenance, or failure to

follow operating instructions.

the use of unauthorized parts or by

service from other than our authorized

agent.

Dealer Stamp

Email: [email protected]

Tel:86-592-5085280

BuildingC09,SoftwareParkPhaseIII,Xiamen361024,Fujian,China

Model:

Date of Purchase:

QC:

Serial Number:

Milesight IoT Co., Ltd. www.milesight-iot.com

4. Configuration Guide 6. Warranty

Steps:

Ensure that the RS485 sensor has connected to UC100, connect

the UC100 device to computer via type-C port and open the

ToolBox, select serial port as USB port and type as “General”,

then type the password to log in ToolBox and configure the device.

(Default login password: 123456)

Preparation:

Type-C USB cable

PC (Windows 10 is recommended)

ToolBox Software: it can be downloaded from Milesight

IoT website.

https://www.milesight-iot.com/software-download/

5. Installation

Remove the back cover of the device, fix the wall plugs into the wall

according to drilling position as referred.

Then screw the cover on the mounting positions and install back the

device.

80g双胶纸

UC100

63x63mm

折页版

44.005.000149

V1.0

客户

编码

机型

材质

尺寸

工艺

版本
