Self-install Instructions

PureFiber-ADSL Failover (Upgrade from ADSL) - Self Install Guide

Skyway West - May 2019

Your current setup

Actiontec

WiFi Router

This is what your service

setup will look like

immediately after Telus

completes their PureFiber

Installation

Please follow this guide to

fully complete the

installation of your

connectivity solution.

IMPORTANT:

You will lose connectivity

during this process. Please

proceed ONLY when it is

okay to do so.

Call Skyway West Support if

you need assistance:

604-482-1212

Fiber ONT

(Provided by Telus)

Wall Jacks

DSL Modem

RouterBoard Management Router

(Sent to you by Skyway)

Panel

Skyway RouterBoard

Management Router

Represented in this guide

by this gray box

You will receive this

RouterBoard management

router from Skyway West.

Please connect it (according

to this guide) in order to

complete your setup.

You may also receive other

equipment from Skyway,

depending on the specifics

of your solution.

Don’t forget to plug in!

All devices described within

this guide must be plugged

in to appropriate power

outlets.

The diagrams herein do NOT

show power cords in order

to keep them simple and

easy to understand.

1. Plug your ADSL Modem to the wall jack, if required

Actiontec

WiFi Router

Fiber ONT

(Provided by Telus)

DSL Modem

Wall Jacks

Actiontec

WiFi Router

Fiber ONT

(Provided by Telus)

Wall Jacks

2. Unplug your Fiber ONT from your WiFi router

An Optical Network Terminal

(ONT) is the device that a

fiber line terminates into,

and converts optical data

into ethernet-protocol data.

DSL Modem

PureFiber Failover RouterBoard Port Diagram

Plug the Fiber ONT into port

ONE (Internet / PoE port) of

the Skyway RouterBoard.

Plug the ADSL or Cable

modem into port TWO of

the Skyway RouterBoard

Plug the Telus Actiontec WiFi

router into port FOUR of the

Skyway RouterBoard

Plug your network firewall

into port FIVE of the Skyway

RouterBoard

PureFiber ONT

ADSL (or Cable) Modem Actiontec WiFi Router

Your network firewall

Fiber ONT

(Provided by Telus) Skyway RouterBoard

Management Router

Actiontec

WiFi Router

Wall Jacks

DSL Modem

Protected

Company Network

Skyway RouterBoard

Management Router

Your Complete Solution

Fiber ONT

(Provided by Telus)

Public WiFi Network

Actiontec

WiFi Router

The Actiontec T3200 WiFi router is

configured for public WiFi. WiFi

internet traffic is separated from

LAN internet traffic; WiFi users

cannot reach your LAN directly

through our management router.

In order to reach your internal

network, WiFi traffic is tunneled to

Skyway and returns through your

Internet connection to your LAN

firewall.

If you prefer to not use the

Actiontec WiFi router, please inform

provisioning@skywaywest.com .

The public WIFi SSID and Password

are written on the Actiontec WiFi

router.

Wall Jacks

DSL Modem
