Miele DGC 6800 Manual de usuario
Installation instructions
Information is subject to change. Please refer to our website to obtain the most
current product specification, technical & warranty information.
The installation steps are described in the enclosed "Installation Diagram".
Leave these instructions with the appliance for the consumer/user.
Information is subject to change. Please refer to our website to obtain the most
current product specification, technical & warranty information.
79
Disposal of packing material
The cardboard box and packing
materials protect the appliance during
shipping. They have been designed to
be biodegradable and recyclable.
Please recycle.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of children.
Danger of suffocation!
Disposal of an old appliance
Old appliances may contain materials
that can be recycled. Please contact
your local recycling authority about the
possibility of recycling these materials.
Ensure that the appliance presents no
danger to children while being stored
for disposal. Before discarding an old
appliance, unplug it from the outlet, cut
off its power cord and remove any
doors to prevent hazards.
Caring for the environment
80
Make sure that the power to the
machine is OFF before installing or
performing maintenance or repairs.
All electrical work should be
performed by a qualified electrician
in strict accordance with national
and local safety regulations.
Installation, repairs and other work
by unqualified persons could be
dangerous.
Verify that the voltage, load and circuit
rating information found on the data
plate match the household electrical
supply before installing the coffee
system.
Do not connect the appliance to a
power inverter or directly to power
produced outside of the normal
electrical grid (i.e. direct solar or wind
power source).
Direct connection to such power
sources can cause power surges and
tripped breakers when the appliance is
turned on, and could damage the
appliance.
Do not connect the appliance to energy
saving plugs or outlets. The reduction
of power to the appliance caused by
these devices will cause the appliance
to run hot and may damage it and/or
shorten its usable life.
If there is any question concerning the
electrical connection of this appliance
to your power supply, please consult a
licensed electrician or contact Miele’s
Technical Service Department. See
back page for contact information.
WARNING:
THIS APPLIANCE MUST BE
GROUNDED
Important
The coffee system comes equipped
witha6ft(1.8 m) power cord with a
NEMA 5-15P molded plug for
connection to a 120 V, 15 A, 60 Hz
power supply.
Electrical connection
81
Installation and combination options
The system is designed to be built into cabinetry.
Installation
82
It is also possible to combine it with other built-in Miele appliances. If the coffee
system is to be built in above another appliance, there must be a full-width, closed
shelf between them (exception: installation with a warming drawer).
Installation
83
Ventilation
When installing the coffee system,
make sure that it is sufficiently
ventilated at the back so that steam
and hot air can escape.
The ventilation openings in the
surrounding cabinets and the space
below the ceiling must be at least
78 3/4"² (200 cm²).
Otherwise condensation can form,
causing damage to the coffee system
or the surrounding cabinets.
Installation
Make sure no power is supplied to
the unit. The same applies in the
event of disassembly!
When built into cabinetry, only use
the coffee machine in ambient
temperatures between +50°F/10°C
and +100°F/38 °C.
You will need two Allen wrenches
size 3 and 5 for the installation.
To align the appliance door flush with
the kitchen cabinetry, there must be a
sealing strip around the installation
recess; otherwise, a sealing strip must
be put in place around the appliance.
^If there is no sealing strip around the
installation recess, stick the Miele
sealing strip onto the appliance from
behind before putting it into the
recess.
The sealing strip is available from
Miele.
Installation
84
Tip: A place to set down the coffee
system at the level of the installation
recess is helpful. This makes it easier
for you to install the system's
connections.
^Unscrew the four feet on the
underside of the unit by about 1/16"
(2 mm) using the larger Allen wrench.
The feet can be unscrewed by up to
3/8" (10 mm).
^Connect the system to the electricity
supply.
^Insert the coffee system all the way
into the installation recess.
When inserting the system into the
recess, make sure the electrical
connection is not damaged.
^Make sure that the coffee system is
centered and straight in the
installation recess. If necessary, align
the system using the four feet.
The coffee system comes with four M5
Allen head screws that you can use to
align and fasten it in the installation
recess.
^Open the front door and partially
tighten the screws.
^Align the appliance by carefully
adjusting the lower Allen head
screws until the unit is centered in the
installation recess.
^To secure the system in the cabinet,
tighten the upper Allen head screws
by hand.
Installation
85
Adjusting the door hinges
If the door cannot be opened or closed
easily after installation, you will have to
align the door (TX 20):
^To adjust the door flush with the front
of the cabinet, turn screw a.
^To adjust the door horizontally and
vertically, turn screw b.
Installation
86
Miele's RemoteVision Wi-Fi technology
creates a 'virtual link' between your
appliance and our monitoring center. If
a fault occurs, Miele's client service
center will be notified and contact you,
or another trusted individual identified
on your call roster, in order to gain
access to your appliance to fix the
problem.
For information on set-up and
installation of the RemoteVision module
see the "Installation" section of this
manual.
Be sure your wireless system meets the
following requirements
–A wireless router that supports an
IEEE 802.11b/g protocol
–Windows XP®or newer operating
system, Mac®OS X 10.3 or higher
–Cable or DSL modem
–Microsoft®Internet Explorer 6 or
higher, Safari 2.0 or higher, Firefox
1.5 or higher
* Please note that each wireless router
manufacturer supplies their own device
drivers and setup programs. Due to the
differences in manufacturers, exact
router setup instructions are not
included in this manual. Wording and
instructions may vary.
RemoteVision (optional accessory)
87
Miele uses software to operate and control the coffee system.
This product contains Adobe® Flash® Player software under license from Adobe
Systems Incorporated, Adobe Macromedia Software LLC. Adobe and Flash are
registered trademarks of Adobe Systems Incorporated.
The proprietary rights of Miele and other relevant software suppliers (e.g. Adobe)
must be respected.
Miele and its suppliers reserve all rights to the software components.
In particular, the following are prohibited:
–Copying and distribution,
–Modifications and derivations,
–DE compilation, reverse engineering, disassembling and other such software
reductions.
An overview of the integrated Open Source components and a copy of the current
license can be obtained at www.miele.com/device-software-licences. You will
need to enter the specific product name.
Copyright and licenses
