Midea KL15TTGIW Manual de usuario

Read This Manual

Use all instructions and explanations of

the installation before use. Follow the

instructions carefully. Keep the operation

instructions handy for later use. If the

application is sold or passed on then ensure

that the new owner always receives those

operation instructions.

OWNER’S MANUAL

Twin Tub Washing Machine

KL15TTGIW

CONTENTS

SAFETY INSTRUCTIONS

Safety precautions ....................................................

INSTALLATION

Product description ..................................................

Unpacking the washing machine ...............................

Installation area ......................................................

Change the position of the drain hose .........................

OPERATIONS

Control panel ...........................................................

Preparation before washing ......................................

Washing...................................................................

Rinse.......................................................................

Spin..........................................................................

Refer to the following table to select spinning time.....

Reference of laundry quantity corresponding to different capacities...

Laundry volume and detergent dosage reference..........

Special functions.......................................................

Maintenances

Cleaning and Care .....................................................

Cleaning the cabinet..................................................

Cleaning the inlet filter...............................................

Anti-freezing protection............................................

Operation when objects are dropped into the outside of the spin tub.....

Trouble shooting........................................................

Technical specifications.............................................

Energy efficiency test program............................................

SAFETY INSTRUCTIONS

Safety Precaution

For your safety, the information in this manual must be followed

to minimize the risk of fire or explosion, electric shock, or to

prevent property damage, personal injury or loss of life.

This appliance is not intended for use by persons (including children) with reduced physical,

or mental capabilities, or lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

sensory

If the supply cord is damaged, it must be replaced by the manufacturer, its service

agent or similarly qualified persons in order to avoid a hazard.

The new hose-sets supplied with the appliance are to be used and that old hose-sets should not

be reused.

The openings must not be obstructed by a carpet.

This appliance is intended to be used in household and similar applications such as:

− staff kitchen areas in shops, offices and other working environments;

− farm houses;

− by clients in hotels, motels and other residential type environments;

− bed and breakfast type environments;

− areas for communal use in blocks of flats or in launderettes.

SAFETY INSTRUCTIONS

Wash rated

capacity

Maximum

Water Pressure

Model

Spin rated

capacity

15.0 kg 7.0kg

0.6MPa

KL15TTGIW

SAFETY INSTRUCTIONS

！Warning!

This combination of symbol and signal word indicates a potentially

dangerous situation which may result in death or serious injuries

unless it’s avoided.

Caution!

This combination of symbol and signal word indicates a potentially

dangerous situation which may result in slight or minor injuries

or damage to property and the environment.

Note!

Explanation of the symbols:

This combination of symbol and signal word indicates a potentially

dangerous situation which may result in slight or minor injuries.

SAFETY INSTRUCTIONS

Do not install the machine in damp or rainy

environment to avoid electric shock, fire,

machine failure, or deformation. Do not spray water directly to the machine.

Do not dismantle the machine by

yourself.

Forbid dismantling

Do not place inflammable materials

like burning candle, mosquito incense,

cigaret etc. or heating source like electric

stove, calorifier etc. on the machine.

Do not let baby sit on it or place heavy

things on it.

To avoid electric shock resulting from

electric leakage, please connect

grounding wire of the plug properly.

Grounding

Wipe off dirty and dust on the plug

often to prevent poor contact with

power supply.

Make sure that the water inlet hose

is connected and the tap is opened

before washing.

Do not exceed the max. water level to

avoid water over flowing and machine

failure.

Do not let baby climb to the machine

or play near running tub to avoid

accident.

Do not put hands into the tub before

it stopping running.

If use warm water, the water

temperature should not exceed 50℃.

Do not replace power cord by yourself.

Do not pull the cord when unplug

the plug.

wat erpr oof

Insert the plug tightly when use.

Unplug the plug from socket after use.

Do not wash clothes that are stained

with kerosene, petrol, alcohol, and

other flammable substance.

Do not wash down-filled coat, raincoat

or similar clothes.

Do not insert or unplug the plug with

wet hands to avoid electric shock.

This appliance is for indoor use only.

If the supply cord is damaged, it must

be replaced by the manufacturer, its

service agent or similarly qualified

persons in order to avoid a hazard.

！！！

！！

！

Do not put finger into leaking hole on

control panel in case of any harm.

Do not put finger into rotation shaft

position on control panel in case of

any harm.

INSTALLATION

Product DescriptionProduct Description

• The product line chart is for reference only, please refer to real product as standard.

Note!

Drain hose

Accessories

manual

Inner spin cover Water inlet hose

Control panel

Wash cover

Lint filter

Pulsator

Base

Spin cover

Cabinet

Safety cover

Frame

Wash tub

Power plug

Unpacking the washing machineUnpacking the washing machine

1. Remove the cardboard box and styrofoam packing.

2. Lift the washing machine and remove the base packing.

3. Remove the tape securing the power supply cord and drain hose.

4. Remove the inlet hose from the drum.

•

Packaging material (e.g. Films, Styrofoam) can be dangerous for children.

There is a risk of suffocation ! Keep all packaging well away from children.

Warning!

！

Installation area

Before installing the machine, the location characterized

follows shall be selected:

1.Rigid, dry, level surface

2.Sufficient ventilation

3.Keep far away from the heat resources such as coal or gas.

and Avoid direct sunlight

, Room temperature is above 0 C

• wandering!

•

Stability is important to prevent the product from

Make sure that the product should not stand on the power cord.

Warning!

！

INSTALLATION

W> 20mm

Change the position of the drain hose

Front

Drain hose

According to the installation site, the drain hose can also be at the wash

side of the machine . The method is as follows:

The ex-factory installation position of the drain hose is located the spin side .

installed

1,Unplug the power cord and empty water in the drain hose

completely.

2,Spread a piece of soft cloth on the floor (e.g. a blanket)

and place the washing machine on it gently.

Take the drain hose out from the buckle at the spin side,

put it into the buckle at the wash side.

Hang up the drain hose kit.

and

Blanket

There are two ways to place the end of drain hose:

•

• Position drain hose properly ,otherwise damage might result of water leakage.

Do not kink or protract the drain hose.

• If drain hose is too long, do not force it into machine as it will cause abnormal noises.

Trough

Hose

Retainer

Bind

Min.86cm

Max.100cm

Warning!

！Warning!

！

water trough

Under3m

Under 15cm

Min.86cm

100cm

Max.

1.For lower drain system

2.For upper drain system

Preparation Before Washing

Wash timer: be used to select required washing time.

Spin timer: be used to select required spinning time.

●

● Wash-Drain selector: For washing or rinsing, select “ Normal”or“ Heavy”. For

draining ,select “Drain”

● Water inlet: be used to inject water..

• The product line chart is for reference only, please refer to real product as standard.

Note!

Drain

Open tap

Plug in

Add detergent

Washing

load and Close door

Put down the drain

Choose washing

program

Choose washing

time

Choose washing

function

Arrived after the water

level, close the tap

Open the door

•

The maximum gradient of the supporting surface for the washing machine should not exceed 2º.

•Do not tear down electrical wires and components in the machine by yourself.

•There are holes on the base for ventilation. These holes should not be blocked by

foreign objects (carpets, etc.).

•Never connect the grounding wire with the live wire, or it may lead to an electric shock.

•Check that there are no objects such as coins, hairpins, mud or sand in the pocket.

•Strings should be knotted in advance to prevent entanglement.

•Clothes can be classified for washing according to the texture, dirty degree and color.

•For small pieces (e.g.,stockings) or fluffy clothes, put them into a nylon net for washing.

Warning!

！

• The product line chart is for reference only, please refer to real product as standard.

Note!

OPERATIONS

Spin timer

Wash timer Drain selector

Soak

Was h inlet se lect or

Water inlet selector

Washing Spinning

HeavyHeavy

Heavy

NormalNormal

Normal

Wash-Drain SelectorWash-Drain Selector

Control Panel

Rinse Drain

Wash

Wash selector

Drain

Drain Drain

Wash/Rinse

Rinse Rinse

Wash Wash

soft

-7-

OPERATIONS

Spin

Spin cover

Safety cover

Shake out the laundry and

put them into the spin tub.

Put the inner spin cover on .

Confirm the inner spin cover is placed

horizontally.

the laundry Close the safety cover

and the spin cover.

Correct Incorrect

spin cover

Spin tub

Refer to the following table to select spinning time.

About 50

seconds

About 1

minute

About 1-2

minutes

About 2-3

minutes

About 3-4

minutes

About 5

minutes

Spin time

Washing

materials Silk Light clothes

(fiber/blended)

Knitwear

(fiber)

Underwear

(cotton)

Slipover

(cotton/linen)

Toweling coverlet

(cotton)

Reference of laundry quantity corresponding to

different capacities

Open tap

Rinse

Drain

Choose washing

program

Choose washing

time

Choose washing

function

Arrived after the water

level, close the tap

Heavy

Normal

Drain Drain

Rinse Rinse

Wash Wash

2.0kg Capacity about 4 pcs. about 3 pcs. about 2 pcs. about 1 pcs.

3.0kg Capacity about 6 pcs. about 4 pcs. about 3 pcs. about 1 pcs.

3.6kg Capacity about 7 pcs. about 5 pcs. about 4 pcs. about 2 pcs.

5.0kg Capacity about 10 pcs. about 7 pcs. about 5 pcs. about 3 pcs.

6.0kg Capacity about 12 pcs. about 9 pcs. about 6 pcs. about 3 pcs.

7.0kg Capacity about 14 pcs. about 10 pcs. about 7 pcs. about 4 pcs.

7.5kg Capacity about 15 pcs. about 11 pcs. about 8 pcs. about 4 pcs.

8.5kg Capacity about 17 pcs. about 13 pcs. about 9 pcs. about 5 pcs.

10.0kg Capacity about 20 pcs. about 15 pcs. about 11 pcs. about 6 pcs.

4.6kg Capacity about 9 pcs. about 6 pcs. about 5 pcs. about 2 pcs.

12.0kg Capacity about 24 pcs. about 18 pcs. about 13 pcs. about 7 pcs.

14.0kg Capacity about 28 pcs. about 22 pcs. about 17 pcs. about 9 pcs.

12.0kg Capacity about 24 pcs. about 18 pcs. about 13 pcs. about 7 pcs.

8.0kg Capacity about 16 pcs. about 12 pcs. about 8 pcs. about 5 pcs.

Capacity

Laundry

...... ...... ...... ...... ......

Jacket

about 1600 g

Shirt

about 500 g

Uniform

about 650 g

Jeans

about 900 g

5.5kg Capacity about 11 pcs. about 8 pcs. about 6 pcs. about 3 pcs.

13.0kg Capacity about 26 pcs. about 20 pcs. about 15 pcs. about 8 pcs.

15.0kg Capacity about 30 pcs. about 24 pcs. about 19 pcs. about 10 pcs.

16.0kg Capacity about 32 pcs. about 26 pcs. about 21 pcs. about 11pcs.

Tabla de contenidos

Otros manuales de Arandela de Midea

Midea

Midea MAR30-P0501GP Manual de usuario

Midea

Midea MAE180-2404TPS/01FM Manual de usuario

Midea

Midea 360111 Manual de usuario

Midea

Midea MAH180-A2801PS/01FM-US Manual de usuario

Midea

Midea MLV41N1AWW Manual de usuario

Midea

Midea MF200W85B Series Manual de usuario

Midea

Midea MTE150-P2004S Manual de usuario

Midea

Midea l712wmb16 Manual de usuario

Midea

Midea MLV47C3AWW Manual

Midea

Midea MT725B Manual de usuario

Midea

Midea MA100W75 Manual de usuario

Midea

Midea Sicily Glory G01 Manual de usuario

Midea

Midea MFWG7514 Manual de usuario

Midea

Midea MLV47C4AWW Manual

Midea

Midea MFW-801S Manual de usuario

Midea

Midea MA500W210 Series Manual de usuario

Midea

Midea MTW55 Manual de usuario

Midea

Midea MFW-EC950 Manual de usuario

Midea

Midea MAD160-A2801GPS Manual de usuario

Midea

Midea MTWR45 Manual de usuario

Midea

Midea MAC160-S2802TPS/FM Manual de usuario

Midea

Midea MT1250G Manual de usuario

Midea

Midea MLV47A3AWW Hoja de instrucciones

Midea

Midea MA500W150 Series Manual de usuario

Manuales populares de Arandela de otras marcas

Tricity Bendix

Tricity Bendix AW 1000 W Guía del producto

Panasonic

Panasonic NA-F60L5WRB Manual de usuario

GE WSLP1500 Manual

Electrolux

Electrolux EWF1284EDW Manual de usuario

Bosch

Bosch WAN2829BSN Manual de usuario

LG TV2516DV3B Manual de usuario

LG TH2517DSAV Manual de usuario

VESTEL

VESTEL CMH-XL 7510 TE Manual de usuario

AEG

AEG 74335 Manual de operación

Johnson

Johnson JWF721A Manual de usuario

Beko

Beko WTE7604XLW0 Manual de usuario

Danby

Danby DTT100A1WDB Instrucciones de montaje

Amica

Amica WA 14 Ex Manual de usuario

Daewoo

Daewoo DWD-F1222 Manual de usuario

Bosch

Bosch WAS28461AU Manual de usuario

Miele

Miele PW 6080 Vario Manual de usuario

Finlux

Finlux FLX108CF220 Manual de usuario

Whirlpool

Whirlpool 3LBR5132AN0 Manual de usuario
