Midea FT30-8MB Manual de usuario
READ AND SAVE THESE INSTRUCTIONS
Attention: Pictures in the IM are for reference only.
GD Midea Environment Appliances MFG.Co.,Ltd.
No.28, Dong Fu Road, Hesui East Industrial Area, Dong Feng Town,
Zhongshan, Guangdong 528425 P.R.China
ELECTRIC FAN
MODEL: FT30-8MB
TABLE FAN
OWNER’S MANUAL
1
Read Rules for Safe Operation and Instructions Carefully.
CAUTION
1. If the supply cord is damaged, it must be replaced by manufacturer
or its service agent or a similarly qualified person in order to avoid
a hazard.
2. To protect against the risk of electrical shock, do not immerse the
unit, cord or plug in water or other liquid.
3. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Young children should be
supervised to ensure that they do not play with the appliance.
4. When the appliance is not in use and before cleaning, unplug the
appliance from the outlet.
5. Keep electrical appliances out of reach from Children or infirm
persons. Do not let them use the appliances without supervision.
6. When the fan was assembled, the rotor blade guard shall not be
taken off anymore
- Prior cleaning unplug the fan.
- The rotor guard shall not be dissembled/opened to clean the
rotor blades.
- Wipe the fan enclosure and rotor blade guard with a slightly
damp cloth.
WARNING
1. Never insert fingers, pencils, or any other object through the
grille when fan is running.
2. Disconnect fan when moving from one location to another.
3. Be sure fan is on a stable surface when operating to avoid
overturning.
4. DO NOT use fan in window, rain may create electrical hazard.
5. Household use only.
RULES FOR SAFE OPERATION
PART FIGURE
2
1. Front grill
2. Blade
3. Plastic nut
4. Rear grill
5. Motor shaft
6. Oscillating clutch knob
7. Pedestal
8. Screw
9. Spinner
10. Base
11. Nut
12. Piano switch
ASSEMBLY OF BASE
1. Detach screw from base of the fan.
2. Match locking tab to base and click into position.
3. Tighten the screw in the base to secure the fan to the base.
Note: All the pictures in this manual are for explanation
purpose only. Any discrepancy between the real object
and the illustration in the drawing shall be subject to the
real subject.
GRILL & FAN BLADE ASSEMBLY
1. Unscrew the spinner clockwise (or take the spinner out from the bag) and the
plastic nut counterclockwise to remove both of them. Fix the rear grill to the
motor then tighten the plastic nut again. (Fig.1)
2. Insert the blade into shaft, and make sure the rotor shaft pin is fitted into groove
of the blade. Turn the spinner counterclockwise to tighten the blade. (Fig.2)
3. Open the clips on the Front Guard and place the Front Guard onto the
Rear Guard (align the locking screw holes) and close clips. Secure both
guards firmly by fitting and tightening the locking screw and nut. (Fig.3)
182311
5
4
6
7
12
Handle
Motor
tighten
loosen 10
9
Spinner Spinner
tighten
tighten
Groove
Stopper Pin
loosen
Plastic Nut
Fig.1 Fig.2 Fig.3
Blade
3
Speed control
Speed is controlled by the piano switch. (0-1-2-3)
0--Off 1--Low 2---Medium 3---High
Oscillation control
To make the fan oscillate, push down on the oscillating clutch knob located on the
top of the motor housing.
To stop the fan down from oscillating in the position desired, push on the oscillating
clutch knob once more.
Tilting control
To adjust the air flow upward or downward, push the grilles lightly to the desired
direction.
OPERATION INSTRUCTION
The fan requires little maintenance. Do not try to fix it by yourself. Refer it to qualified
service personnel if service is needed.
1. Before cleaning and assembling, fan must be unplugged.
2. To ensure adequate air circulation to the motor, keep vents at the rear of the
motor free of dust. Do not disassemble the fan to remove dust.
3. Please wipe the exterior parts with a soft cloth soaking a mild detergent.
4. Do not use any abrasive detergent or solvents to avoid scratching the surface.
Do not use any of the following as a cleaner: gasoline, thinner.
5. Do not allow water or any other liquid into the motor housing or interior parts.
MAINTENANCE INSTRUCTION
CLEANING
1. Be sure to unplug from the electrical supply source before cleaning.
2. Plastic parts should be cleaned with a soft cloth moisten with mild soap.
Thoroughly remove soap film with dry cloth.
DISPOSAL：Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities. Contact your
local government for information regarding the collection systems
available. If electrical appliances are disposed of in landfills or dumps, hazardous
substances can leak into the groundwater and get into the food chain, damaging
your health and well-being.
