Midea AMS150-CJ Manual de usuario

OWNER’S MANUAL

Electric Fan

Model: AMS150-CJ

READ AND SAVE THESE INSTRUCTIONS

Attention: Pictures in the IM are for reference only.

IMPORTANT SAFETY INSTRUCTIONS

Read Rules for Safe Operation and Instructions Carefully.

Caution

WARNING

1. If the supply cord is damaged, it must be replaced by

manufacturer or its service agent or a similarly qualified

person in order to avoid a hazard.

2. To protect against the risk of electrical shock, do not immerse

the unit, cord or plug in water or other liquid.

3. This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or

lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a

person responsible for their safety. Children should be

supervised to ensure that they do not play with the appliance.

4. When the appliance is not in use and before cleaning, unplug

the appliance from the outlet.

5. Correct Disposal of this product

This marking indicates that this product should not be

disposed with other household wastes throughout the EU. To

prevent possible harm to the environment or human health

from uncontrolled waste disposal, recycle it responsibly to

promote the sustainable reuse of material resources. To

return your used device, please use the return and collection

systems or contact the retailer where the product was

purchased. They can take this product for environmental safe

recycling.The packaging material is recyclable. Dispose of

the packaging in an environmentally friendly manner and

make it available for the recyclable material

collection-service.

1. Never insert fingers, pencils, or any other object through the

grille when fan is running.

2. Disconnect fan when moving from one location to another.

3. Be sure fan is on a stable surface when operating to avoid

overturning.

4. DO NOT use fan in window, rain may create electrical hazard.

5. Indoor use only.

RULES FOR SAFE OPERATION

IMPORTANT SAFETY INSTRUCTIONS

WARNING

6. Keep electrical appliances out of reach from Children or infirm

persons. Do not let them use the appliances without

supervision.

Indoor and household use only.

8. When the fan was assembled, the rotor blade guard shall not

be taken off anymore.

- Prior cleaning unplug the fan.

- The rotor guard shall not be dissembled/opened to clean the

rotor blades.

- Wipe the fan enclosure and rotor blade guard with a slightly

damp cloth.

PRODUCT INTRODUCTION

Pictures in the manual are for reference only, and real objects within the

packaging box will prevail in the end.

Note:

Parts name

78 89 910 10

NO. Description NO. Description

1 Operation panel

2Display panel

3Air outlet

Ambient light of belt

Base

Power cord plug

Air inlet grille

9 Pre-filter

10 HEPA filter

6Power line

Remote Controller ×1 Manual × 1 HEPA Filter ×2

PRODUCT INTRODUCTION

Parts list

INSTALLATION INSTRUCTIONS

Installation steps

Remove the protective

film of the filter.

Take out the pre-filter

Press the raised part on both

sides to pull it outwards, and

take out the pre-filter.

21 Remove the air inlet grille.

Buckle

Install the HEPA filter4

It is recommended to clean the filter once every two weeks and replace it once

every six months (the cleaning and replacement cycle can be adjusted according

to the use environment).

INSTALLATION INSTRUCTIONS

Installation steps

Install the pre-filter

Align the slot position at the

bottom, and buckle up the upper

U-shaped buckle.

Install the air inlet grille

Align the upper two buckles

and press them tightly, then

press the two sides at lower

part, slowly and gently buckle

the air inlet grille.

Buckling

position

Plug power supply7

INSTRUCTIONS

Control area Display area

Button Function Description

“- 、+”

Startup/Standby.

Set wind speed/timing.

Multi-angle oscillating switch of 30°,60°, 120° and 0°.

In the startup mode, press this button for cyclic switch between normal wind

(12 gears, indicator light is on) /sleep wind (3 gears, indicator light is

on)/baby wind (2 gears, indicator light is on).

Timed shutdown is achieved in the startup state, and reserved startup is

achieved in the standby state;

After clicking , set the timing time by pressing "+, -" (the display screen

shows 0-1-2- … -12-0h in a cycled manner), and when the timing time is 0h, it

indicates cancellation of timing/reservation.

Start up or shut down the mode of the wind changing with the temperature.

In the mode of wind changing with the temperature, the indicator light is on,

and the wind force can be automatically adjusted according to the change of

environmental temperature.

Short press to turn on/off the net ion sterilization module.

Long press for 3 seconds to reset the filter.

Ambient light function, turn on/off the Ambient light.

INSTRUCTIONS

Additional Features and Maintenance

Forced shutdown

Intelligent memory

There is no operation during the running of the fan, after 12 hours of contin-

uous operation, the fan will be forced to shut down automatically.

When the fan is turned off or powered off, it will run in the state before

turning off or power off when the power is powered on again (the timing

function is not memorized).

Screen-off function

In case of no operation for 60 seconds during normal operation, the indicator

light on the body will be automatically off, but the fan will continue to oper-

ate. Press the ON/OFF button to turn off the fan when the screen is off, and

press the other button to restore display.

Automatic reset of oscillating function upon shutdown

Upon shutdown, the oscillating function is automatically reset.

Remote control button description

Note:

The remote control should be normally used within 5 meters of the front of the product and 30

degrees of the deviation angle.

The battery contains many heavy metals, acids and bases, etc., which may threaten human's

health; Waste batteries should be recycled separately.

Start up or shut down

oscillating and air blowing

Startup/Standby

Switch the wind type

Start up /shut down the mode of

the wind changing with the

temperature

Set the timed shutdown/

reserved startup

Press “+, -” to set the wind

speed or timing time

AAA Battery, 1.5 V

Battery

Use manganese or alkaline batteries of type "AAA".

DO not use rechargeable batteries.

INSTRUCTIONS

Remote control button description

Filter replacement

Filter model: FQ150CJ-2

(including 2 sets)

12 When the indicator light for replacement

of filter is on, the prompt that reminds you

of filter replacement will appear. If it is not

replaced in time, the prompt will appear

during each startup.

4 Long press the net ion button for 3 seconds

to turn off the indicator light for filter

replacement.

Replace a new filter

PRODUCT PARAMETER

AMS150-CJ

Model

50Hz

Rated frequency

33W

Rated power

220-240V~

Rated voltage

≤61dB

Noise

INSTRUCTIONS

Pre-Filter cleaning

Unplug the power cord1

Remove the dust with vacuum

cleaner

3Install the machine in reverse

order and plug power supply

Take out the filter2
