Midea MBL-1000 Manual de usuario

PERSONAL BLENDER

USER MANUAL

MBL-1000

MBL-1000-GN

MBL-1000-PK

CONTENT

IMPORTANT SAFETY INSTRUCTIONS.

PART NAME

TECHNICAL DATA OF THE PRODUCT

INSTRUCTIONS FOR USE

IMPORTANT NOTE: Please read the manual carefully before operating your

product. Retain it for future reference.

RECIPES

CLEANING AND MAINTENANCE

CIRCUIT PRINCIPLE DIAGRAM

ABNORMALITY ANALYSIS AND HANDLING

To avoid the risk of serious injury when using your blender, basic

safety precautions should be followed, including the following.

READ ALL INSTRUCTIONS, SAFEGUARDS, AND WARNINGS

BEFORE OPERATING BLENDER

There is a potential injury from misuse. Please handle it with care.

Always disconnect the appliance from the supply if it is left unattended

and before assembling, disassembling or cleaning

This appliance shall not be used by children. Keep the appliance and its

cord out of children reach.

Appliances can be used by persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the appliance in

asafe way and if they understand the hazards involved.

Children shall not play with the appliance

Be careful when handing the sharp cutting blades, emptying the bowl

and during cleaning

Be careful if hot liquid is poured into blender as it can be ejected out of

the appliance due toasudden steaming

Switch off the appliance and disconnect from supply before changing

accessories or approaching parts that move in use.

This appliance is intended to be used in household and similar

applications such as:

–staff kitchen areas in shops, offices and other working environments;

–farm houses;

– by clients in hotels, motels and other residential type environments;

– bed and breakfast type environments.

IMPORTANT SAFETY INSTRUCTIONS

10.

If the supply cord is damaged. it must be replaced by the manufacturer.

its service agent or similarly qualified persons in order to avoid a hazard.

Ensure that the blender is switched off before removing.

SAVE THESE INSTRUCTION.

THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY.

Caution:

The failure tofollow any of the important safeguards and the important

instructions for safe use is a misuse of your personal blender that can

void your warranty and create the risk of serious injury.

Note

IMPORTANT SAFETY INSTRUCTIONS

PART NAME

No. Description

Lid

Jar (600ml)

Blade Assembly

Blend body

Switch Button

TECHNICAL DATA OF THE PRODUCT

Product name Model No. Rated voltage Rated frequency Rated power

MBL-1000

MBL-1000-GN

MBL-1000-PK

PERSONAL BLENDER 220-240V~ 50-60Hz 600W

Fill the bottle with your favorite ingredients. Be

sure not to fill ingredients over he 600ml marking.

Fasten the blade assembly on the open end of

the bottle.

Turn the bottle upside down, line up arrow “▲”on

the blade assembly to the lock “ ” on the base,

place the bottle in the base by pressing and

simply turn the bottle clockwise to lock “ ” on the

base.

Place the blender base on a flat surface and plug

in it. Pressing switch, the blender will start to

work, release switch to stops working.

INSTRUCTIONS FOR USE

After the ingredients are fully blended, stop the

blender working, and turned counterclockwise

rotation the bottle , take out the bottle form the

base.

RECIPES

INSTRUCTIONS FOR USE

Item

Carrot Test

Jar capacity 600ml

Pineapple smoothie

Crushing ice cubes

and water

Kiwi smoothie

Banana smoothie

Food Quantity

240g carrot + 360g water

154g pineapple, skin removed

diced, 300ml milk

3pcs ice cubes

168g kiwi, peeled diced

3pcs ice cubes, 300ml milk

1/2 banana, halved

250ml milk

1 scoop ice cream

1tbsp honey

250g 20mm diameter i ce cubes

250g ambient water

Time

1 mins

15 seconds

Rotating blades can cause severe injury.

DO NOT put hands, spatulas, etc. in the container while the machine is running or while

the container is still on the base.

Lids is not interchangeable between different container styles, types, and sizes.

DO NOT reach into container while machine is running.

Machine running time can not be more than 3 minutes. After the shutdown, it is

necessary to let it fully heat, cooling to room temperature.

Warning

Replace the blade assembly to use.

1. In case of abnormalities such as abnormal noises, smell, smoke, etc., you

should immediately cut off power and stop use.

2. If the product cannot work, please check if the power supply is connected, if

the switch is put to the ON position and if fittings are installed in place.

3. If the product still cannot work after checks mentioned above, please consult

the designated repair centre for maintenance.

Product does

not work

Blender blade

stuck

ABNORMALITY ANALYSIS AND HANDLING

Abnormality Handling

Fault Analysis and Elimination

Symptom Analysis of

Possible Causes Countermeasure

The jar assembly is not

installed in place.

The jar assembly must be closed in place.

The inching switch is not

pressed.

Keep the switch press states.

The amount of processed

food is too much.

Reduce the amount of processed food.

Food sticking the blade. Switch off electrical power if clean up the

ingredients on the clean blade.

The Products

found abnormal

odor, hot, smoke

and other

phenomena

The amount of processed

food is too much.

Reduce the amount of processed food.

The product running times

too long.

Reduce the motor running times.

The temperature of the

processed ingredients is

too high.

Do not exceed 60 °C.

Jar drain juice

(water)

The blade holder seal is

missing or not properly

mounted on the tool

holder assembly.

Check the blade holder seal states.

The jar is screwed into the

blade holder assembly

without tightening.

Check the jar whether on tightening.

The jar is screwed into the

jar cover without tightening.

Check the jar whether on tightening

Unplugged from the power source before

cleaning.

Remove all fittings except the main engine for

leaning in water. Please be careful when

cleaning the blade, sharp blade, to avoid being

cut.

Use a damp cloth to wipe the surface of the

motor body, with a dry cloth, must not be the

main motor body into water or other solution for

cleaning, in order to avoid danger.

After all the parts are dried, the method can be

assembled according to the previous method.

The product has any problem in use, please do

not disassemble without permission of the host,

should immediately contact the nearest

authorized service provider or customer service

maintenance point detection, maintenance.

The blade can be disassembled for cleaning,

disassembly, a hand glove on the fixed blade,

another hand counterclockwise rotation onnector

remove blade, connector, washer for cleaning.

CLEANING AND MAINTENANCE

CIRCUIT PRINCIPLE DIAGRAM

Cleaning

Note:

The appliance must not be disposed of with regular household waste.

At the end of its service life, the appliance must be properly delivered

to a collection point for the recycling of electrical and electronic

equipment. By Collection By Collection and recycling of old appliances,

you are making an important contribution to the conservation of our

natural resources and provide for environmentally sound and healthy

disposal.

Environmental protection

MESIN PENGISAR PERIBADI

PANDUAN PENGGUNA

MBL-1000

MBL-1000-GN

MBL-1000-PK

KANDUNGAN

ARAHAN KESELAMATAN PENTING.

NAMA BAHAGIAN

DATA TEKNIKALPRODUK

ARAHAN PENGGUNAAN

NOTA PENTING: Sila baca buku panduan ini dengan teliti sebelum anda

mengendalikan produk ini dan dismpan untuk rujukan kelak.

RESEPI

PEMBERSIHAN DAN PENYELENGGARAAN

DIAGRAM PRINSIP LITAR

PENGENDALIKAN DAN ANALISIS KEABNORMALAN
