X556 IMEI Writing Procedure

Micromax X556

1. Technical Specifications :

Please fill below information in Remarks, Below given remarks are for reference only

Particular

Remarks

Key Matrix For Flashing

SPRD Flashing tool

Chipset

SC6531DA

Android Version

NA

Processor Frequency

900/1800MHz

Network Mode

GSM

ROM

32Mb

RAM

32Mb

Internal memory

4MB

Expandable Memory

8GB

Factory mode code

#*878*#

Good Earpiece value in ohms

32 Ohm

Good Loudspeaker value in ohms

8 Ohm

Good Mic value in ohms

330 Ohm

Good Vibrator value in ohms

NA

X556 IMEI Writing Procedure

2. CAUTIONS

I. Flashing & Servicing must be undertaken by qualified personnel only.

II. Ensure all work is carried out at an anti-static workstation and that an anti-static wrist strap is worn.

III. Use only approved Tools & components as specified in the parts list.

IV. Ensure all components, modules, screws, and insulators are correctly re-fitted after servicing and

alignment

V. Ensure all cables and wires are repositioned correctly if Handset disassembled

VI. Electrostatic discharge can easily damage the sensitive components of electronic products.

Therefore, Service Centre must adhere the precautions which mentioned above.

3. IMEI Writing Procedure

3.1 . Engineering code: Power On the device and type #*878*# to enter into Engineering Mode as

Shown below:

3.2. Para Set: Move down to 8 number which is Parameter set (Para Set) as shown below:

X556 IMEI Writing Procedure

3.3. Update IMEI Number: Move down to 16 number for Update IMEI Number as shown below:

3.4. IMEI 1: Enter 15 Digit IMEI 1 as “a IMEI 1” (Ex: a123456789123456) by selecting the language

settings and after Enter 15 digit IMEI Press OK as shown below:

X556 IMEI Writing Procedure

3.5. IMEI 2: Similarly Enter 15 Digit IMEI 2 as “ a IMEI 2”( Ex: a987654321987654) by selecting the

language settings as shown above fig and after Enter 15 digit IMEI Press OK as shown below:

X556 IMEI Writing Procedure

3.6. EXIT: After entering the both IMEI press back for exit as shown below:

X556 IMEI Writing Procedure

3.7. Restart: After Exit from Engineering Mode, restart the device. Your IMEI will write correctly in the

device. Press *#06# for checking IMEI shown like as below:

Thanks

For any Query or suggestion, Please write to tech.help@micromaxinfo.com
