1. Connect an IEEE®802.3af/at/bt-compliant

PSE to the PD-USB-DP60’s “PoE IN” RJ45

socket using a standard Cat 5/5e/6 Ethernet

cable. (Note: The maximum allowed length

of the Ethernet cable is 100 meters).

2. Check that the “Power” LED is yellow to

verify that the PD-USB-DP60 is powered on.

3. Connect one side of the supplied USB

Type-C®cable to the PD-USB-DP60’s

USB-C socket. (Note: Any USB-C connec-

tion polarity is allowed.)

4. Connect the other side of the USB Type-C

cable to the USB-C powered device.

5. Verify that the USB-C powered device is

getting power from the PD-USB-DP60.

PoE IN

USB-C®

PD-USB-DP60 Quick Start Guide

Ethernet-to-USB-C Data Dongle

If PoE power isn’t available, and wired Etherent

is required, the PD-USB-DP60 can be powered

from a USB Host:

1. Connect one side of the supplied USB Type-C

cable to the USB-C host.

2. Connect the other side of the USB Type-C

cable to the PD-USB-DP60’s USB-C socket.

3. Connect a standard Cat 5/5e/6 Ethernet cable

the PD-USB-DP60’s “PoE IN” RJ45 socket to

connect to an IEEE 802.3 10/100/1000 Mbps

network.

LED Indicators

LED Appearance Status

Power

No Light

PD-USB-DP60 is:

powered o or powered

on as a dongle

Yellow On PD-USB-DP60 is powered

Link/

Act

No Light No data link

Green On Data link on

Green

Blinking Data activity on

Specicaons

Data

• PoE IN

• 10/100/1000 Mbps

• USB Type-C

• USB 2.0

• USB 3.1 Gen 1

Power

• PoE IN

• Input Voltage: 42-57 VDC

• Input Current: 1.75A max

• USB Type-C

• 5 VDC/3A

• 9 VDC/3A

• 15 VDC/3A

• 20 VDC/3A

Environmental Informaon:

• Operating Temperature: 0°C to 40°C (32°F to 104°F)

• Operating Humidity: 90% Max (non-condensing)

• Storage Temperature: −20°C to +70°C (−4°F to +158°F)

• Storage Humidity: 95% Max (non-condensing)

• Dimensions: 22.4 mm (H) x 66.8 mm (W) x 105.2 mm (L)

• Weight: 150g

The Microchip name and logo and the Microchip logo are registered trademarks of Microchip Technology

Incorporated in the U.S.A. and other countries. All other trademarks mentioned herein are property of their

respective companies.

Notes

• If the USB host is running the Windows®operating system, the device driver should be automat-

ically installed (plug and play) after the PD-USB-DP60 is connected. Linux®may require driver

installation in case the LAN7800 Ethernet controller is missing. Apple®requires driver installation.

• If the USB host doesnt recognize the PD-USB-DP60 as a USB device, please go to the LAN7800

product page to download and install the appropriate device driver.

• Powering multiple PD-USB-DP60 from the same PoE multiport midspan may aect data/power per-

formance to connected USB-C devices (i.e. laptop) if they are sharing common peripheral equipment

such as monitors, projectors, etc.

Technical Support

For technical support please visit the Microchip Technical Support Portal www.microchip.com/support

LAN7800 Driver

To download device drivers for the LAN7800 please visit the LAN7800 WEB page: LAN7800

USA/Canada: +1 877 480 2323
